Flashing System Installation

Types FCU-3-in-1 and FCU-1-in-1

User Manual

UM-4018_AM02-620e, Rev. 3.0, 2020/05/12

Table of Contents

Need help?

Do you have a question about the FCU-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADB Safegate FCU-1

Page 1 Flashing System Installation Types FCU-3-in-1 and FCU-1-in-1 User Manual UM-4018_AM02-620e, Rev. 3.0, 2020/05/12...
Page 3 Material Handling Precautions and Storage precautions that must be followed. ADB SAFEGATE reserves the right to examine goods upon which a claim is made. Said goods must be presented in the same condition as when the defect therein was discovered. ADB SAFEGATE furthers reserves the right to require the return of such goods to establish any claim.
Page 4 This manual could contain technical inaccuracies or typographical errors. ADB SAFEGATE BV reserves the right to revise this manual from time to time in the contents thereof without obligation of ADB SAFEGATE BV to notify any person of such revision or change. Details and values given in this manual are average values and have been compiled with care. They are not binding, however, and ADB SAFEGATE BV disclaims any liability for damages or detriments suffered as a result of reliance on the information given herein or the use of products, processes or equipment to which this manual refers.
Page 5: Table Of Contents
2.2 Abbreviations and terms ......................................9 3.0 Introduction ..................................11 3.1 Flashing system overview ....................................11 3.2 Lay-out of the equipment cabinets ................................. 12 3.2.1 FCU-1 ..........................................12 3.2.2 FCU-3 ..........................................13 3.2.3 LMC ..........................................14 3.3 Intended use ..........................................14 3.4 Description ..........................................
Page 6 8.0 Technical data ..................................59 8.1 Technical characteristics ....................................... 59 8.2 Ambient conditions ....................................... 59 A.0 SUPPORT ....................................61 A.1 ADB SAFEGATE Website ...................................... 61 A.2 Recycling ............................................ 61 A.2.1 Local Authority Recycling ..................................61 A.2.2 ADB SAFEGATE Recycling ..................................62...
Page 7 Table 29: Default remote control signals ..................................53 Table 30: J-Bus connectors ........................................55 Table 31: Wiring for connectors P1-P4 ................................... 55 Table 32: Technical characteristics ....................................59 Table 33: Ambient conditions ......................................59 UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 9: Safety
1.0 Safety Introduction to Safety This section contains general safety instructions for installing and using ADB SAFEGATE equipment. Some safety instructions may not apply to the equipment in this manual. Task- and equipment-specific warnings are included in other sections of this manual where appropriate.
Page 10: Introduction To Safety
Using this equipment in ways other than described in this manual may result in personal injury, death or property and equipment damage. Use this equipment only as described in this manual. Failure to follow this instruction can result in serious injury or equipment damage Copyright ADB Safegate, All Rights Reserved ©...
Page 11: Material Handling Precautions: Storage
Note To minimize the risk of errors, the ADB SAFEGATE Sales Representative will have information on which gasket goes with which base. This information is also provided in the product Data sheets, the User Manuals and the Spare Part Lists.
Page 12: Operation Safety
• Airport Operations, Maintenance and other Authorised Personnel • This information is a summary of the safety requirements on operation and maintenance personnel based on general electrical and laser safety precautions. Copyright ADB Safegate, All Rights Reserved ©...
Page 13 Safedock system should only be used by airport operations and maintenance personnel who have been properly trained in the use of the system. ADB SAFEGATE takes no responsibility for incorrect use of the system. All warnings contained in the text of this manual must be strictly observed.
Page 14: Maintenance Safety
