Summary of Contents for Onyx ONX908STW-0
- Page 2 ONX908STW-0 FAN COIL THERMOSTAT Application: 24VAC，Heat/cool, Installation and operation instructions PECIFICATION: Electrical Rating…………………… 24VAC 3.0 A per terminal （G terminal 5A） Terminal Load……………………… Set point Temperature Range……….. 5℃ to 35℃ 115mm×90mm ×28mm Dimensions………………………… Color……………………………….. White EATURE: Large LCD display with backlight Set points and room temperature display simultaneously Maintains the temperature within the range of 0.5℃...
- Page 3 ① Power button ⑧ Setting temperature ② System switch (HEAT, COOL) ⑨ Indicate fan switch position ③ Fan switch (AUTO, ON) Heat on shows when the thermostat ⑩ ④ Sleep operation button is calling for heat ⑤ ▲ Raises Temperature setting Cool on shows when the thermostat ⑥...
- Page 4 CHECK THERMOSTAT OPERATION Switch on the thermostat system should stop operating. Fan operation Cooling system operation Set fan button to On or Auto Auto is the most commonly selected Press system switch to cool mode ( setting and runs the fan only when the heating Press “▼“...
- Page 5 CONFIGURATION The configuration menu allows you to set certain thermostat operating characteristics to your system or ④ personal requirements. Switch off the thermostat and hold the sleep operation Button for over 3 second till power on again means you have entered the first configuration menu item. There are 6 menu items. Press ④...
