- Page 1 Ｐａｐｅｒｌｅｓｓ Ｒｅｃｏｒｄｅｒ ＴＲＭ－００Ｊ Ｕｓｅｒ’ｓ Ｍａｎｕａｌ DWG.No.4B-5408 www.jetec.com.tw TEL:+886-4-23729418 (40349)台中市西區福人街11號 sales@jetec.com.tw 久德電子...
- Page 2 Paperless Recorder TRM-00J Operation Manual Introduction Thank you for purchasing our electronic product (TRM-00J). Before using this product, please read this manual carefully to understand its contents. Please keep this manual and use it whenever necessary. Precautions upon Usage Please read this section before use.
- Page 3 Warning Wrong connection ofthe product may cause fire, which may lead to the breakdown of the product. After the wiring work, make sure that all connections are donecorrectly before turning the power of the product ON. Never turn the power ON while the wiring work is in progress. Never touch the high-voltage section of the product, such as the power supply terminal.
-
Page 4: Table Of Contents
Contents Outline ·················································································· - 1 - Section 1 1.1. Features ······················································································· - 1 - 1.2. Check the Product ··············································································· - 1 - 1.3. Name of Parts ·················································································· - 1 - 1.4. Basic Screen Navigation ··········································································· - 2 - Installation ··············································································· - 4 - Section 2 2.1. - Page 5 5.4. Record ······················································································· - 35 - 5.4.1. Record Cycle and File Record Cycle······························································································· - 35 - 5.4.2. Record Type ························································································································ - 35 - 5.4.3. Conditions to Start/Stop the Recording ························································································· - 35 - 5.4.4. Record Data ························································································································· - 37 - 5.5.
-
Page 6: Outline
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Section 1 Outline 1.1. Features ●This product is a paperless recorder that displays measurement data on LCD on a real-time basis and save them into an external memory (USB memory or SD card). LCD with touch panel allows you to operate the recorder veryeasily. -
Page 7: Basic Screen Navigation
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 1.4. Basic Screen Navigation Power On Initial screen 4 Sec. after Real-Time Trend Historical Trend Mode key Horizontal Trend Horizontal Trend Graph key Graph key Mode key Vertical Trend Vertical Trend Graph key Graph key... - Page 8 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Main Menu Back key Back key Parameter key System key MENU key MENU key Parameter Setting System Setting Input setting Storage Media Display setting Device/Other Record setting Others - 3 - www.jetec.com.tw TEL:+886-4-23729418 (40349)台中市西區福人街11號...
-
Page 9: Installation
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Section 2 Installation 2.1. Precautions upon Installation Warning To avoid electrocution and damage to the device, always turn the power OFF upon detaching/attaching the product. ★ Ambient Temperature (Use the product within the range indicated below.) ①... -
Page 10: How To Attach/Detach
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 2.2. How to Attach/Detach ★ Attach to Panel ① Make a hole at the panel surface. ② Insert the product from the front surface. ③ Change the size of the attachment to be used depending on the thickness of the panel surface. -
Page 11: Outline View And Dimensions Of Panel Cut
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 2.3. Outline View and Dimensions of Panel Cut Unit: mm Unit: mm - 6 - www.jetec.com.tw TEL:+886-4-23729418 (40349)台中市西區福人街11號 sales@jetec.com.tw 久德電子... -
Page 12: Wiring
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Section 3 Wiring 3.1. Things to be Noted during the Wiring Work Warning To avoid electrocution and breakdown of the product, never turn the power ON while the wiring work is in progress. ★ For thermocouple input, use the designated wire or extension lead wire. -
Page 13: Terminal Layout
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 3.2. Terminal Layout RS-485 Power DI/DO Analog Input 4-6 Analog Input 1-3 3.3. Wiring to Each Terminal 3.3.1. Power Supply Terminal Terminal No. - 8 - www.jetec.com.tw TEL:+886-4-23729418 (40349)台中市西區福人街11號 sales@jetec.com.tw 久德電子... -
Page 14: Analog Input Terminal
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 3.3.2. Analog Input Terminal Terminal No. Input V+/b V+/b V+/b Terminal No. Input V+/b V+/b V+/b Common to All Channels: Method of Wiring per Input Type TC・mV ※ In case of mA input, use 250Ω shunt resistor and wire at the area where V input is located. -
Page 15: Di/Do Terminal
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 3.3.6. DI/DO Terminal DI: Non-voltage Contact Input (9 points), common DO: Open Collector Output (12 points), common Pin No. Signal Pin No. Signal DO10 DO11 DO12 DI_COM DO_COM DI_COM DO_COM DI_COM DO_COM DI_COM DO_COM... -
Page 16: Screen Description
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Section 4 Screen Description 4.1. Common Display Section ① ③ ⑤ ② ④ ⑥ ① State of SD Card Shows the state of SD card throughthe text color. Blue: Not inserted Yellow Green: Inserted (with a remaining capacity of more than 30%) - Page 17 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 ④ State of Recording Shows the state of recording through the text color. Blue: Recording is stopped Red: Recording in progress ⑤ Clock Displays current date and time. See 6.2.4Clock to set date and time.