PURSUANT to LASER NOTICE NO. 54, DATED June 24, 2007 • ADB SAFEGATE accepts no liability for the misuse of its equipment or for the consequences of this misuse. • ADB SAFEGATE recommends that eye safety procedures be followed in accordance with ANSI Z136.1 –...
Page 15: Material Handling Precautions, Esd
• Allow only qualified personnel to perform maintenance, troubleshooting, and repair tasks. • Only persons who are properly trained and familiar with ADB SAFEGATE equipment are permitted to service this equipment. • An open airfield current circuit is capable of generating >5000 Vac and may appear OFF to a meter.
Page 17: About This Manual
The manual covers installation of the following: • FCU-1 and FCU-3 If in the manual the term equipment used, this refers to both the FCU-1 and FCU-3. 2.1 How to Work with the Manual 1. Familiarize yourself with the structure and content.
Page 18 Flashing mode: Simplified Short Approach Lighting System with Sequenced flasher heads TWAVBI Type of armored multiwire underground signalization cable Unidirectional Elevated Light type (ADB type elevated flashing head) WAGO Brand of spring leaf connectors Copyright ADB Safegate, All Rights Reserved ©...
Page 19: Introduction
The illustration shows a schematic overview of the components of a flashing system. The design plan shows the actual lay- out. A flashing system can contain up to 32 flashing heads. Every flashing system has one LMC. The LMC can be installed in an FCU-1 cabinet or in a FCU- 3 cabinet. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12...
Page 22: Lmc
FCU-3: one cabinet with three FCUs for 3 flash units: three-phase power supply. It is possible to combine these two types of cabinets in one system. Then, FCU-1 cabinets must have a separate junction box (option) to connect to the three-phase power supply.
Page 23: Local Master Controller (Lmc) Description
The LMC is a PCB installed in the cabinet door of any equipment cabinet in the flashing system. It is recommended to install the LMC in an equipment that you can easily access for maintenance. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 24: Options
A multiwire PCB has 2 times 12 terminals. The terminals handle the maximum 8 incoming and maximum 8 outgoing signals between the equipment and the remote control system. There is only one multiwire PCB possible per LMC, so also one multiwire PCB per flashing system. Copyright ADB Safegate, All Rights Reserved ©...
Page 25: Table 3: Multiwire Options
The multiwire back-indication signals are provided over dry contact relays. The maximum contact load is: • AC - 110 V -0.5 A - 60 VA • DC - 110 V -0.5 A - 30 W UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 27: Inspection And Transport
The LMC is packed separately. 4.2 How to transport the crate CAUTION • The maximum weight of the equipment is approximately 47 kg (FCU-3) or 19.4 kg (FCU-1). • Keep the crate in a vertical position at all times. •...
Page 29: Pre-Installation
When you carry out the calculations, make sure that the last FCU PCB receives at lease 190 VAC between the phase and neutral conductor; • Calculate maximum 1.5 A per FCU PCB. • Make sure the cable is suitable for 415 V AC. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 30: Connection Between Equipment And Flasher Heads
5: 3 phases, neutral and protective earth Note In a system with a combination of FCU-1 and FCU-3 cabinets, all equipment cabinets must have a three-phase power supply. This means that all FCU-1 cabinets must have a separate junction box for the phases.
Page 31: Table 6: Recommended Multiwire Cables
Typical resistance at 55 °C Power supply tolerance [%] Maximum cable length Maximum cable length [mm] [Ohm/m] 48 V DC [km] 24 V DC [km] 0.65 0.04 J-Bus cables (option) UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 32: Design And Cast Concrete Foundations
The illustrations show typical dimensions. Adjust the dimensions of the concrete foundation to the actual soil conditions Jet blast To limit the effects of jet blast, make sure the equipment cabinets face the largest vertical surface parallel to the approach axis. Copyright ADB Safegate, All Rights Reserved ©...
Page 34: Cast Concrete Foundations
4. Use the MOV over-voltage protection (option) in all areas where lightning occurs frequently. 5. ADB strongly recommends to install one earthing rod with each equipment cabinet to achieve a local direct overvoltage drain to the ground. Copyright ADB Safegate, All Rights Reserved ©...
Page 35: Install Cables On Site
