Smart Vision Lsi Crossover XCHM3 Installation And Assembly Instructions

Led area luminaire

INSTALLATION AND ASSEMBLY INSTRUCTIONS

Crossover® XCHM3 LED Area Luminaire

SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION

Read these instructions completely and carefully, observing all CAUTIONS and

WARNINGS shown throughout these instructions.

· Disconnect or turn off power before installation or servicing.

· Verify that supply voltage is correct by comparing it with the luminaire label information.

· Make all electrical and grounded connections in accordance with the National Electrical Code (NEC) and any

applicable local code requirements.

· Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing or performing

maintenance.

· Allow lamp/luminaire/driver to cool before handling.

NOTICE: RISK OF PRODUCT DAMAGE- Failure to follow instructions could result in damage to product

and void ALL warranties!

· Only install fixture with lens facing downward.

· Never connect components under load.

· Do NOT mount or support these fixtures in a manner that can cut the outer jacket or damage wire insulation.

· Do NOT exceed fixtures maximum ambient temperature rating.

· It will occasionally be necessary to clean the outside of the lens. Frequency of cleaning will depend on

ambient dirt level and minimum light output which is acceptable to the user.

· Lens should be wiped with a DAMP cloth with a solution of warm water and a mild, non-abrasive household

detergent. Dry with soft, dry, clean cloth.

· Do NOT use chemical cleaners such as powder cleansers, bleach, etc.

· Do NOT use scouring pads, as this will scratch and damage the lens finish.

· Do NOT wipe with a soiled cloth or wet towel - these may leave a residue that can damage finish.

· Do NOT pressure wash or hose down luminaire.

LSI Industries Inc.

10000 Alliance Road

483933 Rev. 3/12

BEFORE YOU BEGIN

Cincinnati, Ohio 45242

(513) 793-3200

Fax (513) 793-0147

1 / 3

www.lsi-industries.com

Table of Contents

Do you have a question about the Lsi Crossover XCHM3 and is the answer not in the manual?

Page 1 INSTALLATION AND ASSEMBLY INSTRUCTIONS Crossover® XCHM3 LED Area Luminaire SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION BEFORE YOU BEGIN Read these instructions completely and carefully, observing all CAUTIONS and WARNINGS shown throughout these instructions. WARNING! RISK OF ELECTRIC SHOCK ·...
Page 2 Crossover® XCHM3 LED, cont'd. Listed for Wet Locations ALL UNITS: 1. Remove luminaire from packaging, taking care to protect lens and finish. Check packing slip to make sure all parts are present before proceeding. Check carton for supplied mounting hardware. 2.
Page 3 Crossover® XCHM3 LED, cont'd. ALL UNITS: 6. Position luminaire over all-thread. Feed supply wiring through center hole on back of luminaire. Use supplied hardware to secure luminaire to pole and/or arm bracket. To ensure level luminaire, tighten upper nut first, then lower nut, (tighten each to 25 ft-lbs.) making sure luminaire and/or arm is "square"...