-
Page 18: Real-Time Trend
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.2. Real-Time Trend Displays the latest data that is being recorded. See the description of each section. 4.2.1. Common Sections of Real-Time Trend ① ② ③ ④ ① Group Switching Key Switches the group to be displayed. -
Page 19: Trend Display
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.2.2. Trend Display Horizontal Trend Vertical Trend ② ③ ② ⑤ ⑤ ⑥ ⑥ ⑦ ③ ① ⑦ ④ ①Trend Line Draws the line with the color that was set per channel. ② Scale Displays the scale per channel. - Page 20 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 ④ Channel Number Key Pressing thechannel number key allows the user to switch the subjected channel to be displayed at the scale. Upon doing so, the trend line will get thicker and the unit will be displayed for approximately 3 seconds.
-
Page 21: Bar Graph Display
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.2.3. Bar Graph Display ① ② ③ ① Bar Graph Displays the bar graph of the measuring value per channel. Color and scale of the graph are based on the setting that is made for... -
Page 22: Digital Display
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.2.4. Digital Display ① ② ③ ① Measuring Value Displays the measuring value of each channel in a numerical format. However, in case of a breakdown of the sensor or this product, the following texts will be displayed: -H-: This will be displayed when the detected input value is higher than the measuring range. -
Page 23: Event History
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.2.5. Event History Scroll Bar Displays the history of events. Up to 50 event histories shall be kept. Events that were triggered during the display of this screen will be displayed by pressing the update key. -
Page 24: Historical Trend
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.3. Historical Trend Displays past data. See the description of each section. 4.3.1. Common Sections of Historical Trend ① ② ③ ④ ① File Key If the file key is pressed, a file selection screen appears. From the file selection screen, select the file to be displayed at the historical trend. -
Page 25: Trend Display
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.3.2. Trend Display ③ ④ ③ ⑥ ② ⑥ ⑦ ⑦ ⑧ ② ④ ① ⑧ ⑤ ① Trend Line Draws the line with the color that was set per channel during the recording. -
Page 26: Event History
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 ⑥ Auxiliary Line Can set the number of auxiliary lines per channel. Set the scale auxiliary line(Partitions) if necessary. ⑦ Time Stamp Time and Line Displays the time stamp with the desired time interval during recording. Desired time interval varies depending on the setting of the record cycle that is set during recording. -
Page 27: File Selection
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.3.4. File Selection Selects the file to be displayed with the historical trend. Select the memory media (internal memory/SD card/USB memory) where the data is being recorded. When memory media is selected, folders will be displayed on the left side of the screen while files that are contained in the selected folder will be displayed on the right side of the screen. -
Page 28: Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.4. Settings This section describes the basic operation to be performed at each setting. See Section 6List of Settings for the list of setting values. 4.4.1. Basic Operation of Setting Screen The method of setting operations differs depending on the setting. Methods of operation are as follows: List Display; Select/Non-select;... -
Page 29: Unnecessary Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.4.1.4. Numerical Value Input Displays the numerical value input screen when the key is pressed. Add or subtract values through ▲/▼ key to set the desired value and press “Enter” key. 4.4.2. Unnecessary Settings This product has a function that hides unnecessary settings in accordance with the settings condition. -
Page 30: Main Menu
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.4.3. Main Menu If parameter setting key is pressed, 4.4.4Parameter Settings will be displayed. If system setting key is pressed, 4.4.5System Settings will be displayed. Press Back key to go back to the original screen. - Page 31 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.4.4.1. Copying of Setting Value Allows the user to copy the setting value of the input setting (except for the display color) between channels. Utilize this function if several sensors of the same kind will be used.