2. Provide sufficient mechanical protection for the actual conditions on site. 3. Provide adequate earthing of the cable screening/armoring. 4. Allow for one meter cable slack above ground for all cables. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 37: Installation
PC with serial port connection: • Dongle with connection cables and Flasher Configuration Software.Installation 6.4 Install 6.4.1 Install equipment cabinets Identify 1. Identify the equipment cabinet with the serial number. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 38: Install Local Master Controller (Lmc)
Deviate the cable to the junction box (B) or use an underground T-junction. • Install a two-core and an earthing cable between the junction box and the FCU-1 cabinet. 5. Through the bottom, put the cables in the FCU-1 cabinet.
Page 39: Install External Temperature Probe
5. Install the LMC PCB on the inside of the door (B). 6. Install the screws (A). Connect and finish (FCU-1 and FCU-3) 7. Connect the earthing wire between the fixation point (A) and the earthing of the cabinet. .
Page 40 Installation Install 1. Make a hole: • in the cabinet bottom or in the gland plate (FCU-1 only); • or in the cabinet base (FCU-3 only) See the illustration ; • or in the cabinet top below the sunshield (FCU-1 or FCU-3);...
Page 41: Install Electrical Connections
6.5.1 Switch OFF power supply 1. Switch OFF the main power supply at the substation. 2. Open the fused input switches (A). • FCU-1: fuse holders F1 and F2; • FCU-3: fuse holders F1, F2 and F3; 6.5.2 Connect power input supply FCU-1 cabinet with one-phase cable 1.
Page 42: Connect Power Output To Flash Units
2. Connect the wires to connector TB2 of the FCU PCB (A) with the flasher head (B). For the connection schema, see § Connectors 3. Attach the cables to the strain relief rail. Use an strain relief clamp. Copyright ADB Safegate, All Rights Reserved ©...
Page 43: Connect Lmc
2. Connect the local bus to connector P2 of the LMC PCB. 3. Connect the door switch detection to connector P7 of the LMC PCB. • FCU-1: black wire with label 39 • FCU-3: black wire. 4. Connect the connector for the MOV to connector P6 of the LMC PCB.
Page 44: Install Remote Control Connections
1. Attach the cable to the earthing bar (A). Use the strain release clamp (B) provided with the equipment. 2. Use one strain release clamp per cable. 3. Make sure that the cable screen is tightened with the strain release clamp. 4. Remove the cable shield above the strain release clamp. Copyright ADB Safegate, All Rights Reserved ©...
Page 45 Multiwire - PCB1486 . To connect the individual wires to the WAGO connectors, use WAGO tool. 7. Make sure the multiwire is earthed. Connect J-Bus cables (if present or purchased) UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 46 2. Make sure the J-Bus cable is earthed in the tower only, not in the equipment cabinet. Remove multwire cable, if installed. 3. Disconnect the flat multiwire cable (A) from the connector P5 of the LMV PCB and P3 of the multiwire PCB. Copyright ADB Safegate, All Rights Reserved ©...
Page 47: Pcb Drawings And Settings
LMC. If the number of flashes exceeds the lifetime of the flasher head, an error is also sent back. 7.1.1 Layout of the Printed Circuit Board (PCB) The board has a fuse (A) of 2AT or 2AF, 5 x 20 with 1.5 A breaking capability. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 48: Connectors
Connection number on the Connector name on the Connector name on TB2 Wire color flasher head flasher head Trigger: Lamp cathode TRIG Brown +400V: Lamp anode +400V Blue Yellow/Green Cab+ Cab+ Black Cab- Cab- Black Copyright ADB Safegate, All Rights Reserved ©...
Page 49: Straps
To set the resistors, set the straps as follows: Table 13: FCU straps Strap Bus use Resistor 680 Ohm Terminating resistor 150 Ohm Pull up Pull down Local bus UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 50: Dip-Switchest
Baud rate local bus 9600 baud Baud rate local bus 19200 baud Baud rate local bus 38400 baud Factory settings Invalid No parity Valid (no parity) Local bus Odd parity. Local bus Even parity Factory settings Copyright ADB Safegate, All Rights Reserved ©...
Page 51: Leds
To distribute the internal distribution of the bus signal. The internal distribution is fixed on delivery. P1 and P3 To connect the local bus to the other cabinets in the system. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 52: Local Master Controller (Lmc) - Pcb1513
