Summary of Contents for Spectrum Digital AppBox E54
- Page 1 AppBox E54 System User’s Guide Specializes in designing with Microchip products AppBox E54 System User’s Guide AppBox...
- Page 2 Notice ! Spectrum Digital, Inc (SDI) provides the enclosed product under the following conditions: The user/customer assumes all responsibility and liability for the proper use, storage, and safe handling of the product. Further, the user indemnifies SDI from all claims arising from the use, installation, storage, and handling of the product.
-
Page 3: Table Of Contents
AppBox E54 Features ........ -
Page 4: Introduction
1.0 Introduction This document describes the features of the AppBox E54. The AppBox E54 is designed to be used in an industrial environment with a CAN, RS485, USB, or Ethernet interface to provide flexible, modular I/O (AppIO) for specific applications. These AppIO Modules allow customized solutions to be integrated for a wide variety of applications that need to go into a CAN, RS485, USB, or Ethernet communications environment. -
Page 5: What's Included In The Appbox E54
NOTE: This product does not include any software or drivers. Development tools (Atmel-ICE and Software code generation suite) can be obtained from Microchip/Atmel at: https://www.microchip.com/development-tools/. 1.3 AppBox E54 Front Panel The features of the front panel on the AppBox E54 are shown in the figure below: Ethernet LED1 AppBox E54 Front Panel 1.4 AppBox E54 Accessories... -
Page 6: Appbox E54 Communication Expansion
Distribution Box (Part/SKU #: 703924-0001) and AppBox cable (Part/SKU #:703923-0001) are required. The Distribution Box expands the J2 connector to four (4) images of the AppBox E54 J2 connector. The AppBox cable bridges all signals on the AppBox E54 J2 connector to a connector on the Distribution Box. -
Page 7: Installation
2.1 Attaching Power to the AppBox E54 Power can be provided to the AppBox E54 by two different means; the AppBox power supply with cable (Part/SKU #: 703925-0001), or wiring the 2 position terminal block header (included with AppBox E54) that plugs into the E54 CPU Board’s power input connector. -
Page 8: Installation Of Appio Modules
+12 -24 VDC is present. Place the meter/scope probes on the 2 screws to measure. 11. Turn off the power source 12. Insert the terminal block header into the power input of the AppBox E54. 13. Turn on the power source. -
Page 9: Attachment Of The Distribution Box To The Appbox E54
15. Apply power to the AppBox E54 2.3 Attachment of Distribution Box to the AppBox E54 Listed below are the steps to attach the Distribution Box (Part/SKU #: 703924-0001) to the AppBox E54: 1. Remove ALL power to the AppBox E54 enclosure 2. -
Page 10: Installation Of Atmel-Ice
6. Plug the emulator end of the ribbon cable into the “SAM” Port on the emulator 7. Plug in the Atmel-ICE debug into connector J6 on the AppBox E54 CPU board. Visually inspect the connection to insure all the board pins are in the female cable connector. -
Page 11: Interfaces
3.0 Interfaces This section describes the interfaces on the AppBox E54 CPU Board. These interfaces include the connectors, jumpers, switches, LEDs, and test points. The location of each of these interfaces is shown in the figure below: EXT1 LED1 EXT2... - Page 12 The table below lists all the interfaces on the AppBox E54 CPU Board. AppBox E54 CPU BOARD INTERFACES INTERFACE NAME TYPE OF INTERFACE Connector for power input Connector for RS-485/CAN USB Connector Ethernet Connector SD Card Connector Connector for header 5x2...