-
Page 32: System Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.4.5. System Settings Pressing each submenu key will display the corresponding setting screen. Section 6List of Settings for settings to be displayed at each submenu. Provided, however, that SD card, USB memory, internal memory, and version are not included in the setting screen. - Page 33 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Save/Read of Setting Values A function to save setting values of this product to the external memory. Pressing the setting value saving key will create the setting value file. Setting value reading key will read the saved file and reflect the content of the setting value file to setting values in the product.
- Page 34 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Format A function that formats the subjected memory. Product will erase all data in the subjected memory. Make sure that the subjected memory does not contain any data other than that for the product.
-
Page 35: Channel Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 4.4.6. Channel Settings The above screen will be displayed by pressing the channel number key for 2 seconds. If the setting verification key is pressed, a list of channel settings of the subjected channel will be displayed. - Page 36 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Input Scale Upper Limit Range Key and Lower Limit Range Key: Pressing them will display the Numerical Value Input screen, which allows the user to change the range of the scale. Back Key: Sets the temporarilyset scale range back to the saved setting value.
-
Page 37: Function Description
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Section 5 Function Description 5.1. Measuring Value Performs a setting in accordance with the sensor to be used for each channel. 5.1.1. Method of Setting in Accordance with the Type of the Sensor Method of setting per input type:... -
Page 38: Square Root Operation
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 If the measuring value of other channels is used, a more accurate measurement can be achieved by using the sensor that is more accurate than the measurement accuracy of the internal circuit. 5.1.3. Square Root Operation... -
Page 39: Alarm
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 5.2. Alarm Allows the user to set up to 4 alarms per channel and outputs ON/OFF of the subjected alarm through ALM output/DO output. Setting shall be done at the alarm setting. It can also attach the message to the subjected alarm. -
Page 40: Record
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 5.4. Record Can set conditions of the contents to be recorded to the memory. 5.4.1. Record Cycle and File Record Cycle Record Cycle: Sets the time interval of the recording of measurement value. File Record Cycle(File rec. cy): It divides the file per time that was set. - Page 41 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 5.4.3.1. Schedule Function Allows the user to set the time to start and stop the recording. It also allows the user to specify the date to activate the function on a per day of the week basis or on a daily basis. If the day of the week is specified, the function will start and end the recording only within the specified day of the week.
-
Page 42: Record Data
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 5.4.3.3. Communication Allows the user to start/stop the recording through the sending of specified command via communication function. See 5.10Communication for detail. 5.4.4. Record Data Creates the record file into inserted SD card or USB memory (hereinafter referred to as “external memory”) in accordance with the setting. -
Page 43: Lapse Time
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 5.6. Can set the function per DI. Other usage: It can also be used as the message trigger. DI Function OFF: Turn DI function OFF Record ON/OFF: Starts/stops the recording through DI. See 5.4.3.2ON/OFF of DI for details. -
Page 44: Communication
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 5.10. Communication Allows setting and monitoring through the serial communication via RS-485 and USB. See Communication Manual for the specification of communication. 5.11. LCD Backlight Reduces the brightness during sleep mode in order to prolong the life of LCD backlight. Setting shall be done at 6.2.1LCD backlight. -
Page 45: List Of Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Section 6 List of Settings Lists down name, setting range, and initial value of each setting. Those settings with the description “per ...” at the remark column means that the setting shall be done on a per subject basis. - Page 46 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.1.2. Scaling Name Setting Range Initial Value Remark Square root Meas. upr lim Input voltage/current (Upper limit of measuring Meas. lwr lim - 327.67(mV, V, mA) 10.00 range) Meas. lwr lim Input voltage/current (Lower limit of measuring -327.68(mV, V, mA) - Meas.
