OptiX RTN PI-DC B20
Product Overview and Installation Guide
Issue: 07
Date: 2018-10-30
HUAWEI TECHNOLOGIES CO., LTD .
Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://www.huawei.com
Email:
support@huawei.com
Safety Precautions
• Customer equipment connected to the GE electrical ports of outdoor PIs must have surge protection
capabilities. If customer equipment does not have surge protection capabilities, PIs must be installed indoors.
• Do not touch the connector terminals or pins of P&E cables or DC power cables. Instead, hold the insulation
parts of the cables.
• Prevent conductors or hands from touching the terminals or pins in the P&E ports and DC input/output ports on
PIs.
• Before installing a DC input power cable on a PI, identify the positive and negative ends of the cable. Ensure
that the cable is connected correctly. Install a circuit breaker at the negative end of the external power supply
device to prevent circuit loops from damaging the power cable and PI.
• Before installing a DC output power cable on a PI, identify the positive and negative ends of the cable. Ensure
that the cable is connected correctly. Do not connect the output port of the external power supply device to the
DC output port of the PI.
• Do not connect the output port of the external power supply device to a P&E port of the PI.
• Do not install any cables when devices are powered on.
• When making and installing cables, avoid dropping any metal scraps or other miscellaneous objects into a PI.
• After setting DIP switches, switch off the power supply. After waiting for 6 seconds, switch on the power supply
again.
01
Advertisement
Related Manuals for Huawei OptiX RTN PI-DC B20
Summary of Contents for Huawei OptiX RTN PI-DC B20
- Page 1 HUAWEI TECHNOLOGIES CO., LTD . Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.
-
Page 2: Product Overview
Product Overview The RTN PI-DC B20 is a full-outdoor PI with high power. It uses DC power input and transmits GE electrical signals and -48 V power signals to the full-outdoor RTN 300 equipment through an outdoor network cable. Appearance and Ports Port Description The pin assignments for Ethernet service signals in the ports GE1 and GE2 are consistent with those in Maintenance... - Page 3 Product Overview Principles and Application Scenarios Principles Application Scenarios The RTN PI-DC B20 receives one channel of DC power signals and two channels of GE service signals. After the PI receives DC power signals, the DC-DC processing module increases the voltage to -51.0 V. The RTN PI-DC B20 can supply power to OptiX RTN 300 full-outdoor microwave equipment series.
-
Page 4: Technical Specifications
Product Overview Technical Specifications Power Supply Electromagnetic Compatibility and Safety Compliance Item Description Item Description DC input, with the voltage ranging from –38.4 V to –57.6 V •Passes CE certification. Input voltage •Complies with EN55022 Class B. •Complies with IEC61000-4-4. Electromagnetic compatibility Input power cable diameter 2.5 mm... - Page 5 Installation Guide Terminating a DC Output Power Cable with a Connector Strip a power cable based on the stripping Use a screwdriver to poke the cable locking indicator. latches out. 12 mm 10 mm 10 mm NOTE For the stripping length, see the stripping indicator on the PI. Push the cable locking latches on both sides Insert the power cable.
- Page 6 Installation Guide Terminating a Ground Cable with an OT Terminal Fit the exposed cable into the Strip a ground cable. Mapping between the cross-sectional area of a cable Crimp the OT terminal lug. OT terminal. conductor (C) and the length of an exposed cable (L1) A: OT terminal Cross-sectional L1 (mm)
- Page 7 Installation Guide Terminating a DC Input Power Cable with a Connector Stripping a Power Cable Strip a power cable based on the stripping indicator. NOTE For the stripping length, see the stripping indicator on the PI. 12 mm 10 mm 8 mm Use a pair of diagonal pliers to trim off the -48 V power line.
- Page 8 Installation Guide Terminating a DC Input Power Cable with a Connector Connecting the Power Cable to the Connector Insert the blue power line of the cable into a power cable connector. Power Cable Connector Terminal Line -48 V power line (blue) 0 V ground line (brown/black) Pull the line slightly.
- Page 9 Terminating an Outdoor Network Cable with Shielded RJ45 Connectors Prepare an outdoor network cable Arrange the core wires according to the pin assignments and cut them Prepare the following tools. Strip the cable. and shielded RJ45 connectors. neatly (exposing a length of 12 mm). 8: brown 7: white and brown 6: green...
- Page 10 Installation Guide Installing a PI NOTE Open the cover of the PI. Set DIP switches according to the plan. In normal conditions, you must first select the power supply mode and then power on. If you need to change the power supply mode after power-on, you need to restart the PI. Loosen the screws on the cover of the PI to open the cover.
- Page 11 Installation Guide Installing a PI Install an input power cable on the PI. Install an output power cable on the PI. Connect the DC power connector to Connect the DC power connector to the DC power ports. the DC power ports. Power supply device Connected to an RTN 300...
- Page 12 Installation Guide Installing a PI Install PI service cables to the ports GE1/P&E1/GE2/P&E2. CAUTION The shield layers of all cables connected to the PI must be grounded using wire clips. CAUTION Otherwise, the cables may be damaged by lightning strikes. Avoid dropping any metal scraps or other miscellaneous objects on the front panel or in any ports of the PI.
- Page 13 Installation Guide Installing a PI Close the cover of the PI and tighten all the screws on the cover. (Optional) Mount the PI onto a wall. Drill holes for mounting the PI. NOTE Determine the positions for mounting the PI on the wall, drill holes, and install bolts. If multiple PIs need to be •Tighten the screws in sequence, as shown in the mounted, reserve at lease 50 mm of space around each PI for ventilation.
- Page 14 Installation Guide Installing a PI (Optional) Mount the PI onto a pole or tower. Route hose clamps through mounting holes and fasten the hose clamps on the pole or tower. Mounting holes for Fasten the hose hose clamps. clamps Install the PI on the support. CAUTION •Before fastening the PI onto the pole or tower, hole the PI to Down...
- Page 15 Connection between PI and RTN 300 NOTE NOTE When the RTN 320/380H is installed at a high position on a tower, When the RTN 380 is installed at a high position on a tower, maintenance personnel cannot performance off-tower maintenance personnel cannot performance off-tower RTN 320/380H RTN 380 maintenance through WLAN.
-
Page 16: Checking The Installation
Appendix Checking the Installation Check the installation. Check Item The PI installation position meets the requirements specified in engineering design documents. The PI is installed securely. The appearance of PI components is in good conditions. If there are any paint peeling-off, bump marks, or smears, repaint or clean the components.
