Owner's Manual
1. Read the Owners Manual thoroughly before first use.
2. Charge the LiftPlus for six hours before using it for the first time. If the LiftPlus battery
completely discharges, recharging will take 72 hours. See page 5 for battery and
charging information.
3. The lead screw requires regular lubrication for proper working condition. See page 13
for maintenance schedule.
1-800-MAGLINE (624-5463)
LiftPlus
Important Startup Instructions
Serial #: _________________________________
Date of Purchase: ________________________
®
1
LiftPlus
www.magliner.com
®
Advertisement
Table of Contents
Related Manuals for Magliner LiftPlus
Summary of Contents for Magliner LiftPlus
- Page 1 1. Read the Owners Manual thoroughly before first use. 2. Charge the LiftPlus for six hours before using it for the first time. If the LiftPlus battery completely discharges, recharging will take 72 hours. See page 5 for battery and charging information.
-
Page 2: Table Of Contents
Replacement Parts ........................16 Warranty Magliner products have a one (1) year warranty unless otherwise specified from the date of purchase against defects in workmanship or material. Any part or component, except items covered by warranties of other manufacturers, returned to the factory or service center freight prepaid by the owner, found upon examination by Magline, Inc. -
Page 3: General Safety Instructions
1. Read the Owners Manual thoroughly before first use. 2. Charge the LiftPlus for six hours before using it for the first time. If the LiftPlus battery completely discharges, recharging will take 72 hours. See page 5 for battery and charging information. -
Page 4: Liftplus Unit
LiftPlus ® LiftPlus Unit Up/Down Switch Lift Screw Parking Brake Latch Brake Lever Electrical Interface Panel Quick On/Off Switch Change Latch Front Rollers Column Column Handle Storage Rollers Circuit Breaker Wheel and Casters Battery Tire Assembly Compartment Column Channels Folding Latch... -
Page 5: Charging The Battery
LiftPlus ® Battery The LiftPlus® must be charged for six hours before using it the first time. If the LiftPlus battery completely discharges, recharging will take 72 hours. When not in use, it is recommended to keep the LiftPlus plugged in to maintain a maximum charge. -
Page 6: Using The Liftplus
LiftPlus ® Using the LiftPlus NOTE: The LiftPlus must be unfolded and the folding latch locked before the quick change latch is lifted or lowered. Failure to do so can damage the unit. Loading the LiftPlus 1. Do not exceed the load capacity of 350 lbs. (120 lbs. on high-speed models). -
Page 7: Changing Attachments
Push through fully so that the pin does not back out on its own. 5. Reverse these steps to remove the attachment from the quick change latch. Moving with the LiftPlus 1. Always stay behind the unit when moving it. Use both hands on the handlebars. -
Page 8: Folding The Unit
LiftPlus ® Folding the Unit NOTE: Never walk away from the unit when the folding latch is in an unlocked position. Never store the unit with the power switch left “on.” If the lift actuation switch is accidentally pressed while the unit is folded, it can damage the unit. -
Page 9: Unfolding The Unit
LiftPlus ® Unfolding the Unit NOTE: A folded unit can be stood up on end for storage, but before you unfold it, you must lay it flat on the ground. Unfolding the Unit 1. Set and lock the brakes. 2. Grasp the folding latch handle and rotate it slightly forward to remove some tension on the red latch. -
Page 10: Using The Brakes
LiftPlus ® Brakes Brake Operation 1. To engage the brakes, squeeze the brake lever toward the handlebar. 2. To lock the brakes, squeeze the brake lever toward the handlebar and press the red parking brake latch forward with your thumb. - Page 11 LiftPlus ® Adjusting the Brake Calipers The brake calipers can be adjusted using a 3/16” hex screwdriver. The brake caliper screws are accessed between the wheel spokes on either side. 1. Adjust the brake cable mount to its highest position as described in the preceding section (Adjusting the Brake Cable Tension).
-
Page 12: Replacing The Battery
If the unit appears sluggish even after charging or if the battery does not hold its charge for very long, the battery may need to be replaced. Use only Magliner replacement parts. The battery has a warranty of six (6) months. -
Page 13: Maintenance
LiftPlus ® Maintenance Inspection Area Procedure/Normal Condition Frequency Keep clean and dry. Replace any cracked or missing Outside Surfaces Daily covers. Fasteners Daily Tighten any loose hardware. Battery Charging Daily Green charging light should turn on when charging. Rear Wheels Daily Inspect wheels and tires for wear and cracks. -
Page 14: Troubleshooting Guide
LiftPlus Lubrication Points ® Troubleshooting Guide Problem Solution(s) The lift does not respond, and does 1. Is the power switch turned on? not make any noise when the lift 2. Has the circuit breaker tripped? switch is activated. 3. Check the battery connections. -
Page 15: Operating Labels
WARNING Read the Operator’s Manual and all labels before use. Do not exceed rated weight capacity - 350 lbs standard speed or 120 lbs high speed 1-800-MAGLINE (624-5463) • www.magliner.com Over Weight ® LiftPlus U.S Patent No. 7,712,582 UP DOWN... -
Page 16: Replacement Parts
LiftPlus ® Part Accessories Number Work bench (includes platform, vice clamps, vice handle and back bar) 536020 Quick change adapter (for use with 536020 work bench only) 536026 Arbor - 24” long x 1.66” diameter 536039 Adjustable boom with chain/hook assembly (requires arbor... - Page 17 LiftPlus ® Part Parts Number Limit switch (used for upper and lower) 62067 Lock washer for circuit breaker 80799 Motor assembly - high speed (includes motor, mounting bracket, solenoid, 534101 brake, Pulley #1, Pulley #2-3 and timing belt) - 120 lbs. capacity...
- Page 18 LiftPlus ® 1-800-MAGLINE (624-5463) www.magliner.com...
- Page 19 LiftPlus ® 1-800-MAGLINE (624-5463) www.magliner.com...
- Page 20 LiftPlus ® MAGLINE INC. ® 1205 West Cedar Street Standish, Michigan 48658 1-800-MAGLINE (624-5463) Email: customerservice@magliner.com www.magliner.com Form # B9353 10/19 REV © Copyright 2016-2019, Magline, Inc. Patent: www.magliner.com/patents 1-800-MAGLINE (624-5463) www.magliner.com...
