Domotique embarquée Embedded home automation LIGHT AIR SWITCH Ref : 43.00009.10 User Manuel & Troubleshooting Guide Acknowledgement...........P.2 Safety Warnings............P.2 Equipment description...........P.2 Accessories / Associated references....P.2 Technical characteristics........P.3 Connectors..............P.4 Set-up................P.5 Wiring................P.5 Pairing................P.7 Configuration.............P.8 Troubleshooting guide...........P.11 Terms and conditions..........P.12 Warranty terms & after-sales......P.12 Domotique embarquée... -
Page 2: Acknowledgement
Acknowledgement We thank you for your purchase and hope that you are fully satisfied with this product. Domotique embarquée Embedded home automation Before you use this product, we recommend you read the instructions below carefully. This manual explains how to use and install the product in accordance with its intended use. Safety Warnings WARNING: Do not disassemble the device Any contact with the product's internal components can cause injury. - Page 3 Up to 32 2-button switches / 64 1-button switches BUS CAN type 6-way Micro-Fit BUS CAN type 6-way Micro-Fit CONNECTORS 2-way PicoMax outputs Scheiber v8.0 Multibloc Protocol 6-way PicoMax inputs and coding ANTENNA PCB antenna PCB antenna FIRMWARE VERSION 8.00 or higher...
-
Page 4: Connectors
J9A and J9B have the same function, the connection Ref. SCHEIBER 0E.CON1485 can be done on J9A or J9B. 1) INPUT 5, ANALOGUE CODING Ref. SCHEIBER 0D.CRD450 (0,4M) to 0D.CRD465 (15M) 2) -VDC OUTPUT 3) INPUT 4, DIGITAL 4) INPUT 3, DIGITAL... - Page 5 Installation instructions • This device must be located in a ventilated place to avoid the risk of water spatter. • Do not install on heat-sensitive supports as carpet, PVC floor, etc... • Imperatively install the product in a cool and dry place. Domotique embarquée Embedded home automation Meaning of the lights :...
-
Page 6: Wiring
Advanced wiring 120 Ω terminaisons Connect multiple modules on the same network CAN cable 230V AC 12-24V DC power supply Domotique embarquée Embedded home automation 2.4 Ghz to module N°3 Coding 2 coding 1 12-24V DC battery Module N°2 Module N°1 Connect multiple modules and a Navicolor on the same network Light Air Switch 2.4 Ghz... -
Page 7: Pairing
Pairing switches on the outputs It is possible to set the switches in different ways depending on your installation. Domotique embarquée ON = turn on the lights Embedded home automation OFF = turn off the lights Case 1: The ON is commanded by a button and OFF by a second button. Operation of the dimming in this case: by pressing the ON button, the intensity of the lighting increases. -
Page 8: Configuration
Domotique embarquée Embedded home automation Configuration A. Configure a permanent output Example of use: connect a reading light equipped with an ON / OFF button Enter the setting mode (press the L key for 3 seconds) Choose an output that has not been paired and flashes to designate it as a permanent output (example: S2). - Page 9 Domotique embarquée Embedded home automation D. Configure the extinction of several outputs Example of use: switch off the ceiling light and various mood lighting, without switching off the bedside lighting. Enter the setting mode (press the L key for 3 seconds) Choose an unconfigured output (example S2).
- Page 10 Domotique embarquée Embedded home automation F. Save the state of the outputs in case of power failure By default, the output status is saved in the event of a power failure. This function can be disabled from a Navicolor. G. Configure the block alarm clock By default, the block wakes up when the power is turned on.
-
Page 11: Troubleshooting Guide
Domotique embarquée Embedded home automation Troubleshooting Guide Observed dysfunction Troubleshooting instructions 1. Check the protection (fuse or circuit breaker) on the power input 2. Check the power of the uses (5 A max per output) 3. Check the voltage on the power connector The outputs do not work 4. -
Page 12: Terms And Conditions
RESPONSIBILITY LIMITS: In any case, the company SCHEIBER will not be held responsible for direct damages or damages not due to the normal use of the equipment. In case of a dispute arising between the parties, the case shall be submitted to the French Right to the court specified by the company SCHEIBER. - Page 13 Solutions connectées intelligentes Question ? contact@scheiber.fr Bellevue, Tél : +33 (0)2 51 51 73 21 clients@scheiber.fr • fournisseurs@scheiber.fr 85120 • Saint-Pierre du Chemin www.scheiber.fr France Marinebeam LED Lighting 660 Riverland Dr, Ste B Charleston, SC 29412 (843) 885-8644...
