Power Tools Service Manual
PRODUCT NAME
36 V Cordless Blower
RB 36DA
Model
CONTENTS
TROUBLESHOOTING GUIDE -------------------------------------------------------------------------------------------- 1
REPAIR GUIDE ---------------------------------------------------------------------------------------------------------------- 3
1. Precautions on disassembly and reassembly ----------------------------------------------------------- 3
Disassembly --------------------------------------------------------------------------------------------------- 3
Reassembly ---------------------------------------------------------------------------------------------------- 6
Connecting diagram ----------------------------------------------------------------------------------------- 8
Application of lubricant -------------------------------------------------------------------------------------- 8
Tightening torque --------------------------------------------------------------------------------------------- 8
Checking after reassembly --------------------------------------------------------------------------------- 8
Load current --------------------------------------------------------------------------------------------------- 9
2. Precautions in disassembly and reassembly of the charger ----------------------------------------- 9
3. How to check and replace the power supply unit ------------------------------------------------------- 9
STANDARD REPAIR TIME (UNIT) SCHEDULES ------------------------------------------------------------------- 11
CONFIDENTIAL
Overseas Sales Management Dept.
Jun. 2018
Page
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RB 36DA and is the answer not in the manual?

Questions and answers

Summary of Contents for Koki Holdings RB 36DA

  • Page 1: Table Of Contents

    Power Tools Service Manual CONFIDENTIAL Jun. 2018 PRODUCT NAME 36 V Cordless Blower RB 36DA Model CONTENTS Page TROUBLESHOOTING GUIDE -------------------------------------------------------------------------------------------- 1 REPAIR GUIDE ---------------------------------------------------------------------------------------------------------------- 3 1. Precautions on disassembly and reassembly ----------------------------------------------------------- 3 Disassembly --------------------------------------------------------------------------------------------------- 3 Reassembly ---------------------------------------------------------------------------------------------------- 6...
  • Page 2: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Ensure that the battery is fully charged before checking problems in the following chart. Problem Cause Check Recovery (1) Motor does • Wires are not conducting electricity. • Check status of all wires. • Repair any defects. not rotate. •...
  • Page 3 Problem Cause Check Recovery (2) Cannot • Malfunction with the controller ass’y. • Visually check status of the circuit board surface for any signs of • Replace the wiring ass’y. increase or swelling, scorching, dust, water, or damage caused by impact. vary •...
  • Page 4: Repair Guide

    1. Precautions on disassembly and reassembly [Bold] numbers in the description below correspond to the item numbers in the parts list and exploded assembly diagram for the Model RB 36DA. Disassembly 1. Removing housing (A).(B) set (1) Remove three Tapping Screws (W/Flange) D5 x 20 [2] from the Nose Grill [27].
  • Page 5 3. Disassembling the power supply unit Refer to “How to check and replace the power supply unit” on page 9 for details. (1) Remove five Tapping Screws (W/Flange) D4 x 20 [15] and motor housing (B). Then remove the power supply unit.
  • Page 6 4. Removing the rotor ass’y from the stator FET PCB Because the Rotor Ass’y [19] has a strong magnetic force, securely hold the stator of the stator FET PCB and pull out the Rotor Ass’y [19] towards the direction “D” as shown below. Fig.
  • Page 7: Reassembly

    Reassembly Conduct reassembly by reversing the disassembly procedure, but note the following. 1. Reassembling the power supply unit Refer to “How to check and replace the power supply unit” on page 9 for details. (1) Ensure all wire connections are made in accordance with Fig. 4 “Reassembling the power supply unit” on page 7 when replacing the Wiring Ass’y [16].
  • Page 8 Fig. 4 • Reassembling the power supply unit [10] Switch panel Switch Connector cable (CN4) Internal wire (white) Connector cable (SW) Connector Connector cable (CN3) [12] Connector cable (controller) Connector cable (FET) Controller ass’y Connector [11] Internal wire (red) Internal wire (black) Stator FET PCB [17] Internal wire (red)
  • Page 9: Connecting Diagram

    Connecting diagram Fig. 5 • Connecting diagram DC-speed control switch Connector cable (Switch) Connector [11] Connector cable (CN3) TACT switch Main PCB ass’y PCB ass’y Connector cable (CN4) Connector [11] Connector cable (Controller) Connector cable (FET) FET PCB Noise suppressor ass’y ass’y Application of lubricant...
  • Page 10: Load Current

    Load current Measure the load current values in the Mode 1 and in the turbo mode. Check that the measured values are within the following range: • Mode 1: 4.5±2 A • Turbo mode: 21±2 A NOTE: Perform measurement after operating the blower for several minutes using a fully charged battery.
  • Page 11 2. Checking the stator FET PCB (1) Peel off silicone coating from the Fig. 6 • Stator FET PCB soldered portion of the connector cable (FET) with tweezers or a screwdriver. FET 1 FET 4 (2) Check the resistance between the measuring points “a”...
  • Page 12: Standard Repair Time (Unit) Schedules

    STANDARD REPAIR TIME (UNIT) SCHEDULES Repair Model 60 min. time RB 36DA General Assembly Trigger Lever Housing Nose Grill (A).(B) Set Motor Housing Rotor Ass’y Wiring Ass’y Battery Terminal -11-...
  • Page 13 LIST NO. K865 CORDLESS BLOWER 2018 · 6 ·21 Model RB 36DA (E1)
  • Page 14 PARTS RB 36DA ITEM DESCRIPTION REMARKS CODE NO. USED 6698393 NOZZLE (A) 302089 TAPPING SCREW (W/FLANGE) D5 X 20 (BLACK) BRAND LABEL MV LABEL (B) 313687 TAPPING SCREW (W/FLANGE) D3 X 16 (BLACK) 949424 WASHER M5 (10 PCS.) 961400 HEX. HD. TAPPING SCREW D5 X 70...
