INSTALLATION &
CARE INSTRUCTIONS
MERK15 - HOSE REEL PRODUCT
Thank you for purchasing your AquaJet product.
GENERAL ADVICE
Please read and follow these instructions carefully as failure to do so may cause damage
and/or personal injury and will invalidate the warranty.
• Inspect the product for damage carefully before installation. No claims for damage can be accepted
after installation.
• It is recommended that the packaging materials are saved for future transportation of the tool in the
event of it requiring service or repair. If you decide not to keep them, they must be disposed of in an
appropriate refuse collection container. These materials must not be left within the reach of children
as they are potential sources of danger.
• There are no user serviceable parts. All maintenance and repairs which require the case to be
opened or dismantled should be carried out by Mechline.
• This reel is not supplied with a connection hose or any fixings (screws, wall plugs or "S" hooks.
Please make sure you use suitable fittings when installing. A flexible connection hose must be
used, failure to do so will void warranty.
• Recommended water pressure 3 - 17 Bar (250psi) and maximum water temperature 80ºC (176ºF).
• Leave this Manual with the operator after installation.
&
installation
care instructions
REVISION: 10/2018 | page 1 of 8
Advertisement
Table of Contents
Summary of Contents for MECHLINE Aquajet MERK15
- Page 1 • There are no user serviceable parts. All maintenance and repairs which require the case to be opened or dismantled should be carried out by Mechline. • This reel is not supplied with a connection hose or any fixings (screws, wall plugs or “S” hooks.
- Page 2 AquaJet Pre-Rinse Products CHAPTER 1. GENERAL SAFETY Mechline highly recommends that any operator familiarise themselves with the following safety points and other information contained in this manual before operating the reel. 1.1 It is important to become familiar with the 1.12 Maintain correct balance and footing.
- Page 3 AquaJet Pre-Rinse Products CHAPTER 2. INSTALLATION - using the standard PIVOT brackets If using the optional wall (or floor) fixed mount bracket (part No. MERK-BKT) proceed to CHAPTER 3. 2.1 Ensure the structure to which the hose reel is to be fixed is of sound construction and strong enough to carry the weight of the reel plus the working strain exerted on it when in use.
- Page 4 AquaJet Pre-Rinse Products CHAPTER 3. INSTALLATION - using the optional wall (or floor) FIXED bracket If using the standard wall pivot brackets go back to CHAPTER 2. 3.1 Ensure the structure to which the hose reel is to be fixed is of sound construction and strong enough to carry the weight of the reel plus the working strain exerted on it when in use.
- Page 5 AquaJet Pre-Rinse Products CHAPTER 4. INSTALLATION - of the ROSE head gun If using the fan blade gun proceed to CHAPTER 5, or for the heavy duty gun proceed to CHAPTER 6. 4.1 Fit the rose head gun as shown below using the 1/2” BSP female x male brass swivel fitting and the 1/2"...
- Page 6 AquaJet Pre-Rinse Products CHAPTER 6. INSTALLATION - of the HEAVY DUTY gun If using the rose head gun go back to CHAPTER 4, or for the fan blade gun go back to CHAPTER 5. 6.1 Fit the heavy duty gun as shown below using the 1/2" BSP female x male brass swivel fitting supplied.
- Page 7 AquaJet Pre-Rinse Products CHAPTER 8. RELOCATING MOUTHGUARD 8.1 For wall mounting at heights above 1.6m it is advisable to relocate the mouthguard to the lower position as follows. Note: The hose exit point should not be more than 2.4 metres above floor level. 8.2 Pull some of the hose out from the reel and lock it in position.
- Page 8 Dimensions shown in mm unless otherwise stated. Product accreditation may not apply to all products in the relevant range. Please contact Mechline to confirm. Unless otherwise stated, all products carry a warranty of twelve (12) months against manufacturing defect or workmanship on parts with no inclusion for labour or site attendance.
