Ljunggren Audio

Roll Your Own

Aperture

Version: Aperture PCB1: 1.0, PCB2: 1.0 & 1.1

The only difference between PCB2 1.0 & 1.1 is a short missing trace in 1.0 that is very easy to

fix and is included in the assembly instrucions.

Bills Of Material

Type

Qty Value

Pow er header

Socket strip

Pin strip

Potentiometer

Jack

Toggle sw itch

LED 3mm

Diode

3.5mm resistor

7mm resistor

MLCC X7R

MLCC C0G

Electrolytic

Film cap

Trimmer

Transistor

Voltage reference

IC socket

Sw itch IC

IC socket

OpAmp

IC socket

OpAmp

Vactrol socket

Vactrol

Pow er cable

Mounting screw s

Frontplate

PCB1

PCB2

spacers

nuts

screw s

Knob

Parts

1 2x5pin

POWER

2 1x8pin

CON1-PCB1, CON2-PCB1

2 1x8pin

CON1-PCB2, CON2-PCB2

1 B22K

POT1

2 B100K

POT2, POT3

1 A100K

POT4

4 3.5mm

J1, J2, J3, J4

1 SPDT on-of f-on

SW1

1 SPDT on-on

SW2

1 orange

4 1N4148

D4, D5, D6, D7

2 1N5818

D1, D2

1 680K

R16

4 68K

R4, R5, R22, R34

5 47K

R14, R19, R21, R24, R30

1 4.7M

R28

5 330K

R17, R18, R31, R43, R45

3 12K

R13, R15, R25

1 0R

R20

5 10K

R3, R27, R29, R40, R44

R7, R8, R9, R10, R11, R12, R32, R33,

10 100K

R37, R38

1 100R

R23

2 10R

R1, R2

3 1K

R6, R26, R39

C1, C2, C5, C6, C7, C8, C9, C10, C11,

14 100nF

C12, C13, C14, C15, C16

1 33nF

C21

1 68nF

C19

4 10uF

C3, C4, C17, C18

1 2.2uF

C25

1 220nF

C20

1 470nF

C24

3 50K

VR1, VR2, VR3

3 BC547

Q1, Q2, Q3

1 LM4040 5V

1 DIP16

IC1

1 DG412DJ

IC1

1 DIP14

IC2

1 LM324

IC2

3 DIP8

IC3, IC4, IC5

3 TL072

IC3, IC4, IC5

4 SIP2

LDR1, LDR2

2 NSL-32 SR3

LDR1, LDR2

1 16pin-10pin

2 M3x6 black

1 2mm black

2 11mm

2 f or spacers

3 small cream

1 big red

Description

Euro pow er connector

9mm vertical mount

PJ301M-12 / Thonkiconn / Inline

General purpose.

Schottky rectifier. Pow er polarity protection. Alternatives: 1N5817,

1N5819, SB130.

1% Tolerance

Zero ohm/Jumper

1% Tolerance

1/4W

2.5-2.54mm pin pitch

2.5-2.54mm pin pitch TDK recommended

2mm pin pitch, 5mm dia, max 10mm height. Min 25V.

2mm pin pitch, 4-5mm dia, max 10mm height. Min 16V.

5mm pin pitch WIMA MKS2 recommended

16 pin DIP

16 pin

14 pin DIP

14 pin Alternative: TL064 Alternatives w ith higher current

consumption: TL074, TL084

8 pin DIP

8 pin

2 pin SIP

Advanced Photonix/Silonex

PCB material
