FLAME
µQMCV MIDI to CV interface
MANUAL
Version 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mQMCV and is the answer not in the manual?

Questions and answers

Summary of Contents for Flame mQMCV

  • Page 1 FLAME µQMCV MIDI to CV interface MANUAL Version 1.00...

  • Page 2: Table Of Contents

    Manual FLAME QMCV Version 1.00 Contents 1. Short description..............2. Hardware / connections............3 2.1 Connection to the modular system (Doepfer bus) 2.2 Module overview 2.3 MIDI connections 3. Handling ................3.1 Quad MIDI to CV interface 3.2 Multimode 3.3 Modulation / Pitchbend outputs 3.4 RUN / 1/16th outputs...

  • Page 3: Short Description

    1. Short description The "µQMCV" module is a compact up to 4 voice MIDI-to-CV interface with additional CV out- puts for modulation and pitch bend, as well as two MIDI clock outputs for RUN and 16th clock. The range of notes is 8 octaves. The MIDI interface is multi-mode capable, which means that the individual voices can be used separately on different MIDI channels in defined modes in groups.

  • Page 4: Module Overview

    2.2 Module overview LEARN button Gate Note/Velocity CV outputs voice 1 Gate Note/Velocity CV outputs voice 2 Gate Note/Velocity CV outputs voice 3 Gate Note/Velocity CV outputs voice 4 MIDI Clock RUN output 1/16th MIDI Clock output MIDI Input (MIDI TRS-B Standard) MIDI THRU Output (MIDI TRS-B Standard) CV outputs Modulation and Pitchbend...

  • Page 5: Midi Connections

    2.3 MIDI connections The module has two MIDI sockets (TRS-B standard mini jacks) INPUT and THRU. Connect the MIDI input to the MIDI output of your keyboard / controller or computer. The data received at MIDI-IN is forwarded via MIDI-THRU. A corresponding commercially available adapter (MIDI-DIN to Mini TRS- B) or a 3.5mm (1/8 inch) stereo jack cable is used for the MIDI connection.

  • Page 6: Handling

    3. Handling 3.1 Quad MIDI-to-CV Interface The module is preset as a four-way MIDI-to-CV interface on midi channel 1. The two controllers MODULATION and PITCHBEND also work on this midi channel. Send notes from a connected MIDI keyboard over an 8 octave range of note numbers 12-108. The module can output the GATE and CV voltages for up to 4 notes at the same time.

  • Page 7: Multimode

    3.2 MULTIMODE The four voices of the module (each with GATE / NOTE / VELOCITY outputs) can also be used separately in other defined groups. To do this, the voices must be assigned to other midi chan- nels. There are 5 modes that can be set with the LEARN function (or via SYSEX): quad polyphon (all same midi channel) ->...

  • Page 8: Modulation / Pitchbend Outputs

    3.3 MODULATION / PITCHBEND CV outputs The module has two additional CV outputs: The CV output MODULATION reacts to MODWHEEL (Control Change No. 1) and supplies a voltage of 0 .. + 5V The CV output PITCHBEND reacts to the pitch bend wheel and supplies a voltage of 0 .. + 2v. After switching on, the voltage is set to + 1v (middle position of the pitch bend wheel).

  • Page 9: Settings Via Sysex Files

    Type 2: set midi channel and control change number from the MODULATION output Type 3: set midi channel from the PITCHBEND output You can download some ready-made SYSEX files from the FLAME website. You can also create your own SYSEX files (for example with the freeware program MIDI-OX).

  • Page 10: Sysex Data Format

    (modulation and pitch bend) can be done with the help of SYSEX data. The module understands different types of SYSEX files: Typ 1: SYX file for all data 11110000 Exclusive Status 01111101 Header Flame module 00001011 Flame module “µQMCV” 00000001 version 1 00000110...
  • Page 11 Typ 3: SYX file for setting the midi channel from the CV output pitch bend 11110000 Exclusive Status 01111101 Header 00001011 Flame module “µQMCV” 00000001 version 1 00000111 data type 3 (dump midi channel pitchbend output) 0000xxxx pbch 1 data byte MIDI channel of Pitchbend output (range: 00=channel 1 ..
  • Page 12 - electric damage caused by improper connecting (wrong power supply/ jacks/ MIDI connections/ voltage problems). If you have any complaints please contact your dealer or send an e-mail to: service@flame-instruments.de 4.3 Terms of production conformity: CE, RoHS, UL 4.4 Disposal The device is produced with RoHS-conformity (subject to the regulations of the European Union) and is free of hazardous substances (like mercury, plumb, cadmium and hexavalent chrome).
