CARINA GAS FIRE PIT - MANUAL
USE OUTDOORS ONLY
CAUTION
DO NOT DISCARD THIS MANUAL
•IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS INCLUDED.
•READ, UNDERSTAND AND FOLLOW THESE INSTRUCTIONS FOR SAFE
INSTALLATION AND OPERATION
These instructions are only valid if the following country code is on the appliance. If this code is not
present on the appliance it is necessary to refer to the technical instructions which will provide the
necessary information concerning the modification of the appliance to the condition of use for the
country.
Advertisement
Table of Contents
Summary of Contents for BARKER AND STONEHOUSE CARINA
- Page 1 CARINA GAS FIRE PIT - MANUAL USE OUTDOORS ONLY CAUTION DO NOT DISCARD THIS MANUAL •IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS INCLUDED. •READ, UNDERSTAND AND FOLLOW THESE INSTRUCTIONS FOR SAFE INSTALLATION AND OPERATION These instructions are only valid if the following country code is on the appliance. If this code is not...
-
Page 2: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the (EU) 2016/426 product. This appliance has been tested to and complies with the Outdoor Decorative Gas Appliances. When connecting to a fixed piping system, the installation must conform to local codes or the absence of local codes。... - Page 3 SAFETY INFORMATION WARNING DANGER Certain materials or items, when stored under the fire DANGER indicates an imminently hazardous situation which, if not pit, will be subjected to radiant heat and could be avoided, will result in death or seriously damaged. serious injury.
- Page 4 SAFETY INFORMATION WARNING WARNING We cannot foresee every use which may Improper installation, adjustment, alteration, service or maintenance be made of our fire pit. can cause property damage, injury Check with your local fire safety authority or death. Read the installation, if you have questions about fire pit use.
- Page 5 OPERATION CHECKLIST Operation Checklist For a safe and pleasurable heating experience, perform this check before each use. Before Operating: 1. I am familiar with entire owner’s manual and understand all precautions noted. 2. All components are properly assembled, intact and operable. 3.
-
Page 6: Exploded View
EXPLODED VIEW ASSEMBLY INSTRUCTIONS Step 1... - Page 7 Step 2 Step 3 Please use a cylinder no bigger than 500mm (h) by 325 mm (d) Max Weight 9kg (20lb)
- Page 8 SUPPLIER: BARKER AND STONEHOUSE APPLIANCE CODE: CARINA FIRE PIT 2531-18 TOTAL HEA INPUT: 14.65KW (1066g/h) 3+(28~30/37) GAS CATEGORY: 3B/P(37) 3B/P(30) 3B/P(50) TYPES OF GAS: Butane (G30) Propane (G31) G30, G31 or their mixtures GAS PRESSURE: (28-30) mbar...
-
Page 9: Installing Lp Gas Tank
INSTALLING LP GAS TANK Connect LP Gas Tank Before connecting, be sure that there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner and burner ports. LP GAS Connect regulator/hose assembly to tank by turning knob clockwise until fully secured into... -
Page 10: Lighting Instructions
Note: The leak test must be performed in an area that has adequate lighting in order to see if bubbles are developing and not in a windy or noisy area so larger leaks can be detected by smell or sound. 1. -
Page 11: Troubleshooting
Minimum clearance: Top: 180cm (72") sides:90cm (36") Minimum clearance from sides and back of unit to adjacent combustible construction below the height of the unit, 90cm (36") from the sides and 90cm (36") inches from the back. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Propane cyliner is empty Replace propane cylinder... -
Page 12: Care And Maintenance
CARE AND MAINTENANCE CAUTION: All cleaning and maintenance should be done when the fire pit is cold and with the fuel supply disconnected. 1. DO NOT clean any outdoor fire pit part in a self-cleaning oven. The extreme heat will damage the finish. 2.
