DS2 Disinfectant Sprayer

Model: C46200-00DS

Minuteman International, Inc.

A Member of the Hako Group

988773 Rev A 04/20

Table of Contents

Need help?

Do you have a question about the Minuteman DS2 and is the answer not in the manual?

Questions and answers

Summary of Contents for HAKO Minuteman DS2

Page 1 DS2 Disinfectant Sprayer Model: C46200-00DS Minuteman International, Inc. A Member of the Hako Group 988773 Rev A 04/20...
Page 2 TECHNICAL SPECIFICATIONS Model: DS2 Disinfectant Sprayer Model No.: C46200-00DS Solution/Recovery Tank Capacity ..2.0 gallons (7.6 ltr) Voltage ..... . 115 volts Solution Pump.
Page 3: Table Of Contents
Table of Contents Inspection ..........................6 Electrical - Model C46200-00DS (115V) .................. 6 Grounding Instructions ......................6 User Maintenance Instructions ....................7 Daily Maintenance ........................7 Monthly/Bi-Monthly Maintenance ................... 7 Cord Storage ..........................7 Operating Instructions ......................8 Frame Assembly (450200DS) ....................10 Base Assembly (450230-DS) ....................
Page 4 Page 4...
Page 5 FOR COMMERCIAL USE ONLY IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING WARNING – To reduce the risk of ﬁ re, electric shock or injury: Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. WARNING To reduce the risk of electrical shock, do not expose to rain.
Page 6: Inspection
Inspection Carefully unpack and inspect your machine for shipping damage. Each unit is tested and thoroughly inspected before shipment, and any damage is the responsibility of the delivery carrier who should be notiﬁ ed immedi- ately. Electrical - Model C46200-00DS (115V) This machine is designed to operate on a standard 15 amp.
Page 7: User Maintenance Instructions
User Maintenance Instructions All service and repair should be performed by qualiﬁ ed vacuum service representative or electrician. Daily Maintenance 1. Solution tank should be emptied after each use. Flush pumping system with 1 gallon of clean water after use. 2.
Page 8: Operating Instructions
Operating Instructions 1. Lift the cover tank oﬀ of the of solution tank by releasing the two latches. 2. Add up to 1-1/2 gallons of disinfectant solution to the solution tank. Use only commercially available cleaning chemicals. 3. Place the cover tank back on solution tank and fasten the two latches. 4.
Page 9 Page 9...
Page 10: Frame Assembly (450200Ds)
Frame Assembly (450200DS) Page 10...
Page 11 Frame Assembly BOM (450200DS) Frame Parts List (450200DS) ITEM PART # DESCRIPTION 150004 STRAIN RELIEF, (PIGTAIL CORD GRIP) 450040 FTG-ELBOW 90 3/8 MPT X 3/8 HB NYLON 450222 FTG-ELBOW 90 3/8 MPT X 1/4 HB NYLON 450226 WHEEL-4" 450227 HOSE-WIRE REINF 3/8 X 12" 450303 HOSE-NYLO REINF 1/4 X 27 450304...
Page 12: Base Assembly (450230-Ds)
Base Assembly (450230-DS) Page 12...
Page 13 Base Assembly BOM (450230-DS) Base Parts List (450230-DS) ITEM PART # DESCRIPTION 450205 QUICK DISCNCT PLATE 16GA 450207 LATCH-SOFT 450221 COUPLER-QUICK CONNECT, 1/8MPT 450225 FTG-ADAPTER 1/8 FPT X 1/4 HB BRASS 450230-DS SOLUTION TANK ASM, DISINFECT SPRAY 710025 SCR-THMS 8-32 X 3/8 SS 711552 WASHER-INT LOCK #8 712540...
Page 14: Handle Assembly (450413)
Handle Assembly (450413) Page 14...
Page 15 Handle Assembly BOM (450413) Handle Parts List (450213) ITEM PART # DESCRIPTION 78-71-A GRIP-HANDLE BLACK 450402 WELD-HANDLE 450403 SPRING CLIP, HALF VINYL, 3/4" TO 1-1/8" 450404 SPACER, FOR .75 OD TUBE 450414 SCR-PHMS M6-1.00 X 35 ZP 712533 SCR-PHMS 10-24 X 1.25 SS 712904 NUT-ACORN 10-24 NICKEL 11175239...
Page 16: Wand Assembly (450250Ds)
Wand Assembly (450250DS) Page 16...
Page 17 Wand Assembly BOM (450250DS) Wand Parts List (450250DS) ITEM PART # DESCRIPTION 78-71-A GRIP-HANDLE BLACK 281041 VALVE-CHECK 390066 SOLUTION VALVE ASY COMP 450208 HOSE-1/8 ID NYLOBRAID RAW 450218 FTG-ADAPTER 1/4 FPT X 1/8 HB BRASS 450219 FITTING-NIPPLE QUICK CONNECT 1/8 MPT 450223 FTG-ADAPTER 1/8 FPT X 1/8 HB BRASS 450408...
Page 18 Page 18...
Page 19: Wiring
Wiring Page 19...
Page 20 “Excellence Meets Clean” Minuteman is a Full Line Manufacturer of Sweepers and Scrubbers, for Industrial Facilities. 14N845 U.S. Route 20, Pingree Grove, IL 60140 USA Phone (800) 323-9420 - www.minutemanintl.com A Member of the Hako Group 988773 Rev A 04/20...
