- Page 2 Mandarin Dear friends, Thank you for purchasing our F5J competition high performance electric-powered glider Mandarin. Mandarin is made from selected special light balsa wood. Special Features: Carbon fuselage ; carbon gondole and carbon / kevlar tail tube • Foam core balsa sheeted two-piece wing •...
- Page 3 Fuselage: Glue together assembly of No.1 , 2 and 3 bulkheads (see fig. ). Insert bulkhead assembly into fuselage as deep as possible without problems and too force (fig.). Glue the assembly in this position by 5min epoxy. Glue the front motor mount bulkhead with -3° down and 2° right angles (fig. ). Fuselage pod is sharped in these angles.
- Page 4 - elevator: +- 15 mm - rudder: 25 mm - CG position: 115mm from leading edge Many happy flights with Mandarin wishes to you Reichard Modelsport www.reichard.cz Reichard Modelsport, Grohova 52 , 60200 Brno, Czech Republic reichard@reichard.cz Hobby Club Imported by: P.
- Page 5 Parts list of Mandarin : Wings - 1 pc Fuselage pod + tail tube + canopy - 1 + 1 + 1 pc Rudder - 1 + 1 pc Elevator - 1 pc CFK elevator plate - 1 pc M3 aluminum nut...
