Summary of Contents for micmi WitGarage
- Page 1 Installation Manual...
- Page 2 Thank you for purchasing WitGarage! Quick and Easy Installation 10 Minutes to Finish For more installation instructions, please contact us...
-
Page 3: Table Of Contents
LED Indications ................4 Installation..................5 Check Compatibility ..............5 Install Mobile App & Create Account ........6 Add WitGarage Device to App ..........6 Test sensor for Notification App .......... 11 Install WitGarage on Garage Door Opener......12 WitGarage System Test............13 WitGarage App Introductions............14... -
Page 4: Introduction
INTRODUCTION WitGarage is a companion device to an existing garage door opener with two Wi-Fi configuration modes called “Smart Config” and “AP Mode”, which can make your garage door smarter and securer. It allows multiple users to control and monitor your garage door from anywhere in the world. -
Page 5: Led Indications
The Wi-Fi has not been configured and the device is in “AP Mode” configuration. (3) Blink in Blue Sensor has not been bound to Controller. (4) Blink in Green The Wi-Fi has been configured but the internet may not work. Please check your router. (5) Solid Green Your WitGarage is all set. -
Page 6: Installation
After that, can your garage door opener be activated? -----Yes. It is compatible with WitGarage. Go to step 2. -----No. It is incompatible with WitGarage. STOP and contact us. -
Page 7: Install Mobile App & Create Account
STEP 2 INSTALL MOBILE APP & CREATE ACCOUNT 1) Download "WitGarage" app from Google Play Store/Apple App Store; 2) Launch "WitGarage" app; 3) Create new account by tapping “Create New Account now” or “Login” with Facebook or Twitter. STEP 3... - Page 8 2. Add Your WitGarage to App and Configure Wi-Fi Launch WitGarage app and login; Tap “Add device” to configure Wi-Fi (see the figure below). Note: WitGarage supports two modes of Wi-Fi configuration: “Smart Config” “AP Mode”. “Smart Config” is the...
- Page 9 Steps for “Smart Config” Settings (see figures below): App connection has been set with “Smart Config”.
- Page 10 “AP Mode” (see the right figure). 2) Launch WitGarage app, tap “Add device”, and then tap “AP mode” on the right top of the page (see the figures below). App connection has been set with “AP Mode”...
- Page 11 Now, device has been successfully added to the app and Wi-Fi has been set. You can tap “Setting” in the app for more interesting functions. E.g. rename your new WitGarage device for voice command control. If you don’t rename it, the default name will be “WitGarage” (see the figures below).
-
Page 12: Test Sensor For Notification App
Please test for at least 3 times to make sure the status is in the correct way. If the door state in WitGarage app doesn’t change while turning the directions of sensor, please unbind it from controller, and then rebind them. -
Page 13: Install Witgarage On Garage Door Opener
(2) Rebind: Turn the sensor by 90 degrees, wait for about 5 seconds until the controller’s LED indicator turns to solid green. STEP 5 INSTALL WITGARAGE ON GARAGE DOOR OPENER 1. Stick the sensor to the Top of Garage Door Close your garage door, remove the sticker at the back of sensor and stick it on top of your garage door. -
Page 14: Witgarage System Test
The installation is completed. Let’s try to control the garage door opener and check for the notifications with WitGarage smart system. Launch the WitGarage app, and you will see the status of your garage door. Tap the garage door icon in the app, and your garage door should be opening/closing accordingly. -
Page 15: Witgarage App Introductions
If you have any questions, please email to us. supports@micmi.com. micmi.com You can also visit for FAQs, troubleshooting, and detailed installation instructions with examples and videos. WITGARAGE APP INTRODUCTIONS Features: Garage door controller and monitor Excellent device management Notifications on the door status... - Page 16 If you want to find more fuctions as following, please click the item(see following figure,left), it will show fuctions screen(see following figure,right). (4) Access sharing and device renaming Rename the device by tapping Share access by tapping (5) Smart control by setting schedules and distances Set a schedule by tapping , so that the door will be automatically...
-
Page 17: Witgarage Alexa Skill Setup
Amazon Alexa app. The newest operation guide will be updated on our website. https://micmi.com Following steps describe how to set up Alexa Skill for Witgarage. 1) Launch the Amazon Alexa app on your phone. 2) Click the option icon. - Page 18 3) Select “Skills & Games” 4) search the “Smart Life”skill.
- Page 19 5) Enable the skill. 6) Input your Witgarage account name and password and tap...
- Page 20 “Link Now”. 7) Select the app name “WitGarage” and tap “Link Now”. 8) Authorize 9) Completed page 10) Discover devices...
- Page 21 Alexa voice command to control your door. You can also rename it (see the right figure). Voice Command: “Alexa, turn on Witgarage.” “Alexa, turn off Witgarage.” If you rename your Witgarage device as “Mike”, you should say: “Alexa, turn on Mike.” “Alexa, turn off Mike.”...
-
Page 22: Witgarage Google Home Setup
✓ Witgarage app and a related account. ✓ Witgarage device. 2) Add devices in Witgarage app (Refer to App Instruction) You can skip this part if you've already add a device to your Witgarage account, and in the meantime the device’s name is easily recognized. - Page 23 3) Set up Google Home and configure in Home Control; Configuration needs Google Home app. Search "Google Home" in App Store or Google Play to install the app. 4) Link Smart Life account in Home Control,see following figures:...
- Page 24 Type the keywords “ Smart life” to search like below: Select your region, input the account name and password of...
- Page 25 WitGarage app, and Tap “Link Now”.After you assign rooms for devices, your devices will be listed in the Home Control page. 5) Pease check the device name before you use Google Home to control the garage. You can also rename it (see the right figure).
