dreambaby F820N Instructions

IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY
If you sell or give away this product, make sure you give this instruction to the new owner.
WARNING
WARNING– Incorrect installation can be
dangerous.
WARNING– Do not use the safety barrier if
any components are damaged or missing.
WARNING– The safety barrier must not be
fitted across windows.
WARNING– Never use this gate without
securely installed Locking Brackets and
Locking Hooks.
PARTS LIST
INSTALLATION
A
Gate Panel
B Cover
C Upper Bracket (x2)
Includes 2 sets of mounting
D Lower Bracket (x2)
brackets for convenient
E Upper Hook (x2)
'clip-on/clip-off' relocation
F Lower Hook (x2)
G Locking Rod
H Screws 4x25mm ( x1in) (x16)
5/32
I Masonry/Brick Plugs (x16)
J Templates (x2)
K Base of Casing
L
Top of Casing
M
Release Button
H
I
E
c
inside
frame
outside
frame
1
2
J
F
D
INSTRUCTIONS
Retractable Gate
AND KEEP FOR FUTURE REFERENCE
Read the entire instructions before assembling and installing this product.
This safety barrier conforms to
EN1930:2011;
This safety gate is for domestic use only;
This safety gate has been designed for use
with children up to 24 months of age;
Never use with a child able to climb over or
dislodge/open the gate;
The surfaces that the gate is to be fixed to
must be suitable for the purpose and must
be structurally sound;
C
Optional
Spacer Sets
(sold separately)
See Accessories
Panel *
D
WARNING: This package contains small parts and sharp points in an
unassembled state. Keep out of reach of children. Adult assembly required.
The clearance space between the Base of
Casing and the floor MUST NOT exceed
0.3cm (0.12in);
If the safety gate is used at the bottom of
stairs to prevent the child climbing up the
stairs, it must be placed at the front of the
lowest stair;
If the safety gate is used at the top of the
stairs to prevent child falling down the stairs,
it must not be placed on any stair below the
level of the top stair;
B
M
L
K
F820N.F943N IM_p1-p4_BASEDv2_2016.02.26
At the top of landing, position the gate
15cm (6in) away from the top step;
This safety gate has a manual close system;
This safety gate must NEVER be used as a
pool or pond barrier;
Never leave a child unattended.
This safety gate does not replace proper
adult supervision.
Before you start
This gate can cover
an area of up to
140cm (55in).
A
F820N (white)
F943N (black)
Patent No. 1/604,922
Have on hand a tape
measure. pencil. drill with
4mm (5/32 x1in) drill bit
and a Phillips head
screwdriver.
E
B1 B2
Optional
Spacer Sets
(sold separately)
See Accessories
Panel *
Optional
*
Accessories
(sold separately)
F821N Spacer Sets (white)
F944N Spacer Sets (black)
G
For use when gate is fitted to
Skirting boards / Baseboards
F895 Gate Adaptor Panel
To provide a flat surface
to install gate.
F
