EX-57VAC-100E-A
4K-HDR HDMI Extender over Single
Cat.X with HDBaseT, RS-232,
Bi-directional IR, Ethernet, PoC &
ARC
User Manual
The EX-57VAC-100E-A
Bi-directional IR, Ethernet, PoC & ARC
requirements, and has been certified for international use. However, like all electronic equipment,
the EX-57VAC-100E-A should be used with care. Please read and follow the safety instructions to
protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION................................................................................................................. 1
FEATURES ......................................................................................................................... 1
SPECIFICATIONS .............................................................................................................. 2
PACKAGE CONTENTS ...................................................................................................... 3
CONNECTION DIAGRAM .................................................................................................. 3
PANEL DESCRIPTIONS ..................................................................................................... 4
IR PASS-THROUGH ........................................................................................................... 6
HDMI PIN DEFINITION ....................................................................................................... 7
HARDWARE INSTALLATION ............................................................................................. 7
NOTICE .............................................................................................................................. 8
rev: 180328
WARRANTY ....................................................................................................................... 9
Made in Taiwan
Safety and Notice
4K-HDR HDMI Extender over Single Cat.X with HDBaseT, RS-232,
has been tested for conformance to safety regulations and
Transmitting unit ► EX-57VAC-100E-A-TX ............................................................. 4
Receiving unit ► EX-57VAC-100E-A-RX ................................................................ 5
