- Page 1 SCISSORSAFE LIFELINE SYSTEM FOR WORK RESTRAINT COMBINED INSTRUCTIONS Release date : November 2019...
- Page 2 These User Instructions have been prepared to describe the correct use and Installation of the components needed to install a Temporary Work Restraint System into a concrete structure that has Scissorsafe Void Formers cast into the ceilings . Work Restraint allows operatives the access and...
- Page 3 Record cards are lost, please send a request to • Frequency and type of inspection relevant Scissorsafe Ltd. and a replacement will be made to each component available to you. • Action to be taken if a defective component is found.
- Page 4 SCS003 SCISSORSAFE ANCHORAGE TOOL Storage Cleaning Store this component in clean, dry conditions To clean components manufactured from Steel, use low free of dust , oil, or airborne particles, viscosity lubricant (WD40 or similar ), applied with a preferably in its original packaging.
- Page 5 COMPONENTS SCS002 SCS003 SCS073 /SCS074 TWO PART VOID FORMER SCISSORSAFE ANCHORAGE TOOL POST DRILLED ANCHOR SCS020 SCS013 SCS050 HORIZONTAL LIFELINE 20 mtr 25MM OVAL KARABINER 4 USERS 25KN RATED ANCHOR TO LIFELINE SLING SCS030 - 7 SCS015 SCS021 ADJUSTABLE WORK POSITIONING...
- Page 6 SCS003 SCISSORSAFE ANCHORAGE TOOL The Scissorsafe anchorage tool is a mechanical device that does not need to be drilled into the concrete, it is inserted into pre-formed voids cast into the concrete. Anchorage points – Scissorsafe anchor points These will have been cast into the...
- Page 7 SCS003 SCISSORSAFE ANCHORAGE TOOL Insert Scissorsafe anchor tool until fully engaged into the ceiling void Lock the Scissorsafe anchor tool into the ceiling using one of the 25mm oval karabiners ensuring that the karabiner gate is fully closed and tightened...
- Page 8 SCS003 SCISSORSAFE ANCHORAGE TOOL Only connect to the Scissorsafe Anchorage Tool using a 25mm Oval Karabiner. This has a locking effect on the Anchorage action. Do not try to force a larger diameter connector into the Anchor. A smaller diameter connector may allow the Anchor to exit the void.
- Page 9 Cleaning Storage To clean components manufactured from rope or Store this component in clean, dry conditions free Webbing, use warm water and mild detergent, of dust , oil, or airborne particles, preferably in its applied with a sponge or soft nylon brush. Ensure that original packaging.
-
Page 10: Anchorage Points
20 metres in length for Work Restraint. Anchorage Points Please refer to the Instruction manual section for Anchors. Scissorsafe Anchorage Points These will have been cast into the concrete ceilings in pairs. Remove the orange nailing disks from the... - Page 11 Attach the Anchor to Lifeline Sling (SCS050) to the Anchors with the 25mm Oval Connectors Repeat step 1 ( build a twin anchored sling ) at the lifeline termination point.
- Page 12 Before opening the Lifeline bag, attach the short end connector to the large connector on the Anchor to Lifeline Sling Ensure that any connecting components eg Karabiners or Rope Connectors are free of sharp edges or burrs that could cut into the lifelines webbing. Remove the lifeline from the bag and fully unfurl then connect to the Lifeline...
- Page 13 When the lifeline s connected at both ends, pull the slack webbing through the ratchet Tension the lifeline by pumping the ratchet handle Ensure that at least one and a half complete revolutions of the spreader bar have been made To prevent jamming, ensure that the spreader bar is not overloaded with webbing.
- Page 14 This is how the Lifeline will look when anchored and tensioned at the storage bag end. This is how the Lifeline will look when anchored and tensioned at the Webbing Termination end. There is a wear-indicator woven into this Lifeline. When this becomes evident, please remove the Lifeline from use.
- Page 15 SCS021 ENDURANCE SAFETY HARNESS Cleaning Storage To clean components manufactured from rope or Webbing, Store this component in clean, dry conditions free of use warm water and mild detergent, applied with a sponge or dust , oil, or airborne particles, preferably in its soft nylon brush.
- Page 16 SCS021 ENDURANCE SAFETY HARNESS Pre-Use Inspection It is recommended that the user carries out a suspension test in a safe place before using the harness for the first time, to ensure correct size, sufficient adjustment and acceptable comfort. Fitting instructions STEP 1 Take the harness by its shoulder straps, ensure there...
- Page 17 Retain loose ends with the webbing retaining slides. Ensure final fit is both secure and comfortable. If in any doubt please contact us info@scissorsafe.co.uk Ref D The ideal position of the Rear Dee Connector is between the shoulder blades as shown.
- Page 18 SCS030 - 7 ADJUSTABLE WORK POSITIONING LANYARD Cleaning Storage To clean components manufactured from rope or Store this component in clean, dry conditions free of Webbing, use warm water and mild detergent, applied dust , oil, or airborne particles, preferably in its original with a sponge or soft nylon brush.
-
Page 19: Product Code
SCS030 - 7 ADJUSTABLE WORK POSITIONING LANYARD SCISSORSAFE ADJUSTABLE WORK POSITIONING LANYARD The Adjustable Work Positioning Lanyard is the link ACCREDITED TO between the Anchorage Point and the users Harness. Certification: EN358 It is designed to be used as part of a Work Restraint or... - Page 20 The user retains tension between anchorage and If connecting this Adjustable Work Positioning Lanyard harness by adjusting the length of rope between directly to a Scissorsafe Anchorage device the himself and the anchorage point, relative to the connectors should be swapped between terminal...
- Page 21 If you are in doubt about the correct use of the components or instructions described in these User Instructions, please contact us by phone or email. We provide a series of training courses that are content specific to the equipment we manufacture and distribute, rescue and Inspection if Fall Safety equipment.
