6
Tools Required: Drill Driver, PHILLIPS Bit PH2 and PH1
***For techinal support, please call 800. 374.7438 #2007 servicetech@sisergo.com***
4
5
3
1
2
M Wall
Components Required:
1.
Wall Bracket x 1
2.
Column x 1
3.
Plastic Cover x 1
4.
Top Bracket x 1
5.
Tabletop x 1
6.
Handle x 1
7.
Hardware Bag x1
Hardware:
B x 2 (Ø6 Bushing)
A x 4 (M8x20)
R015637
R011032
D x 4 (M6x25)
E x 6 (5x20mm)
RN-084
R011530
G x 5 (4x16mm)
H x 1 (Hex Key 4mm)
R011500
R011921
Page 1 of 3
C x 2 (M6x16)
RN-081
F x 3 (Ø7,9 Cable Clamp)
R010230
I x 1 (Hex Key 5mm)
R011905
Advertisement
Table of Contents
Summary of Contents for SIS Ergo M Wall
- Page 1 Page 1 of 3 M Wall Components Required: Wall Bracket x 1 Column x 1 Plastic Cover x 1 Top Bracket x 1 Tabletop x 1 Handle x 1 Hardware Bag x1 Hardware: B x 2 (Ø6 Bushing) C x 2 (M6x16)
- Page 2 Page 2 of 3 Assembly Steps: 1. Mount the wall bracket(1) to a wall using four suitable 3. Place column(2) on wall bracket(1), by aiming the two previous screws. mounted (M8x20) machine screws(A) after the rear holes in the wall bracket. 2.
- Page 3 Page 3 of 3 6. Attach tabletop(5) to top bracket(4) using six 7. Attach handle(6) to tabletop(5) in a suitable position and secure cable with cable clamps(F). Mount everything (5x20mm) chipboard screws(E). using five (4x16mm) chipboard screws(G) 8. Remove safety lock from column(2) and push plastic cover(3) downwards.
