Instructions for Williams Gas Appliance
Conversion Kits 8901, 8902 & 8903

KIT CONTENTS:

(1)
Pressure Regulator
(4)
Pilot Orifices (L.P. Gas)
(1)
Burner Orifice (L.P. Gas)
Kit number 8901 & 8902 is for use with model numbers: 2509622; 3509622;
Kit number 8903 is for use with model numbers: 5009622
WARNING: This conversion kit shall be installed by a qualified service agency in accordance with
the manufacturer's instructions and all applicable codes and requirements of the authority having
jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or
production of carbon monoxide may result, causing property damage, personal injury or loss of life.
The qualified service agency is responsible for the proper installation of this kit. The installation is not
proper and complete until the operation of the converted appliance is checked as specified in the
manufacturer's instructions supplied with the kit.
WARNING: The Williams conversion kit numbers 8901 & 8902 can only be used on the model gas
NUMBERS 2509622; 3509622; 3509622.6; 3509922, gas valve 6003. The Williams conversion kit
8903 can only be used on the model 5009622, gas valve 6003. They must never be used on any
other brand of gas valve. DO NOT USE THE CONVERSION KIT ON ROBERTSHAW BRAND GAS
VALVES. If you are unable to determine that gas valve model number, do not convert your furnace.
MANUFACTURED FOR USE WITH PROANE GAS AND EQUIPPED WITH GAS VALVE PART
NUMBER 6003 ONLY.
CAUTION:
The gas supply shall be shutoff prior to disconnecting the electrical power (if equipped
with blower) before proceeding with the conversion.
CONVERSION INSTRUCTIONS-NATURAL GAS TO L.P. GAS
1. Shut off gas to the furnace.
2. Shutoff electric to the furnace (if equipped with blower).
3. Remove face panel from furnace.
4. Disconnect gas supply line from control valve.
5. Disconnect thermostat wires from control valve.
CAUTION: Label all wires prior to disconnection for proper reconnection
6. Remove manifold retaining plate from burner pan by unscrewing ( ) Phillips head screws.
Except model 35099(1, 2)2.
7. Remove burner pan from furnace by unscrewing ( ) Phillips head screws securing pan to
furnace. Except model 35099(1, 2)2.
8. Remove burners (item 2) by unscrewing ( ) Phillips head screws, screw on bracket (item 1)
and ( ) screw on burner (item 2). See figure 1
Note: Bracket (item 1) engages into slot on inner shield of furnace.
Natural Gas to Propane Gas
(2) Conversion Labels
(2) Screws
(1) L.P.G. Tag
3509622.6; 3509922
1
