Summary of Contents for Boss BTC750
- Page 1 BTC750 INSTRUCTION MANUAL...
- Page 2 Customer Service: 1800 505 045 BTC750 INSTRUCTIONS PARTS Required Tools: Builders Square & 10mm Spanner. Spare Wheel Available: BTC750SW ASSEMBLY Step 1: Place main guide(G) onto base(A). Image 1.1 Place rip guide(F) on to main guide (G). Secure with washer(B) and guide knob(D). Image 1.2 Image 1.1...
- Page 3 ALIGNMENT & ADJUSTMENT Step 1 - 90° Alignment: Place 90° builders square (not supplied) on to base(A) and align to 90° (image 3.1). Secure in position by tightening guide knob(D). Adjust the bolt on the guide so it sits firmly against base (image 3.2). Once secured tighten locking nut using a 10mm spanner (not supplied) (image3.3).
