1/2
RETUL MATCH GLOBAL
PART# 09118-1010
BOX NO.
NO.
1
2
3
1
4
5
6
7
FOLLOW MANUFACTURER INSTRUCTIONS BELOW TO ENSURE PROPER SETUP OF MATCH TOWER.
HAZARDOUS CONDITIONS MAY EXIST IF INSTRUCTIONS ARE NOT FOLLOWED.
DESCRIPTIONS
MAIN CHASSIS
BASE PLATE
VANTAGE SHELF
DIGITAL FOOT DEVICE SHELF
POWER CORD
WING BOLT M6X12
TRIPOD HEAD
7
3
6
4
PART NO.
SBC-13-2601
SBC-13-2602
SBC-13-2610
SBC-13-2609
HARDWARE
HARDWARE
HARDWARE
1
5
2
QTY.
1
1
1
1
1
4
1
