Mic 98850 Operation Manual

K/j/t thermocouple pen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION MANUAL
98850/98851/98852/98853/98855
FEATURES
Auto power off with disable feature(15 minutes).
Data hold function freezes readings on display.
°C / °F select function.
High / Low alarm threshold setting is available.
(98851/98853/98855)
K/J/T type selectable(98852/98853)
MATERIAL SUPPLIED
Meter
CR2032 battery
Operation manual
K type probe
THERMOCOUPLE PEN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 98850 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mic 98850

  • Page 1 OPERATION MANUAL THERMOCOUPLE PEN 98850/98851/98852/98853/98855 FEATURES Auto power off with disable feature(15 minutes). Data hold function freezes readings on display. °C / °F select function. High / Low alarm threshold setting is available. (98851/98853/98855) K/J/T type selectable(98852/98853) MATERIAL SUPPLIED Meter...

  • Page 2: Keypad (Controls)

    KEYPAD (CONTROLS) (1) PWR: Turn on / off the meter or data hold mode. (2) MX/MI/AVG: MAX / MIN / AVG mode. (3) MODE: Short press for temperature, REL, Air T. (98851/98853 / 98855 only), RH (98855 only). Long press for K, J, T mode (98852 / 98853 only).

  • Page 3: Taking Measurement

    (3) TAKING MEASUREMENT Make sure you have plugged the K sensor probe in meter, if the probe is not plugged in appropriately, the LCD will show “----” on the display. (4) DATA HOLD Short press PWR button to freeze reading. Short press PWR button again, the meter will return to normal measurement.

  • Page 4: Change Unit

    (7) MAX / MIN / AVG Short press MX/MI/AVG button, MAX icon with the highest reading(the digit from powered on) appears on LCD. Press MX/MI/AVG button again, MIN icon with the lowest reading (the digit from powered on) appears on the LCD. Press MX/MI/AVG button again, AVG icon appears on the LCD.
  • Page 5 Step 2. Hi Temp. alarm setting When Hi Temp. alarm is on, “Hi Set” icons with the default value 50°C(122°F) or the last setting will appear on the LCD. Keep pressing MODE button to increase digit sequentially from hundred digit and release the button when the digit you desired, then for setting ten digit, unit digit and decimal point are the same as hundred unit.

  • Page 6: Troubleshooting

    # Example 1 - Set Hi Temp. alarm at 1283°C: Step 1. Keep pressing MODE button, the number at unit digit cycle from 0 to 9 then jump to tens digit from 0 to 9, too. Then the same action to hundreds digit then thousands digit, until the thousands digit shows ”1"...

  • Page 7: Battery Replacement

    BATTERY REPLACEMENT When low battery indication icon appears on the " " the battery need to be replaced Use a coin to remove the battery compartment cover on the rear of the meter. Replace the CR-2032 lithium battery; install the new battery face up (+) in the battery compartment.

  • Page 8: Warranty

    WARRANTY This instrument is warranted for two years from the date of purchase against material or production defects, in accordance with our general sales conditions. During the warranty period the manufacturer reserves the right to decide either to repair or replace the product. The two years’...

This manual is also suitable for:

98851988529885398855