-
Page 47: Display Setting
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.1.3. Display Name Setting Range Initial Value Remark CH01:TAG01 CH02:TAG02 CH03:TAG03 Any character CH04:TAG04 CH05:TAG05 CH06:TAG06 Description Any character Green Blue Purple Yellow Per Channel Aqua CH01:Purple Dark Red CH02:Red Lime CH03:Green Display Color... - Page 48 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.1.5. Alarm Name Setting Range Initial Value Remark Alm Up Lim Alarm Type Alm Lw Lim Abnl Alarm Alm Tgt Conn DO01-DO12 Input Thermocouple/Resistance Temperature Per Channel, Detector Per Alarm Alarm Value -3276.8-3276.7 (℃)
- Page 49 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.2. Display Setting 6.1.2.1. Group name Name Setting Range Initial Value Remark Group1:DISP_GRP_1 Group2:DISP_GRP_2 Group3:DISP_GRP_3 Group4:DISP_GRP_4 Group Name Any character Group5:DISP_GRP_5 Group6:DISP_GRP_6 Per Group Group7:DISP_GRP_7 Group8:DISP_GRP_8 Group1：ON Group Display Group1 is fixed to ON Group2-8：OFF...
- Page 50 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.2.2. Group channel Name Setting Range Initial Value Remark Non-select CH01 Select Select Non-select CH02 Select Select Non-select CH03 Select Select Group01 Non-select CH04 Select Select Non-select CH05 Select Select Non-select CH06 Select Select...
- Page 51 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 Name Setting Range Initial Value Remark Non-select CH01 Select Select Non-select CH02 Select Select Non-select CH03 Select Select Group05 Non-select CH04 Select Select Non-select CH05 Select Select Non-select CH06 Select Select Non-select CH01 Select...
-
Page 52: Record Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.3. Record Settings 6.1.3.1. Record Operation Name Setting Range Initial Value Remark 0.1 sec 1 sec 2 sec 3 sec 5 sec 10 sec 15 sec 20 sec 30 sec Record Cycle 1 sec... - Page 53 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.3.2. Schedule Name Setting Range Initial Value Remark Schedule Week Day Every Day 00:00:00-23:59:59 Start Time 00：00：00 00:00:00-23:59:59 End Time 00：00：00 Non-select Select Non-select Select Non-select Select Day of the week Non-select specified Non-select...
-
Page 54: Others
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.4. Others 6.1.4.1. Message Name Setting Range Initial Value Remark Message Any character Func Key Alarm On Timing Alarm Off DI ON DI OFF CH01 CH02 CH03 Channel No. CH01 CH04 CH05 CH06 Per Message... - Page 55 User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.1.4.3. Progress time Name Setting Range Initial Value Remark Progress time Record Condition Alm ocrd Record CH01 CH02 CH03 Channel No. CH04 CH01 CH05 CH06 Alarm 01 Alarm 02 Alarm No. Alarm 03 Alarm 01...
-
Page 56: System Settings
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.2. System Settings 6.2.1. LCD backlight Name Setting Range Initial Value Remark Slp t (min) 0-60 Actv. brt. Slp brt. Alm rcvy 6.2.2. Key function Name Setting Range Initial Value Remark FUNC Key Switching of Screen... -
Page 57: Clock
User’s Manual TOHO ELECTRONICS INC. DWG.No.4B-5408 6.2.4. Clock Name Setting Range Initial Value Remark Year (Year) 2000–2099 Month 1-12 1-31 Hour 0-23 Minute 0-59 Second 0-59 6.2.5. Language Name Setting Range Initial Value Remark English Language Japanese Japanese - 52 - www.jetec.com.tw...
