Summary of Contents for CRYPTOHIPPIE SLATE
- Page 3 3. Open your browser and go to this link: http://192.168.8.1 Choose your preferred language and set your master password. You will need this password in the future, so be sure to have it saved or memorized. 4. If you already connected the router to the Internet via an ethernet cable you can skip this step and proceed with step 6.
- Page 4 5. Choose your Wi-Fi network from the drop down menu, type in your password and click “Join” to connect. 6. Click on “Upgrade” from the left menu and update your firmware if there is an update available.
- Page 5 7. Click on “More Settings” in the left menu and then choose “Advanced”. A new tab will be opened in your browser. 8. The default user name is "root". In the password field type in the password you configured in step 3. Then click "Login".
- Page 6 9. In the upper menu click on “System” and then choose “Software”. 10. Click on the “Configuration” tab.
- Page 7 11. Scroll down to “Custom feeds”. Delete everything in that field and paste the whole line from below: src/gz webauth http://opaque.link/files/packages/ar71xx/webauth Then click “Submit”.
- Page 8 Scroll down to “Custom feeds”. Delete everything in that field and paste the 12. After that click on the "Actions" tab again. whole line from below: src/gz webauth http://opaque.link/files/packages/ar71xx/webauth And click “Submit”.
- Page 9 Scroll down to “Custom feeds”. Delete everything in that field and paste the 13. Click on “Update lists” and wait. whole line from below: src/gz webauth http://opaque.link/files/packages/ar71xx/webauth And click “Submit”. 14. In the field "Download and install package" enter: “chwebauth” (without quotes).
- Page 10 15. The image below is what you will see if the set up was done correctly. You can close this tab now. 16. Open a new tab in your browser and go to: https://secure.cryptohippie.com/files/gli.php Enter your Client ID and VPN Password. Then click on the "Fast" button to download the configuration file for the fast connection.
- Page 11 17. Go back to the GliNET Admin Panel tab. From the left menu click on “VPN” and choose “OpenVPN Client”. On that page choose “Add a New OpenVPN Configuration”. 18. Click on "Select a file or drag it here" and mport the file you downloaded in step 16.
- Page 12 19. Now that the VPN configuration is imported you can connect the router to the VPN by clicking “Connect”. It might take a while for the router to connect. 20. In the left menu, click on “More settings”, and choose “Custom DNS Server”.
- Page 13 21. Check your router and make sure that the switch marked in the image below is switched to the left side. 22. In the same menu you've been using, choose "Button Settings". Make sure that the button on the router is switched to the left side before doing this. From the drop down meny choose "OpenVPN Client Toggle (On/Off)".
- Page 14 23. In the left menu click on “Wireless”. Below the network information click on “Modify” and you will be able to change details about the network. We strongly suggest you change the the Wi-Fi Name (SSID), and especially Wi-Fi key since “goodlife”...
- Page 15 25. Scroll down and repeat the same from above for the second Wi-Fi connection. 26. Click on “Reboot”.
- Page 16 27. Click on “Yes”. 28. After reboot your VPN router is now ready to use. Please go to this link in your browser: https://auth.cryptohippie.net and log in with your Client ID and password. If you used LAN to configure the router you can stay connected to it, or if you want to use it with Wi-Fi disconnect your computer from LAN and connect to one of the Wi-Fi networks you configured in step 23.
- Page 17 The middle LED/light on the router's front indicates if the VPN is connected and trasmitting data. Furthermore you can always go to our website https://secure.cryptohippie.com to check if you are communicating through the VPN. The bottom of that website will say "VPN: Connected" if you are.
