Summary of Contents for ULTRAPALACE MIDINOME
- Page 1 MIDINOME A Tap-Tempo Metronome, Master Midi Clock, and CV Clock Manual v3.0...
- Page 2 MIDINOME keeps you and your devices synchronized by generating both a MIDI signal, and an audio click, while keeping both signals perfectly in sync. Midinome can start or stop a MIDI sequence as well as change the tempo by tapping, all while occupying the least amount of real-estate in your pedalboard and keeping functions simple.
-
Page 3: Inputs, Outputs, & Controls
- eliminating drift in long sessions. ● Firmware upgradable/customizable with Arduino Inputs, Outputs, & Controls Start/Stop The Midinome is always either A ctive(Green) or H alted(Red) , the S tart/Stop f ootswitch alternates between these two modes. - Page 4 When the Midi Clock is started or stopped it sends a standard MIDI Start Command (0xFA) or Stop Command (0xFC). If MIDINOME is H alted (Red), and the S tart/Stop button is pressed, it will start both the MIDI Clock and the Audio Click. If the MIDINOME is ...
-
Page 5: Tap Tempo
This will now be the current default tempo, and will be active when power is removed and reapplied. Wait a few seconds after you last pressed the Tap Tempo button, or Midinome might think you mean to tap a tempo in. - Page 6 The LED will flash while the MIDINOME is A ctive , it will flash in sync with the MIDI signal and the audio click or CV clock. When power is first applied to the MIDINOME the LED will light to indicate it is ready.
- Page 7 For Moog and some Arp equipment, a V- trig to S- trig adapter will be required. The Midinome has now 9 click tone presets that can be selected from the menu.
-
Page 8: Volume Knob
Volume Knob Adjust the volume of the Audio Click. Rotate clockwise for louder and counter-clockwise for quieter or silent. When the MIDINOME is in C V Mode , the volume knob has no function. MIDI OUT... - Page 9 MIDI splitters and converters can also be used. DC POWER Midinome takes a standard 2.1 mm power jack, 9VDC. As is common with guitar pedals, it is c entre negative to fit easily on your pedalboard. Midinome is reverse polarity protected, so no worries if the wrong type of adapter gets plugged in.
- Page 10 Connect your headphones and MIDI cable. The MIDI cable should run from the Midinome, to the MIDI IN of the device receiving MIDI signal. Next, connect the power. The LED will flash red for about 3-5 seconds after that the LED will stay lit indicating that the Midinome is ready to go.
-
Page 11: Settings Menu
CV Mode Midinome has a small built in switch that will toggle the device between Audio Click Mode , and C V Clock Mode . The A udio Click Mode is intended to be a metronome, and C V Clock Mode is intended to trigger a synthesiser or drum machine, or to synchronize other electronic devices which accept this standard. - Page 12 And once you are happy with the current changes, press and hold Tap Tempo and press and hold Start/Stop to Save changes and go into regular Midinome operation. CV Divider (Purple LED) You can change the clock division that gets sent out via CV, The purple light will flash accordingly to the subdivision, options are: 1:4, 1:2 , 1:1, and 2:1.
-
Page 13: Tips And Tricks
If you want to send the Audio Click to more people and synchronize your loops live, we recommend using a splitter, headphone amp, or mixer. Firmware Updates Firmware updates will be announced on the Ultra Palace facebook page, or ultrapalace.com. - Page 14 Compatibility This is a list of devices which we’ve tested with the MIDINOME for MIDI or CV. Normally MIDI is universal and you shouldn’t have any problems with any device, as long as it’s configured to receive a MIDI Clock.
-
Page 15: Technical Specifications
If any problems occur, stop using the pedal and contact us for advice on how to proceed. We love feedback, and would be happy to hear from you! We are also open to suggestions for upcoming versions or firmware revisions. Contact info@ultrapalace.com... - Page 16 This manual printed on residue waste from sugar cane processing. © ULTRAPALACE 2020...
