- Page 1 60ft. Electric Drain Cleaner Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Items #62082 & #62083 SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Klutch™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 7 Grounding .............................. 7 Extension Cords ............................ 9 Main Parts of Drain Cleaner ......................... 9 Assembly Instructions ........................10 Before Each Use ..........................12 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Klutch 60ft. Electric Drain Cleaner is intended for household use only. There are four cutting tools included with each drain cleaner. Select the appropriate tool for the cleaning job and attach to cable. Ideal for cleaning floor drains, roof vents, and sink lines. - Page 5 ⚠WARNING WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well lit. Cluttered, wet, or dark work areas can result in injury. Using the drain cleaner in confined work areas may put you dangerously close to cutting tools and rotating parts.
- Page 6 This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet. Do not change the plug in any way. Double insulation eliminates the need for the three wire grounded power cord and grounded power supply system.
-
Page 7: Specific Operation Warnings
Specific Operation Warnings ⚠WARNING To prevent serious injury or property damage read and understand owner's manual before operating. To reduce the risk of injury from moving parts, unplug before servicing. To reduce the risk of electric shock, unplug before cleaning or servicing. ... - Page 8 CHECK with a qualified electrician or service person if you do not completely understand the grounding instructions, or if you are not sure the tool is properly grounded. Grounded Tools: Tools with 3-Prong Plugs Tools marked with Grounding Required have a 3-wire cord and 3-prong grounding plug. The plug must be connected to a properly grounded outlet.
-
Page 9: Extension Cords
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual, including all text under the subheadings, before set up or use of this product. Note: No assembly needed for Item #62082. User-Operated Controls: Page 9 of 29... -
Page 10: Assembly Instructions
Assembly Instructions ⚠WARNING Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual Page 10 of 29... - Page 11 including all text under subheadings therein before set up or use of this product. To prevent serious injury from accidental operation: Turn the rotation switch of the tool to its OFF position and unplug the tool from its electrical outlet before assembling or making any adjustments to the tool.
-
Page 12: Before Each Use
However, if the drain is in poor condition or has not been properly designed, the drain cleaning may damage the drain. If possible, visually inspect the drain’s quality before operation. This drain cleaner is in intended for household use only. Before Each Use ⚠WARNING If the supply cord of this appliance is damaged, it must be replaced only by a qualified service... - Page 13 ⚠WARNING TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the rotation switch of the tool to the OFF position and unplug the tool from its electrical outlet before assembling or making any adjustments to the tool. DO NOT OPERATE WITH ANY GUARD DISABLED, DAMAGED, OR REMOVED. Tool Set-Up When setting up the drain cleaner, wear ANSI-approved, splash-resistant, safety goggles and a NIOSH-approved, dust mask or respirator under a face shield.
- Page 14 7. Rotate the drum and make sure that it turns freely without binding. 8. Check that all warning labels are present, firmly attached, and readable. 9. Make sure belt guard is securely fastened to the drain cleaner. 10. Check the cable for any wear and damage. If any section of the cable is worn or flattened, replace the cable before use.
- Page 15 5. Make sure there is a clear, unobstructed path from the drain cleaner to the electrical outlet. 6. Inspect the drain to be cleaned. If possible, determine the best access point(s) to the drain, the size(s) and length(s) of the drain, distance to the tanks or mainlines, the nature of the blockage, presence of drain cleaning chemicals or other chemicals, etc.
- Page 16 If the outlet is not GFCI protected, use a plug-in type GFCI between the outlet and the extension cord. This will reduce the risk of shock if there is a fault in the extension cord. Manual Feed Operation (Item #62082) ⚠WARNING...
- Page 17 6. As you feed cable, you may feel and see cable slow down and/or start to wind or load up (a twisting or squirming motion). This may indicate a change in the drain line (such as a drain trap, elbow, etc.), a build-up in the drain (mud or grease), or the actual blockage. Continue to slowly feed the cable until it reaches the blockage.
- Page 18 If Cutting Tool Lodges in Drain 1. If the cutting tool stops turning and the cable cannot be pulled from the blockage, release the foot switch while holding the cable with both hands. ⚠WARNING Do not remove your hands from the cable or it may kink, twist, and break. 2.
- Page 19 2. Pull the cable from the drain by hand and feed it into the drain cleaner until the cable is a couple of feet from the drain opening. A flow of water down the line will help to clean the cable as it is retrieved.
- Page 20 4. After ensuring that the rotation switch is in the FOR position, the tension knob has been tightened, and the power-feed lever is in the F (down) position, press the foot switch to start feeding the cable further into the drain. 5.
- Page 21 3. Put the power-feed lever in the up (R) position to pull the cable back and free the cutting tool from the blockage. 4. If the motor can’t pull the cable out, release the pressure from the foot switch and allow the cable to stop spinning.
-
Page 22: After Each Use
After Each Use ⚠WARNING Wipe the external surfaces of the drain cleaner with a clean cloth. Store indoors out of the reach of children. Maintenance ⚠WARNING Procedures not specifically explained in this manual must be performed only by a qualified technician. -
Page 23: Troubleshooting
Maintenance Interval Maintenance Point 1. Loosen the belt guard retaining knob and slide the belt guard off. 2. Use the screwdriver to slide the belt off the back of the drain cleaner drum. 3. Slide the new belt onto the belt pulley above the drum. Removing and Installing the 4. - Page 24 Failure Possible Cause Corrective Action 3. The cable is the wrong size for 3. Change the cable size. the drain pipe. 4. Cable was exposed to acid. 4. Clean and oil the cable regularly. 5. Cable was exposed to acid. 5.
-
Page 25: Parts Diagram
Parts Diagram Item #62082 Page 25 of 29... - Page 26 Item #62083 Page 26 of 29...
-
Page 27: Parts List
Parts List Item #62082 Item #62083 Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. -
