- Page 1 Nano update procedure User manual uRTime www.urtime.net || Email: info@urtime.net...
-
Page 2: Table Of Contents
3.1.1 FLIP software installation .................... 4 3.1.2 Device installation ....................... 6 Nano update ........................8 3.2.1 Update preparation ..................... 8 3.2.2 Firmware update ....................... 10 3.2.3 Nano configuration ....................11 3.2.4 Images screen update ....................19 uRTime www.urtime.net || Email: info@urtime.net... -
Page 3: Table Of Figures
Figure 5 : SCE screen ........................8 Figure 6 : PICASO screen ........................8 Figure 7 : Latest Nano software release to be downloaded on the support website ....10 Figure 8 : Nano update window ....................10 Figure 9 : Configuration menu ....................... 11 Figure 10 : QUARK RFID ......................... -
Page 4: Update Procedure
If you have never update a Nano with your computer, start to the chapter 3.1 Installation of the tools. If you have a Nano firmware older than 18.XX.XX , start to the chapter 3.2.1 Update preparation. If you have a Nano firmware greater than 18.XX.XX, follow only the chapter 3.2.2 Firmware update. -
Page 5: Installation Of The Tools
3.1 Installation of the tools The following steps need to be done on a computer that you will use to update the Nano, only once. The complete procedure is also described in this video: https://www.youtube.com/watch?v=OuAOvbmSp9U (French version) https://www.youtube.com/watch?v=ZSikI0ePTeY&t (English version) 3.1.1 FLIP software installation... - Page 6 Figure 2 : Java Runtime Environment installation Figure 3 : Flip installation uRTime www.urtime.net || Email: info@urtime.net...
-
Page 7: Device Installation
3. Switch on the Nano while holding the red button down. The first time you connect your Nano to your computer, you will have to install the correct driver. Open the device manager. The Nano will be in “Other devices”. - Page 8 Once the driver correctly installed, the Nano will be recognized as an Atmel USB Device in the Device manager. Next : prepare the Nano. uRTime www.urtime.net || Email: info@urtime.net...
-
Page 9: Nano Update
You need to see the current firmware release of the Nano (Menu > Settings > Identity). If the Nano have a firmware release less than 18.XX.XX you need to prepare the update. On the other hand, you can go to the paragraph 3.2.2 Firmware update. - Page 10 This is an example of nano.nv configuration file for a SCE screen : nvScreen = 0 Put the SD card and put the nano.nv file on the SD card before the update. After the update, the Nano loads the configuration file and deletes it.
-
Page 11: Firmware Update
A password, provided by RFConception, will be required to log in. Download the firmware: the filename contains the date of the version. Figure 7 : Latest Nano software release to be downloaded on the support website Once downloaded, unzip the file. You should have two files: “flashNano.bat” and “nano.elf”. -
Page 12: Nano Configuration
After the update, go to the “Nano Type” menu (Menu > Settings > Advanced Settings). A password is required to enter Nano Type, RFID Power or Up Screen. The password is “urtime”. With this menu (Figure 9), configure the Nano in function of the hardware: •... - Page 13 New battery holder, direct sim card holder (3G) but no SD inside. RFID reader is QUARK Figure 12 : RS500 RFID New battery holder + direct sim card holder (3G) + SD inside. RFID reader is RS500. uRTime www.urtime.net || Email: info@urtime.net...
- Page 14 Modem type Remove the back cover to see inside the Nano. 2G Modem (GC864) Figure 13 : 2G GSM module (GC864) 2G modem (GC864). 3G Modem (HE910) Figure 14 : 3G GSM module (HE910) 3G Modem (HE910). However, you need call immediately uRTime.
- Page 15 Figure 15 : Intermediate version with a 3G GSM module(HE910) 3G modem (HE910) Figure 16 : New version with 3G GSM module (HE910) 3G modem (HE910) uRTime www.urtime.net || Email: info@urtime.net...
- Page 16 For WIFI module, you can read “MODEL: XBEES6B” or “XB2B” on the module. XBee module Figure 19 : XBee module If the Nano, have an old hardware version, and have a satellite module, he doesn’t have a Wi-Fi or XBee module. uRTime...
- Page 17 Figure 20 : Intermediate version Figure 21 : New version with Wi-Fi module uRTime www.urtime.net || Email: info@urtime.net...
- Page 18 Satellite module Remove the bottom cover to see inside the Nano. Satellite module Figure 22 : Satellite module on old hardware version Satellite module Figure 23 : Satellite module on new hardware version uRTime www.urtime.net || Email: info@urtime.net...
- Page 19 Satellite antenna Figure 24 : Nano with satellite antenna If you see this module and the antenna, you have a satellite module. uRTime www.urtime.net || Email: info@urtime.net...
-
Page 20: Images Screen Update
To update the images of the screen, go to the advance menu (Menu > Settings > Advanced Settings > Up Screen). A password is required to enter Up Screen. The password is “urtime”. With the PICASO screen the file transfer can take up 5 minutes par files.