Flashing System Installation PCB drawings and settings 7.3 Local Master Controller (LMC) - PCB1513 7.3.1 Layout of the Printed Circuit Board (PCB) Copyright ADB Safegate, All Rights Reserved ©...
Page 53: Straps
7.3.3 Rotary and dip-switches If not specifically noted, all the switches are read only at power-up. If you change a switch setting, restart the equipment before the changed comes into effect. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 54: Table 19: Lmc Pcb Dip-Switch Settings
16 ms interval time 33 ms interval time 66 ms interval time Invalid Declaration of REILS 1 cycle per s 2 cycles per s Rotary Flashing system OFF Step 1 Step 2 Step 3 Remote control Copyright ADB Safegate, All Rights Reserved ©...
Page 55: Leds
Function Status Notes Isolated supply Bus A Isolated supply Bus B Isolated supply local bus. Reserved For future use RUN. One flash per s Higher rate during software upload. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 56: Multiwire - Pcb1486
Rx Bus B the bus. DS11 Rx Bus A 7.4 Multiwire - PCB1486 Note It is impossible to attribute the same function to more than one terminal. 7.4.1 Layout of the Printed Circuit Board (PCB) Copyright ADB Safegate, All Rights Reserved ©...
Page 57: Straps
2 and 3 can also be selected. Bit 0 Bit 1 0FF OFF Use mode 1 ON OFF Use mode 2 OFF ON Use mode 3 ON ON Use mode 4 UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 58: Output Terminals
Misfire limit reached Latched ON/OFF ON/OFF This terminal is activated if the number of misfires exceeds the limit on at least one equipment. To clear the condition, activate the reset misfire function. Copyright ADB Safegate, All Rights Reserved ©...
Page 59: Table 25: Functions For Connector P1
Contact is closed when the flasher system received RUNNING a valid step + mode command. REILS RUNNING ON/OFF ON/OFF You can switch the REILS ON or OFF onto custom contact 1 or 2 UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 60: Control Signals
AC - 110 V -0.5 A - 60 VA; • DC - 110 V -0.5 A - 30 W. 7.4.7 Multiwire default settings This section shows the default multiwire settings. These settings apply to LMC software version 1.21. Back-indication signals Copyright ADB Safegate, All Rights Reserved ©...
Page 61: J-Bus Connection - Pcb1502
The J-Bus interface uses a single or dual databus(es) to allow remote monitoring of a bigger quantity of parameters. An equipment is always a slave on the J-Bus. There can be a maximum of 31 equipments on one bus section with one common bus master. UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 62: Layout Of The Printed Circuit Board (Pcb)
Flashing System Installation PCB drawings and settings 7.5.1 Layout of the Printed Circuit Board (PCB) The PCB provides the interconnection of the user J-Bus(ses) with the LMC. The PCB has gas arresters for overvoltage protection. Copyright ADB Safegate, All Rights Reserved ©...
Page 63: Connectors
Meant for the connection of Bus A from the previous user on the system. Meant for Bus B. Table 31: Wiring for connectors P1-P4 Wire Description Tx + Rx + Tx - UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 64: Slave Connections
10101010 if this is not the case. In the configuration menu of the software, choose the used COM port on the PC, ‘38400’ bd & ‘EVEN’ parity. This will allow proper communication between FCU/ LMC and the dongle. Copyright ADB Safegate, All Rights Reserved ©...
Page 65: Leds
OFF, there is no or reception. traffic on the corresponding bus. RxD from flasher system these LEDs permanently ON, there may be polarity inversion on the bus 7.7 Wiring diagrams FCU-1 UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 67: Technical Data
Temperature From -20 up to 55 °C Altitude From 0 (sea level) up to 1000 meters Relative humidity From 10 % RH up to 95 % RH without dewing UM-4018_AM02-620e, Rev. 3.0, 2020/05/12 Copyright ADB Safegate, All Rights Reserved ©...
Page 69: Support
A.2.1 Local Authority Recycling The disposal of ADB SAFEGATE products is to be made at an applicable collection point for the recycling of electrical and electronic equipment. The correct disposal of equipment prevents any potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling.
Page 70: Adb Safegate Recycling
Main Unit Serial Number. ADB SAFEGATE will continue to monitor and update according for any future requirements for EU directives as and when EU member states implement new regulations and or amendments. It is our aim to maintain our compliance plan and assist our customers.
