Safety Guidelines:
•
Locate the vehicle and Easy Lift on a level and solid floor.
•
Engine must be switched off.
•
Handbrake must be OFF and gearlever in neutral.
•
Tyre pressures must be to manufacturers' recommendations.
•
If using sill-lifter it must be positioned at forward sill jacking point on a front-
engined vehicle. (Refer to manufacturers' handbook.)
•
Always support vehicle with axle stand(s). Ensure the vehicle is sitting
securely on the support stands before getting under vehicle.
•
Do not exceed the weight capacity of the Easy Lift (1500kg).
•
Do not use the Easy Lift if damaged.
•
Do not allow untrained persons to operate the Easy Lift.
Note: No responsibility is accepted for incorrect use of the Easy Lift.
Our products are designed to be used correctly and with care for the purpose for which they are
intended. No liability is accepted by the Tool Connection for incorrect use of any of our products, and
the Tool Connection cannot be held responsible for any damage to personnel, property or equipment
when using the tools. Incorrect use will also invalidate the warranty.
If applicable, the applications database and any instructional information provided has been designed
to offer general guidance for a particular tool's use and while all attention is given to the accuracy
of the data no project should be attempted without referring first to the manufacturer's technical
documentation (workshop or instruction manual) or the use of a recognised authority such as
Autodata.
It is our policy to continually improve our products and thus we reserve the right to alter
specifications and components without prior notice. It is the responsibility of the user to ensure the
suitability of the tools and information prior to their use.
Guarantee
If this product fails through faulty materials or workmanship, contact our
service department direct on: +44 (0) 1926 818186. Normal wear and tear are
excluded as are consumable items and abuse.
www.power-tec.co.uk
Distributed by The Tool Connection Ltd
Kineton Road, Southam, Warwickshire CV47 0DR
T +44 (0) 1926 815000 F +44 (0) 1926 815888
info@toolconnection.co.uk www.toolconnection.co.uk
Easy Lift Hydraulic
3000kg
www.power-tec.co.uk
92409
Advertisement
Summary of Contents for Power Tec Easy Lift 92409
- Page 1 92409 Safety Guidelines: • Locate the vehicle and Easy Lift on a level and solid floor. • Engine must be switched off. • Handbrake must be OFF and gearlever in neutral. • Tyre pressures must be to manufacturers’ recommendations. • If using sill-lifter it must be positioned at forward sill jacking point on a front- engined vehicle.
- Page 2 92409 Easy Lift Hydraulic Specifications: Ideal for bodyshops, this mobile vehicle lift will raise cars and light commercials to a maximum height of 995mm. No electrical connections Weight: 85kg are required as the Easy Lift uses a 350bar hydraulic pump powered by the Lifting Capacity: 1500kg (per side: 3000kg max vehicle weight) workshop compressed air supply.
- Page 3 92409 Easy Lift Hydraulic Instructions Lifting Attachments: The Easy Lift is supplied with wheel-lifter and a sill-lifter. (Refer to Figs. 3 & Raising: 1. Move Easy Lift to vehicle using the handlebars. 2. Place in desired position, ie, at the front or rear wheel of vehicle (if using the wheel lifter) or fitted under the forward sill jacking point (if using the sill lifter on a front-engined vehicle).
- Page 4 92409 Easy Lift Hydraulic Hydraulic Pump Oil Level: Why does the vehicle not turn over when lifting it with the Easy Lift? The Easy Lift hydraulic pump is supplied ready-filled with hydraulic oil. Prior to first use remove the sealing plug from the dipstick hole (E on Fig. 1) and fit the cap/dipstick assembly.
