Summary of Contents for Omni M-505
- Page 1 Welcome to OMNI M-505 3D Printer Install Manual Contact：Cora Lee Skype: cora8809...
- Page 2 Note: 1, Please ensure that the package is intact before signing; 2, After unpacking, please confirm the package and quantity is consistent with enclosed packing list; 3, Please be carefull when you assemble; 4, Please use sandpaper or knife to fix if both end of rod ...
- Page 3 All Parts as below...
- Page 4 Step 1：Check all Arylic Parts and take out the paper.
- Page 5 Step 2：Framework Assembly Parts：A*1，B*1，C*1，M3*18 screw*8，M3 nut*8. Ps: A is Left and B is Right. Pre-Installation After installation...
- Page 6 Step 3：Framework Fixed and Z-axis motor support Assemble Parts：H1*1, H2*1, D*1, I1*1, I2*1, J1*1, J2*1, J3*1, J4*1, M3*18 svcrew*20, M3 nuts*10. After installation Pre-Installation...
- Page 7 Step 4： Y axis Screw Arbors Assemble Parts：E*1, M8*400MM screw arbors*2, M8 nuts*12, M8 cushion ring*12. After installation Pre-Installation...
- Page 8 Step 5： Y axis Front Base Frame Assemble Parts：F*1, U*4, M3*18 screw*4, M3 nuts*4. After installation Pre-Installation...
- Page 9 Step 6：Y axis Rod Assemble Parts：K*2, M8*380MM sliding rod*2, Bearing*3, M3*18 screws*2, M3 nuts*2. After installation Pre-Installation...
- Page 10 Step 7：Y axis Belt and Z axis's Limited switch Fixed Assemble Parts：L*1, M*1, R*2, P*2, M3*18 screws*5, M3*30 screws*2, M3 nuts*7. Pre-Installation After installation...
- Page 11 Step 8：Y axis Motor and Z axis Motor Assemble Parts：O*1, Q*1, Z axis Motor*2, Y axis Motor*1, Belt*70cm, M3*10 Inner hexagon screws*12, M3*18 screws*4, M3 nuts*4. After installation Pre-Installation...
- Page 12 Step 9：Hot Bed Assemble Parts：Hot Bed*1，Aluminium plate*1, M3*30 screws*4, M3 nuts*4, Compression springs*4, Thumb nuts*4. After installation Pre-Installation...
- Page 13 Step 10：Z axis Rod Assemble Parts：M8*363mm sliding rod*2, M8*325mm screw arbors*2, M8*435mm sliding rod*2, Print Parts*2, Bearing*3. Pre-Installation After installation...
- Page 14 Step 11：Extruder Assemble Parts：U-Metal plate*1, S*4， Extruder Motor*1 set, 40*40*10 Fan*1, M3*18 screws*8, M4*8 screws*12, M3*20 Inner hexagon screws*3. 2 extra screw for Fan. Pre-Installation After Installation...
- Page 15 Step 12: X axis Motor and Belt Assemble Parts：X axis Motor*1, Belt*90cm, M3*20Inner hexagon screws*3, M3*18 screws*2, M3 nuts*2.
- Page 16 Step 13：Limited Switch Assemble Parts：X axis Limited Switch *1, Y axis Limited Switch *1, Z axis Limited Switch *1.
- Page 17 Step 14：LCD Screen Assemble Parts：LCD Screw*1, Screen Cover*1, M3*18 screws*4, M3 nuts*4, Plastic Pillars*4. Pre-Installation After installation...
- Page 18 Step 15：Power Supply Assemble Parts：Power supply*1, Power cable*1, Power Plug*1, M3*12 screws*3. Ps：Default EU Plug After installation Pre-Installation...
- Page 19 Step 16：Mainboard Assemble Parts：Mainboard*1, M3*30 screw*4, M3 nut*4, Plastic Pillars*4.
- Page 20 Step 17：Feeding Frame Assemble Patrs：V*1, W*1, X*2, M8 nuts*4, M3*18 screws*4, M3 nuts*4. After installation Pre-Installation...
- Page 21 Complete Finish...
- Page 22 All comments are welcome! Thank you very much!
