ENDURA II CABINET PLANS AND INSTRUCTIONS
Thank you for purchasing your Wall Bed from Wallbeds Northwest.
When purchasing a complete "Endura II DIY Kit,"
already done for you. However, you will need to drill a few holes and possibly cut
moulding on site (if your project comes with moulding), proper tools, and the ability to
assemble the unit. Please carefully read the instructions and pay special attention to the
safety guidelines
NOTE! PLEASE READ THROUGH THE DIRECTIONS BEFORE YOU PURCHASE ANY OF THE
FOLLOWING ITEMS. SOME ITEMS MAY NOT BE NEEDED.
LEVEL
LADDER
STUD FINDER
ELECTRIC DRILL
Various Bits - #2Square
#2 & #3 Phillips
**Note: Some Pre-drilling is necessary for
Confirmat Screws - 3/16 Bit.
If you have ordered a unit that has Crown &
Base Moulding it does not come pre-cut.
You will need to cut it to fit onsite and will
need a chop saw and nail gun or hammer
with finishing nails.
Wallbeds Northwest
17646 NE 65th St.
Redmond, WA 98052
Wallbeds Northwest
Tools Needed
TAPE MEASURE
NEEDLE NOSE PLIERS
NAIL GUN OR
FINISHING NAILS
HAMMER
HEX Wrenches
NOTE!
most of the manufacturing work is
CRESCENT WRENCH
SLOTTED SCREW DRIVER
PHILLIPS HEAD SCREWDRIVER
3/16" DRILL BIT
MITER SAW-FOR MOULDING
1-425-284-6692
www.wallbedsnw.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wallbeds Northwest ENDURA II CABINET
Summary of Contents for Wallbeds Northwest ENDURA II CABINET
- Page 1 Wallbeds Northwest ENDURA II CABINET PLANS AND INSTRUCTIONS Thank you for purchasing your Wall Bed from Wallbeds Northwest. When purchasing a complete "Endura II DIY Kit," most of the manufacturing work is already done for you. However, you will need to drill a few holes and possibly cut moulding on site (if your project comes with moulding), proper tools, and the ability to assemble the unit.
-
Page 2: Parts List
ENDURA II PARTS LIST NOTE; There are extra parts provided for some of the following. PARTS LIST 1 Right & 1 Left Endura II Mechanism 200 - #10 Nickel Screws -5/8" 8 Hex Head Machine Screws 10 Rafix Connector Bolt 10 Rafix Connector Right &... - Page 3 PAGE 3...
- Page 4 Assembled View of Endura II Wallbed Cabinet For Melamine and/or Thermofoil Projects only; Please note the addition of an Unfinished Plywood Top Stretcher . This is for extra strength when attaching the Wallbed Cabinet to the Wall through the Top Back Stretcher.
- Page 5 THE PLATFORM ASSEMBLY The platform is the part of the wall bed that holds the mattress and is pulled down from the wall. Start by assembling the platform section. The following example is for a full size bed. Assembly for twin and queen is the same with the exception being that the twin uses one door panel.
- Page 6 Attach “L” Brackets as shown using 5/8" Nickel wood screws. Use only 5/8" screws when assembling the head, side and foot rails. FOOT Use 5/8" Nickel wood screws to attach “L” brackets to the slats. 5/8" Nickel Wood Screw "Z" Bracket HEAD Square the “rail”...
- Page 7 Verticals as shown below. The Top Front Stretcher should not be mounted until the Platform assembly is installed. When using confirmat screws, a 3/16" pilot hole needs to be drilled through the verticals and into the horizontal parts. ENDURA II CABINET Confirmat screws should be Rafix Connectors should be used in these locations.
- Page 8 Installing the Cabinet to the Wall IMPORTANT! DO NOT MOUNT WALL BED INTO DRY WALL ONLY. IT MUST BE SECURELY FASTENED INTO ALL AVAILABLE STUDS. Position the cabinet against the wall where it is to be mounted. Make sure that it is square. Locate all the studs that are behind the cabinet.
- Page 9 INSTALLING PLATFORM TO CABINET Set the Platform Section upright in front of the Wallbed Cabinet.(Note:The Front Door Panels should not be attached at this point). Slide the Platform into the Cabinet evenly making sure to align the slots on the mechanism as shown.
- Page 10 You can only tighten the mechanism, not loosen it. Rear View - Adjustment Nut Thank you for purchasing your wallbed from Wallbeds Northwest If you have any questions, please contact us at Wallbeds Northwest Inc.
