Everglow Liberty Gas Torch Installation & Maintenance Manual

GAS TORCH INSTALLATION / MAINTENANCE
Torches are set for 7" Water Column pressure on natural gas and 11" W.C. pressure for LP

FOR YOUR SAFETY

If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, immediately
call your gas supplier.
THESE INSTRUCTIONS SHOULD BE LEFT WITH THE CONSUMER.
KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE.
F
D
C
A
California Proposition 65 Warning:
Chemicals known to the State of
California to cause cancer, and
birth defects or other reproductive
Liberty Gas Torch

SPECIAL NOTE

FOR YOUR SAFETY
Do not place combustible materi-
als near this appliance.
Do not store or use gasoline or
other flammable vapors and liq-
uids in the vicinity of this or any
other appliance.
Item
I
A
B
C
H
D
E
G
F
G
H
I
E
NOTE: Torches are made to be mounted on a standard
3" O.D. gas lamp post.
B
ALSO, IT IS VERY IMPORTANT TO USE THE PROPER
TORCH FOR NATURAL OR FOR L.P. GAS.
THERE IS A DIFFERENCE! MAKE SURE TO SPECIFY!
These torches are designed to perform admirably under a
variety of weather conditions, but strong wind gusts and/
or rain may extinguish the flame. If this occurs, simply
turn the gas OFF at the torch valve, let any remaining gas
dissipate and clear for a few minutes, and relight if condi-
tions improve.
The sheer nature of having a visible yellow flame will
result in some smoke or soot during operation, especially
on LP gas.
FOR YOUR SAFETY
The installation of this torch
must conform with all local
codes or, in the absence of local
codes, with the latest edition of
the National Fuel Gas Code
ANS Z21.42-1993.
Part. No.
GLV-LT Torch Valve (No orifice special thread)
N/A (2) S.S. Washers 3/8" x 1-1/2"
122-A 1/8" Pipe Nipple
119-BA 1/4" to 1/8" Reducer
113-B2 1/2 1/4" Pipe Nipple
120-BA Orifice Head (Specify Natural or LP)
N/A Flame Deflector
108A 1/8" Pipe Cap
N/A Lava Rock
Description
