Kinetic Technologies RD1-4028 Manual

Reference design eval kit, dvi to displayport converter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Reference Design Eval Kit
STDP4028-RD1
RD1-4028
DVI to DisplayPort Converter
Kinetic Technologies cannot assume responsibility for use of any circuitry other than circuitry entirely embodied
in a Kinetic Technologies product. No intellectual property or circuit patent licenses are implied. Kinetic
Technologies reserves the right to change the circuitry and specifications without notice at any time
March 2020 – Revision 03a (Rev. B)
Page 1 of 16
Company Confidential

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RD1-4028 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kinetic Technologies RD1-4028

  • Page 1 RD1-4028 DVI to DisplayPort Converter Kinetic Technologies cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Kinetic Technologies product. No intellectual property or circuit patent licenses are implied. Kinetic Technologies reserves the right to change the circuitry and specifications without notice at any time March 2020 –...

  • Page 2: Table Of Contents

    Reference Design Eval Kit STDP4028-RD1 Contents Purpose and Scope ............................4 Description .................................4 2.1. Set Up Instructions .............................5 2.1.1. I2C Host Port ............................5 2.1.2. In-System Programming (ISP) ......................6 2.1.3. Diagnosis ............................6 Board Description ..............................7 3.1. Principal Components and Functions ......................9 3.2. Connector Descriptions ...........................
  • Page 3 Reference Design Eval Kit STDP4028-RD1 List of Tables Table 3.1-1. Principal Components and Functions.................... 9 Table 3.1-1. Principal Components and Functions (continue) ................10 List of Figures Figure 1. Connection Diagram: PC DVI Signal to DP Stream ................5 Figure 2. Block Diagram ............................ 7 Figure 3.

  • Page 4: Purpose And Scope

    DVI input signals supporting video resolution from 640 x 480 up to 2560 x 1600. The RD1-4028 also features digital audio inputs SPIDIF and I2S up to 8 Ch. This reference design meets the following: Stand-alone operation: Includes necessary firmware (either IROM or external SPI) to work independently;...

  • Page 5: Set Up Instructions

    509). STDP4028 register setting changes are required in order to receive audio on I2S input. This can be done through I2C host configuration or through firmware changes. The RD1-4028 supports video resolution from 640 x 480 up to 2560 x 1600 and audio up to 8 Ch. 2.1.1. I2C Host Port Host connector (CN901) allows configuration of the STDP4028 IC from an external host (microcontroller) through conventional I2C interface.

  • Page 6: In-System Programming (Isp)

    Reference Design Eval Kit STDP4028-RD1 2.1.2. In-System Programming (ISP) RD1-4028 uses SPI Flash to store the firmware. In case of a new firmware upgrade, the following method should be used. • ISP through UART connector: Allows programming the SPI Flash through UART (RS232) connector.

  • Page 7: Board Description

    Reference Design Eval Kit STDP4028-RD1 3. Board Description Figure 2. Block Diagram March 2020 – Revision 03a (Rev. B) Page 7 of 16 Company Confidential...

  • Page 8: Figure 3. Board Picture

    Reference Design Eval Kit STDP4028-RD1 Figure 3. Board Picture March 2020 – Revision 03a (Rev. B) Page 8 of 16 Company Confidential...

  • Page 9: Principal Components And Functions

    Reference Design Eval Kit STDP4028-RD1 3.1. Principal Components and Functions Below is a summary of all necessary connectors, switches, and other components. Please refer to the latest board schematics for further details. Table 3.1-1. Principal Components and Functions Label Description RefDes Power Input Input 12 V, down conversion to 5 V, 3.3 V, and 1.2 V.

  • Page 10: Connector Descriptions

    Refer to the datasheet for more details. R510 3.2. Connector Descriptions The RD1-4028 has the following connectors. The locations of these connectors are shown in the board picture in Figure 3. CN301 – +12V DC 4A Power Input Jack CN902 – GProbe Interface (4x1 pin keyed header) connects to the UART port of the STDP4028. Use the Kinetic GProbe board and interface cable for connecting the board to an external PC that has GProbe software running.
  • Page 11 Reference Design Eval Kit STDP4028-RD1 CN901 – I2C Host Interface (header 17X2) connector for connecting external host. This is used only when an external host controller accesses the DisplayPort transmitter; not used for normal operation. In normal operation, internal MCU controls the overall functioning of the DisplayPort Transmitter (refer to the schematics for complete pin description for the Host Interface).
  • Page 12 Reference Design Eval Kit STDP4028-RD1 CN801 – DisplayPort connector. Pin out details are shown below. Pin 1 ML_Lane 0(p) Pin 2 Pin 3 ML_Lane 0 (n) Pin 4 ML_Lane 1 (p) Pin 5 Pin 6 ML_Lane 1 (n) Pin 7 ML_Lane 2 (p) Pin 8 Pin 9...
  • Page 13 Reference Design Eval Kit STDP4028-RD1 CN401 – DVI-D input dual link DVI connector. Pin out description for the DVI connector is shown below. Pin 1 RX2- Pin 2 RX2+ Pin 3 Pin 4 S_RX1- Pin 5 S_RX1+ Pin 6 DVI_SCL Pin 7 DVI_SDA Pin 8...
  • Page 14 Reference Design Eval Kit STDP4028-RD1 CN904 – SPDIF Input connector. The pin out description is shown below. Pin 1 Pin 2 I2S_0 Pin 3 CN903 – I2S Digital Audio Input (52 pin) connector. Pin A1 Pin A2 & A3 Pin A4 through A6 Pin A7 Pin A8 &...

  • Page 15: Switches

    Pin 4 3.3. Switches DVI Configuration Switch (SW401): The RD1-4028 board has a switch for DVI transmitter hardware configuration. The switch SW401 controls DVI Receivers U401 and U402. The switch position is logic HIGH, which is set for dual pixel input mode of operation with rising edge data sampling. The switch definitions of SW401 are described below.

  • Page 16: Stuffing Options

    Reference Design Eval Kit STDP4028-RD1 3.4. Stuffing Options 3.4.1. Single/dual bus TTL input Single TTL configuration: stuff R510, unstuff R509 Dual TTL configuration: stuff R509, unstuff R510 3.4.2. IROM/SPI-Flash OCM boot from IROM code: stuff R504, unstuff R503 OCM boot from external ROM code: stuff R503, unstuff R504 March 2020 –...
