STEP 1:
First Set of Pins
• Slide 1st set of pins on Thigh Assembly into the groove on
Calf Assembly.
STEP 2:
Second Set of Pins
• Hook end of Calf Assembly over the second set of pins
on Thigh Assembly.
ASSEMBLY INSTRUCTIONS
PARTS LIST
Thigh Assembly
• Remove Pull-pin from Thigh Assembly.
Groove on
Calf Assembly
KNEE FLEXION
Tibia Assembly
Pull-pin
STEP 3:
• Slide Thigh Assembly completely onto Calf Assembly.
• Replace Pull-pin.
Pull-pin
