Gale Force/Clean Force Air Mover Stand Mounting Instructions
CONTENTS NEEDED:
• Both metal side brackets (Picture 1)
• Both shoulder pins (Picture 2)
• Both nylon spacers (Picture 3)
1
• 8- 1
⁄
" screws (Picture 4)
4
Remove the screws in the nut certs and discard screws.
Screw the shoulder pins into the center of each bracket.
OWNERS MANUAL
Read instructions before use.
Save these instructions
1
3
Slide the shoulder pin into the notches on the stand. Aim
the air mover to desired position and insert both locking
pins through the holes to hold the air mover in position.
Picture 1
Picture 3
Line up nylon spacer with metal side bracket and using
longer screws attach to the air mover.
Picture 2
Picture 4
2
4
Advertisement
Table of Contents
Summary of Contents for Dry Air Gale Force Stand
- Page 1 OWNERS MANUAL Gale Force/Clean Force Air Mover Stand Mounting Instructions Read instructions before use. Save these instructions CONTENTS NEEDED: • Both metal side brackets (Picture 1) • Both shoulder pins (Picture 2) Picture 1 Picture 2 • Both nylon spacers (Picture 3) •...
- Page 2 OWNERS MANUAL Force 9 Air Mover Stand Mounting Instructions Read instructions before use. Save these instructions CONTENTS NEEDED: • Both metal side brackets (Picture 1) • Both shoulder pins (Picture 2) Picture 1 Picture 2 • 8- ⁄ ” screws (Picture 3) Picture 3 With circular part of the side brackets toward the center Screw both shoulder pins into the center of each bracket.
