Summary of Contents for Linnea SDB-110BT

Page 1 Installers & User guide Smart Deadbolt...
Page 2 Due to app updates, there may be changes to this manual. Please contact Linnea for help at help@linnea-home.com.
Page 3: Table Of Contents
Table of Contents In The Box Speciﬁcations Requirements Lock Anatomy Preparing Door for Installation Prepare Lock for Installation Installation Instructions Test Lock Preparing the Door Frame Pairing Features Unlocking Locking Lock Tutorial Lock Behavior Troubleshoot...
Page 4: In The Box
In The Box Battery Case Lid Rubber Gasket Back Assembly Front Assembly Back Plate Strike Plate Housing & Bolt Assembly Screw Holder Strike Plate 25mm Batteries x 4 Bolt Screw x 2 Wood Screw x 4 40mm 22mm 80mm Keys x 2 Bolt Screw x 3 Bolt Screw Tailpiece...
Page 5: Specifications
Speciﬁcations Model Linnea SDB-110BT Material Zinc Alloy Current Rating (Standby) ≤ 30uA Current Rating (Active) ≤ 200mA Batteries 4 x AA Alkaline (Non-Rechargeable) Unlock Mechanism Bluetooth, Passcode, Keys Front Side Back 60mm 30mm 45mm 60mm...
Page 6: Requirements
Requirements Door Thickness & Gate Clearance Height & Width 35mm 38mm - 50mm >110mm (60mm bolt tongue) >120mm (70mm bolt tongue)
Page 7: Lock Anatomy
Lock Anatomy Outer Body Inner Body Battery Cover Release Touch Screen Keypad Battery Cover Keyhole Cover (Release pins to access physical key unlock) Thumbturn 9V Jumpstart...
Page 8: Preparing Door For Installation
* Please ensure that there is an existing handle on your door for push - pull access. * Not for: metal gates, glass doors or sliding doors. If you are unsure if your door is suitable, contact us at: support@linnea-home.com...
Page 9 How to use the Drill Sheet Drilling (Door) Fold here Make sure this before drilling is aligned to the holes for side centre of door edge Door edge Chiseling Put the bolt tongue in & Depth Width: chisel around the edge 2 - 3mm or until bolt assembly...
Page 10: Prepare Lock For Installation
Prepare Lock For Installation Set Back Assembly for Left / Right Installation Right Installation Left Installation Set the toggle to ‘R’ for Set the toggle to ‘L’ for right-side installation. left-side installation. Remove Battery Cover Change Tailpiece (Optional) For door thickness > 50mm, change the default (60mm) tailpiece attached to the 80mm tailpiece.
Page 11: Installation Instructions
Installation Instructions Measure If you are replacing your current deadbolt lock, industry standards are 60mm or 70mm backset. To determine which basket length you should use, so measure the distance (x) between the center of 54mm hole to door edge. 54mm Hole Prepare bolt assembly based on the distance (x) Bolt ships with bolt assembly in 60mm position.
Page 12 Insert Bolt and Front Assembly into door edge The ‘+ ‘ hole on the backset should be in the middle of the hole. Screw Holder Right Installation Left Installation Screws 25mm Secure the Front Assembly using the Back Plate To do this, place the Back Plate (ensuring the correct side placement). Follow this orientation...
Page 13 Screw it to the Front Assembly using the three 40mm screws. The cable should come out from the side Screws 40mm Connect Wire Connector Connect the Wire Connector from the Front Assembly though the 54mm hole to the Back Assembly. Ensure that the wire is installed properly and securely.
Page 14 Fit Back Assembly to the Door Tailpiece Ensure thumbturn position is turned to ‘unlock’ position. Left Installation Right Installation...
Page 15 Secure the Back Assembly Screws 05mm 22mm Insert 4 of AA Batteries Before closing the battery case lid.
Page 16: Test Lock
Tailpiece and/or thumbturn Left-Right toggle incorrectly set incorrectly set Troubleshoot: Try Setting the Troubleshoot: Dissemble left-right toggle on your back lock and install it again. assembly to the correct side. (See Pg. 10) Still experiencing issues? Contact Linnea Support for more help.
Page 17: Preparing The Door Frame
Preparing the Door Frame Mark out where the bolt tongue locks then Ensure to align the lock to the door frame drill a corresponding hole on door frame. and mark it down. Chisel to ﬁt the strike plate in as well. Door Frame Mark &...
Page 18: Pairing
Pairing CHECKLIST Download TTLock app from App Store/Google Play Lock has not been paired Register a new The keypad stays awake during pairing account or, Turn on your phone’s Bluetooth Login with an existing and Internet connection account on app Setup 1.
Page 19: Features
Lock / Unlock Timer Re-lock After successfully unlocking, the Linnea Smart Deadbolt will re-lock after a period of time (between 5 to 120 seconds). The owner sets this function. Manual Locking Hold the ‘#’ key for 2 seconds to lock the Linnea Smart Deadbolt.
Page 20: Unlocking
Unlocking To unlock the door TTLock App Bluetooth Basic Unlock Passcode / Decoy Passcode Home Main Door Thumbturn Physical Key Basic Issue access Logs Legend Passcode Bluetooth Guest Key Key in your passcode and press ‘#’ Refer to lock tutorial Physical Key Decoy Passcode Use the physical key to unlock the door...
Page 21: Locking
Locking To lock the door Timer Re-Lock ‘#’ Key Thumbturn Physical Key Legend ‘#’ Key Physical Key Press and hold ‘#’ Use the physical key to lock the door Timer Re-Lock Thumbturn Refer to Lock Tutorial - Step 7 Use thumbturn at the back of lock...
Page 22: Lock Tutorial
Lock Tutorial - on Deadbolt Keypad - on TTLock App Default factory Passcode In the factory mode (before pairing), the Passcode to unlock is * 1234567890 # Setting Master Passcode Before proceeding, turn on your Bluetooth and ensure that you are within Bluetooth range of the lock.
Page 23 Lock Tutorial - on Deadbolt Keypad - on TTLock App Deleting Passcodes To delete one at a time, go to Lock Management > Passcodes > Long press on passcode > Delete To delete all passcodes at once, go to Lock Management > Passcodes > Options (upper right corner) >...
Page 24 Lock Tutorial - on Deadbolt Keypad - on TTLock App Enabling & Disabling Timer Re-Lock* To Enable * 2 1 # <Master Passcode> # <Duration between 5-120 seconds> # To Disable * 2 0 # <Master Passcode> # Lock Management > Setting > Auto Lock > Check the box next to To Enable Auto Lock >...
Page 25 Bluetooth sharing allows you to share a Bluetooth Key with other users for mobile access. It allows your guests to unlock the Linnea smart lock via Bluetooth. To create a Bluetooth Key, go to Lock Management > Send eKey >...
Page 26: Lock Behavior
Lock Behavior Sensor Re-lock Security Lockout Mode Privacy Lockout Mode Press the Privacy Lockout button 5 consecutive invalid passcodes Activated by located below the thumb turn on the back of the lock till you hear a long beep Wait for 5 Minutes Press Privacy Lockout Button Bluetooth Unlock Disable By...
Page 27: Troubleshoot
Troubleshoot Lock is not working when Pairing is unsuccessful battery level is not 100% • Try with a different mobile device, using the • Do a Bluetooth Key unlock to refresh the same username and password battery level on the app •...
Page 28 For questions, contact us at: 1 (800) 219-2366 help@linnea-home.com...
