Summary of Contents for bestelectric slimline curve
- Page 1 Installation and User Manual SC0006104V00...
-
Page 2: Important Safety Notes
Installation manual and instructions for use. A. PRESENTATION Firstly we would like to thank you for purchasing this product. Your business is much appreciated and we trust that this equipment will provide many years of use and deliver full satisfaction. Before proceeding to the installation, you should read all the instructions and recommendations detailed in this instruction manual, since the manufacturer will not be responsible for any breakdown or damage caused by misuse. - Page 3 Installation manual and instructions for use. Cleaning and maintenance to be performed by the user, should not be per- formed by children without supervision. Caution: some parts of this product can get hot and potentially may cause burns. Particular attention must be paid when children and vul- nerable people are present.
-
Page 4: Installation
Installation manual and instructions for use. Likewise, a differential protection against ground faults is advisable. The voltage and frequency values of the electricity network must be the same as those indicated on the nameplate. It is possible that the radiator may produce slight noises at the beginning of its operation which is normal due to the expansion and contraction of alu- minium. -
Page 5: Wiring Diagram
Installation manual and instructions for use. WIRING DIAGRAM Brown or Black Display Power plate Blue L: Phase N: Neutral Blue R1: Electronics neutral output R2: Electronics phase output I: Switch Ts: Safety thermostat R: Resistance Brown WALL FIXATION The supplier will provide an installation kit inside the packaging consisting of the following elements: 2x WALL BRACKET 2x SCREW PLUG 2x NUT... - Page 6 Installation manual and instructions for use. Follow the steps illustrated below to hang and install your radiator: 1. Remove the radiator from its packaging and choose where to hang it. 2. Note that the minimum distances required around the radiator. 3.
-
Page 7: Warranty
Installation manual and instructions for use. WARRANTY The company offers an electrical guarantee for the period of 2 years. In order for this guarantee to be valid, you must present the original of the invoice, delivery note or purchase receipt. Previous requirements: •... -
Page 8: Setting Time And Day
Installation manual and instructions for use. F. USE OF RADIATOR Setting the radiator in programming mode, will allow you to assign temperatures at different times of the day, for each day. Understanding the full programming potential of your radiator will help to reduce energy consumption. Display: Link Modes... -
Page 9: Setting Program
Installation manual and instructions for use. ADJUST PROGRAMMED TEMPERATURES: In “Auto” mode the temperature of each hour will change automatically following the programmed Schedule. The user must assign to each hour one of the following temperatures modes: ), used normally when the user is at home. •... -
Page 10: Keypad Locking
Installation manual and instructions for use. 3. Use the [+] key to increase the time value (or [-] to return to the previous time) and select the desired mode again with [OK]. Link Link 4. You must perform this procedure from 0:00 to 23:00 each day and 7 days (when you arrive at 23:00 on day one, when you press [+], it will automatically skip to 0:00 hours on day two and so on until day 7. -
Page 11: Error Messages
Installation manual and instructions for use. The advanced settings are: C1- Choose ºF or ºC (default ºC). • C2- Choose type of control (default PID). • C3- Temperature Compensation Offset (default 0ºC). • • C4- Firmware. C5- Open window detection (turning off for 30 minutes if a drop of 2.4 °C is detected in 4 minu- •... - Page 12 Unit 7, Marrtree Business Park, Grimbald Crag Close, Knaresborough HG5 8FA Phone: 01423 733000 Email: info@bestelectricradiators.co.uk...