-
Page 13: Connectors
3.1 Connectors The following section describes the connectors on the AppBox E54 CPU Board. INTERFACE NAME TYPE OF INTERFACE MATING CONNECTOR Amphenol Anytek Connector for power input, 2 Terminal Block Plug, 2 pos position TJ0231530000G TS02315A0000G Molex 10 Position Rectangular... -
Page 14: J2, Rs485/Can Connector
The following table shows the signals present on the J2 connector. J2, RS485 / CAN Connector Pin number Signal name RS485_A RS485_B DGND CAN_H CAN_L JP8, VDD_5V if installed DGND No Connect No Connect DGND AppBox E54 System User’s Guide AppBox... -
Page 15: J3, Usb Connector
RD- to Pin 3, U11 No connect CHS GND to Ground GRN_A to VDD_3V3 GRN_C to LED0/ANEN_SPEED YEL_C to PC15_ETH_LED YEL_A to VDD_3V3 SH1 to Ground SH2 to Ground MH1, No connect MH2, No connect AppBox E54 System User’s Guide AppBox... -
Page 16: J5, Sd Card Connector
3.1.6 J6, Cortex-M Debug Connector The following table show the signals present on the J6 connector. J6, Cortex-M Debug Connector Pin number Signal name VDD_3V3, +3.3 volts PA31_SWDIO DGND PA30_SWCLK DGND PB30_SWO No Connect No Connect DGND RESETn AppBox E54 System User’s Guide AppBox... -
Page 17: Appio Module Connectors
0.1 inch (2.54 mm) centers. Note: The user should be aware that several signals from the AppBox E54 CPU are shared and present on all 3 connectors. If the signals are used by one connector (AppIO Module) they should not be used on the other connectors. -
Page 18: Ext1, Appio Module 1 Connector
Master in slave out line of serial PD29_SPI_MISO peripheral interface, always implemented, bus type Clock for serial peripheral PD26_SPI_SCK interface, always implemented, bus type DGND Ground Ground VDD_3V3 Power for the AppIO Module Power for the AppIO Module AppBox E54 System User’s Guide AppBox... -
Page 19: Ext2, Appio Module 2 Connector
Master in slave out line of serial PC07_SPI_MISO peripheral interface, always implemented, bus type Clock for serial peripheral interface, PC05_SPI_SCK always implemented, bus type DGND Ground Ground VDD_3V3 Power for the AppIO Module Power for the AppIO Module AppBox E54 System User’s Guide AppBox... -
Page 20: Ext3, Appio Module 3 Connector
Pin 17, EXT2 implemented, bus type Clock for serial peripheral interface, PC05_SPI_SCK Pin 18. EXT2 always implemented, bus type DGND Ground Ground VDD_3V3 Power for the AppIO Module Power for the AppIO Module AppBox E54 System User’s Guide AppBox... -
Page 21: Jumpers
3.2 Jumpers This section describes the jumpers on the AppBox E54 CPU Board . All jumpers are located on the bottom side of the circuit board. All jumpers are surface mount jumpers. The figure below shows the location of each jumper. - Page 22 The table below describes the jumpers on the AppBox E54 CPU Board. FACTORY DEFAULT JUMPER NAME POSITION DESCRIPTION POSITION Installed = +5 V power to Pin 1, EXT1 Installed Installed = +5 V power to Pin 1, EXT2 Installed Installed = +5 V power to Pin 1, EXT3...
-
Page 23: Switches
3.3 Switches The table below describes the switches on the AppBox E54 CPU board. TYPE OF FACTORY DEFAULT SWITCH NAME FUNCTION SWITCH POSITION Pushbutton P31_SWITCH Open switch Connects RS485A to SW2, position 1, Rocker switch RS485B RS485 terminator on Disconnects RS485A from... -
Page 24: Leds
3.5 Test Points This section discusses the test points on the AppBox E54 CPU Board. All test points are on the top side of the circuit board. Their location is shown in the diagram in section 3.0.The table below describes the test points on the E54 CPU board. -
Page 25: Mechanical Information
5.0 Mechanical Information The following drawing provides the mechanical information for the AppBox E54. All dimensions are in inches. Note: Drawing is NOT to scale. Top View AppBox E54 Side View AppBox E54 6.0 Schematics The following pages include the schematics for the E54 APP Board inside the AppBox E54. - Page 28 100K 1% 100K 1% 10K 1% 100K 1% 10K 1% 10K 1% 4.7K 1% 4.7K 1% 10K 1% 10K 1% 100K 1% 100K 1% 100K 1% 100K 1%...
- Page 33 Spectrum Digital, Inc PO Box 1559 Sugar Land, TX. 77487-1559 Web site: www.spectrumdigital.com Sales: sales@spectrumdigital.com Support: support@spectrumdigital.com Copyright Spectrum Digital Inc, © 2020 519198-4001 AppBox E54 System User’s Guide AppBox...
