Burnaby TIKI TORCHES Installation & Maintenance Instructions

222 Woodland Drive, Vancouver, B.C. V5L 5C8 Ph: (604) 877-1599 Fax: (604) 875-6776

If you smell gas:

NOTE: The installation of these Tiki Torches must conform with local codes or in the absence of local codes,

with National Fuel Code ANSI 223.1

Do not store or use gasoline or other flammable vapors

and liquids in the vicinity of this or any other appliance.

_____________________________________________________________________________

Burner Screen:

Stainless Steel 3/32" RD x 5/32 cc

Perforated

Revised June 23/10

INSTALLATION & MAINTENANCE INSTRUCTIONS

TIKI TORCHES FOR PERMANENT MOUNT

FOR YOUR SAFETY

Shut off gas to the appliance

Open windows

Don't touch electrical switches

Extinguish any open flame.

Immediately call your gas supplier

FOR YOUR SAFETY

TIKI TORCH FOR PERMANENT MOUNT

(PROPANE)

Table of Contents

Do you have a question about the TIKI TORCHES and is the answer not in the manual?

Page 1 Don’t touch electrical switches Extinguish any open flame. Immediately call your gas supplier NOTE: The installation of these Tiki Torches must conform with local codes or in the absence of local codes, with National Fuel Code ANSI 223.1 FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 2 TIKI TORCH FOR PERMANENT MOUNT (NATURAL GAS) Burner Screen: Stainless Steel 3/32” RD x 5/32CC Perforated Each Tiki Torch Cone is individually packaged to prevent physical damage to the cone assembly. Any claims of damage must be made immediately upon receipt of goods. The Tiki Torch Cones are designed to be installed on rigid piping by qualified gas fitters and according to local codes.
Page 3 These instructions shall be left with the appliance for the consumer to retain for future reference. NOTE: To convert L.P. Tiki Torches to Natural Gas use, change orifice #54 to #48. Install 2 of the 3/16” machine plugs in the primary air intake openings, which will render all openings for primary air Closed..
Page 4 First Hex Nut Second Hex Nut Remove the 6/32 stainless steel screw and lift up the stainless steel burner screen. Inspect for blockage or corrosion. Clean or replace if required. Using #54 drill bit for LP and #48 drill bit for NG, clean the burner orifices, if required.
