- Page 1 EVOSKILLZ Audio Embedder with Source Sensing, EDID and Scaling Source Sensing Audio Embedder Part Number: EVOSKLZ1 www.vanco1.com • 800.626.6445...
- Page 2 DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters.
-
Page 3: Package Contents
INTRODUCTION The Evolution by Vanco EVOSKILLZ is a first of its kind. This patent pending technology gives the ability to pass audio and video from an HDMI source and have the audio switched to a secondary audio source automatically via 3.5mm input. EVOSKILLZ comes equipped with an HDMI 2.0a input for audio and video, a 3.5mm stereo port to provide audio from a secondary source,... -
Page 4: Specifications
SPECIFICATIONS HDMI Compliance ............HDMI 2.0a HDCP Compliance ............HDCP 2.2/1.4 Video Bandwidth ............18Gbps Video Resolutions ............Up to 4K2K@50/60Hz(YUV4:4:4), HDR10 and Dolby Vision Compatible Color Space .............. RGB, YCbCr 4:4:4, YCbCr 4:2:2 HDMI Audio (Pass-through) ......... LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X Audio Embedding ............ -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Front Panel Micro USB C: Plug in included power cable and adapter, cable can also be connected to a PC for available firmware updates Power LED: Solid and on when power is being provided to the unit RX Signal: Solid and on when a device is powered on, connected, and passing signal from the HDMI output port HDMI Input: Connects to HDMI source Stereo IN: Connects to a secondary analog audio source via 3.5mm... -
Page 6: Connect And Operate
CONNECT AND OPERATE Analog Audio/Voice Control Source HDMI Source HDMI Stereo Audio Cable HDTV HDMI 1. With power off, connect an HDMI source to the HDMI INPUT of the EVOSKILLZ unit using an HDMI cable 2. Connect an HDMI display to the HDMI OUTPUT using a HDMI cable 3. -
Page 7: Software Setup
SOFTWARE SETUP 1. Click on Connect 2. Click on the Checkbox for SW Control 3. Click Apply a. f SW Control is not selected, settings will be read from the dials on the unit b. If SW Control IS selected, settings will be read and applied from the software and will override any dial settings 4. - Page 8 6. The top number is the largest WHOLE number 7. The bottom number is to the nearest tenth a. The example shown above would 4.1db as a setting. b. A setting that is too HIGH will never switch from HDMI to Analog Audio c.
- Page 9 9. For installations where other variables can apply such as a microphone or paging application, use the REFRESH TIME setting. This setting will look for the analog audio signal based on the time period that is selected. a. Click on the dropdown menu and select a time interval, then click apply b.
-
Page 10: Limited Warranty
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco regarding warranty repair or replacement. -
Page 11: Technical Support
TECHNICAL SUPPORT In case of problems, please contact Vanco Technical Support by dialing 1-800-626-6445. You can also email technical support issues to techsupport@vanco1.com. When calling, please have the Model Number, Serial Number (affixed to the bottom of the unit) and Invoice available for reference during the call. - Page 12 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
