Grim Reaper XL Building Instructions by CRASHTESTHOBBY.COM
The Grim Reaper XL is one of the toughest FPV planes on the planet. It is designed to fly at a wide speed range with more room to
carry FPV equipment. We have used the same techniques to build the Grim Reaper XL as we use for our combat planes. It has an
amazing glide. It can carry more weight than the smaller planes. It is cut from solid EPP foam that doesn't crush. It has EPP elevons
that are strong. It has bidirectional reinforced Extreme Tape hinges and laminate to make it strong while protecting the battery and
radio. The plane is designed to use low cost motors, ESCs, servos and batteries. You need one of these!!!! It's time to fly without
worrying about breaking your plane.
Please watch the videos on how to build our flying wings. The videos show technique and will give you more information than can
be provided in written instructions alone. We recommend that you build and laminate the plane before you install the radio and
FPV gear. This makes the plane easier to build and easier to service and repair.
Specifications
a) Center of gravity is back 9" from nose of plane if using the 9" extension.
b) Flying wings will not fly well nose or tail heavy.
c)
Flying wings tend to build tail heavy so you will need to keep the batteries and radio far forward.
d) Front spars are back 1.5" (4 cm) from the leading edge of wing on both right/left/center and on the top/bottom of the wing.
e) Center spars are back 9" (23 cm) from nose of plane on both the top and bottom of the wing.
f)
Spars are tied together with wire joiners and reinforced Scotch Extreme Tape over the top to prevent separation.
g) Elevon throws 3/8" (1 cm) up/down. Use hole close to center of servo and hole at top of elevon horn for best leverage.
h) Target flying weight 50-80 oz (1500-2400 gm). Lighter always flies better.
i)
3530-1400 KV motor recommended with 9x6 propeller. (Some flyers are using the 3536-1800 KV with a 9x6 prop)
j)
Use a 40 amp ESC with the 3530-1400 KV motor and a 80+ amp ESC with 3536-1800 KV motor.
k) 4000-12,000 mAh 3S lipo batteries mounted flat in the wing to decrease drag.
l)
Standard sized servos recommended for any motor capable of over 20 amps.
m) Speed range 15-90 mph depending on finished weight with suggested motors and standard build.
Equipment needed
a) Low-temperature hot glue gun and low-temp rated glue
b) Thin CA glue
c)
(OPTIONAL ) Gorilla Glue (preferably white), or "Goop" brand glue
d) #8 x 3/4" screws to attach motor mount to Formica (2-56 bolts and nuts may also be used) 4 needed
e) Scotch Extreme Tape (2" bidirectional) available at office supply shipping departments and on Amazon.com
f)
Metal straight edge that won't melt or cut when used as a guide for the soldering iron or razor blade
g) Soldering iron with 5/16" wheel collar to set cutting depth
h) Pliers for cutting pushrod to length
i)
New razor blade to cut slit for shock cord
j)
Small Philips head screwdriver to push shock cord into slit
k) Electric drill and bits for attaching motor mount to Formica plate.
l)
Iron for applying laminate (hobby iron is preferable, but clothing iron may be used)
m) Velcro strips
