Summary of Contents for METVISA BIMG LQL.2 Series
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information....................3 General warnings ....................... 3 Technical Characteristics ..................4 Main Components ......................4 Technical Data ........................5 Installation......................5 Device Layout ....................... 5 ..Use of the Device ..................6 ..Utility ..........................6 Commands ................ -
Page 3: Safety Information
1. Safety Information 1.1 General Warnings • Cautions/precautions must be observed when installing, using, maintaining and discontinuing use of this device; • Before carrying out any operation (assembly, utilization (use), maintenance and reuse after prolonged use of the equipment), read the manual carefully; •... -
Page 4: Technical Characteristics
2. Technical Features 2.1 Main Components For the equipment described in this manual, safety in use, cleaning, maintenance and maximum hygiene are guaranteed by the design and special project for all parts, as well as by using stainless steel and other materials suitable for contact with food. The device was built with the following features: •... -
Page 5: Technical Data
2.2 Technical Data Power Nominal Measures Voltage Capacity Model weight Nominal Length.xHt.xWidth (mm) (kg) LQL2110M604 200x585x200 LQL2220M501 200x585x200 LQL2220M502 200x585x200 LQL2220M504 200x585x200 LQL2220M604 200x585x200 LQL4L110M604 200x705x200 LQL4L220M501 200x705x200 LQL4L220M502 200x705x200 LQL4L220M504 200x705x200 LQL4L220M604 200x705x200 Noise level (device with load): 65 dB. ATTENTION! Features like: model, serial number and voltage of the equipment are provided on the label (figure below). -
Page 6: Use Of The Device
To ensure correct operation and safety, the machine must be positioned in an airy environment and on a sufficiently wide, level, dry and stable support surface, away from heat sources and water taps, and at a medium height of 80 cm. Install your appliance by leaving a distance of at least 20 cm around it so that it has sufficient space for inspection, maintenance, cleaning and use. -
Page 7: Commands
4.2 Commands The appliance consists of the on-off button on the front of the cabinet. See descriptive of the following command: • On/Off Button - used to turn the device on and off. In position "1" turns on, in position "0" turns off. 4.3 Operating Procedures Before operating your device, make sure that the items that come into contact with the food (cup, lid and overcap) are perfectly clean. - Page 8 • Add the liquid according to your recipe, but always comply with the "MAX" level indicated on the cup. In possession of the pre-cut pieces of food (approximately 2 cm), place them in the cup; • Before plugging in your device, always lock the cover with the overcap on the cup; •...
-
Page 9: Cleaning And Maintenance
ATTENTION! This appliance is intended for household use and should not be used for any other purpose. Do not leave the appliance running for more than 3 uninterrupted minutes. If processing has not finished after that time, let it stand for 10 minutes before putting it back into operation. To avoid damaging the device, never turn it on with the glass empty. -
Page 10: Maintenance And Procedures In Case Of Malfunctions
To sanitize the cup, follow the instructions below: • With the cup attached to the coupling and cup holder, add warm water (500ml less than the maximum capacity of the cup or at least twice the height of the blade) and a little neutral detergent inside the cup. - Page 11 Whenever an item related to the safety of the device is removed (e.g. when performing maintenance), put it back in its proper place and confirm that it is performing its function correctly. When a breakdown or non-compliance is detected, refer your device to the nearest technical assistance. See technical assistance on our website: www.metvisa.com.br...
-
Page 12: Annexes
6. ANNEXES Electrical Schematic - Voltage 110 V NOTE: In the above Electrical Schematic, white wires are represented by pink. -
Page 13: Electrical Schematic - Voltage 220 V
Electrical Schematic - Voltage 220 V NOTE: In the above Electrical Schematic, white wires are represented by pink. -
Page 14: Exploded Design
Exploded Design... -
Page 15: List Of Replacement Parts
Replacement Parts Item Code Description Qty. BAS046 Gray Square Base GAB133 Welded case MTE220 Electric Motor 1/3 cv 60 Hz 110 V MTE221 Electric Motor 1/3 cv 60 Hz 220 V MTE026 Electric Motor 1/3 cv 50 Hz 220 V RBT002 Rivet SUC020... - Page 16 IMG-BRASIL Indústria de Máquinas para Gastronomia Ltda. CNPJ 11.193.347/0001-14 - CREA 131726-3 Rod. Antônio Heil - KM 23 Nº 5825 - Bairro: Limoeiro CEP 88352-502 - Brusque - SC - Brazil Phone/fax. +55 47 3251-5555 - Website: www.metvisa.com.br E-mail: sac@metvisa.com.br - vendas@metvisa.com.br...
