Summary of Contents for kincrome KP2301
- Page 1 SMD LED WORKLIGHTS SMD LED 240V WORKLIGHTS 5000K SOFT ALUMINIUM & STEEL BRIGHT WHITE CABLE GRIP HANDLE COLOUR CONSTRUCTION TECHNOLOGY LENGTH KP2301, KP2302, KP2303, KP2304, KP2305 ED1/June 16...
- Page 2 1. Soft Grip Handle 7. Tempered Glass Safety Shield 2. Tilt Lock Knobs 8. SMD LED 3. Light Support Frame 4. H Frame Stand Part No: ......KP2301 Light Angle: .....120º Description ......20W Floor Worklight Ingress Protection: ..IP65 LED Power: .....20W Construction: ....Aluminium Worklight LED Construction: ..SMD (Surface Mounted Device)
-
Page 3: Know Your Product
SMD LED WORKLIGHTS Know Your Product 5. Light Lock Knob 6. Aluminium Light Body 1. Soft Grip Handle 7. Tempered Glass Safety Shield 2. Tilt Lock Knobs 8. SMD LED 3. Light Support Frame 4. H Frame Stand Part No: ......KP2302 Light Angle: .....120º... - Page 4 SMD LED WORKLIGHTS Height Adjustable Tripod 1600mm 1345mm 1040mm Know Your Product 6. Telescopic Stand Leg Lock Knob 7. Telescopic Stand Legs 1. Soft Grip Handle 8. Quick Release Clamp 2. Tilt Lock Knobs 9. Light Lock Knob 3. Light Support Frame 10.
- Page 5 SMD LED WORKLIGHTS Height Adjustable Tripod 1625mm 1375mm 1055mm Know Your Product 6. Telescopic Stand Leg Lock Knob 7. Telescopic Stand Legs 1. Soft Grip Handle 8. Quick Release Clamp 2. Tilt Lock Knobs 9. Light Lock Knob 3. Light Support Frame 10.
- Page 6 SMD LED WORKLIGHTS Height Adjustable Tripod 2140mm 1675mm 1215mm Know Your Product 6. Telescopic Stand Leg Lock Knob 7. Telescopic Stand Legs 1. Soft Grip Handle 8. Quick Release Clamp 2. Tilt Lock Knobs 9. Light Lock Knob 3. Light Support Frame 10.
-
Page 7: Work Area Safety
SMD LED WORKLIGHTS GENERAL SMD LED WORKLIGHT SAFETY WARNINGS Save all warnings and instructions for future reference. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in serious injury. 1) Work Area Safety a. - Page 8 SMD LED WORKLIGHTS 4) Power Tool Use and Care a. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b.
- Page 9 SMD LED WORKLIGHTS DESCRIPTION OF SYMBOLS The following symbols could be shown on the tool: Read the instruction manual before use. Failure to follow the warnings and instructions may Watts result in electric shock, fine and/or serious injury. Warning Kilograms Alternating current Volts Amps...
- Page 10 SMD LED WORKLIGHTS ASSEMBLY Note: The below assembly instructions covers models KP2301, KP2302, KP2303, KP2304 & KP2305. Assembly of Floor Worklights (KP2301 & KP2302) Place the H frame stand (4) on a stable work area with the rubber feet facing down (Fig 1).
- Page 11 SMD LED WORKLIGHTS Assembly of KP2304 & KP2305 - 2 in1 Twin Worklights 1. Place the H frame stand (4) on a stable work area with the rubber feet facing down (Fig.9). 2. Place the soft grip handle (1) frame onto the H frame stand (4). 3.
-
Page 12: Operation
SMD LED WORKLIGHTS OPERATION Note: Always ensure that the LED worklight is directed away from you or other bystanders before switching the LED worklight ON. The LED light output could cause damage to the eyes if directed at a bystander’s eyes. Adjusting the LED Light Output Direction Up/Down The LED work light heads can be tilted 30°... -
Page 13: Cleaning And Maintenance
If this product has materials or workmanship defects (other than defects caused by abnormal or non-warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. - Page 14 www.kincrome.com.au...
