Creative Outdoor Solutions SWIVEL PAD STOOL Assembly Instructions

Step 1
Begin by selecting the bottom frame leg
and the small ring. Spread the frame
apart and position ring holes with frame
holes.
Step 4
Slide the large frame ring over the top
of the already assembled parts, align
bolt holes and lightly hand tighten with
the remaining 4 long bolts and 4 nuts.
Step 7
Offset the top swivel plate from the
bottom to gain access to the bottom
bolt holes and align with holes in the
frame legs. Insert the 4 medium bolts
and secure with the 4 remaining nuts.
Tighten with Phillips screw driver.
HELPLINE 1-949-381-7367
EMAIL SALES@CREATIVEOUTDOORDISTRIBUTOR.COM
ASSEMBLY INSTRUCTIONS
Step 2
Using two of the long bolts and two nuts,
insert and lightly hand tighten, one on
each side.
Step 5
Align bolt holes in top of frame legs and
Insert the short bolt (G) and using one
of the nuts secure and tighten with a
Phillips screw driver. Now tighten all nuts
and bolts with the Phillips screw driver.
Step 8
Turn assembled frame upside down and
place on top of upside down pad. With
swivel plates offset to allow access to
the remaining bolts holes, insert the 4
brass bolts and tighten with Phillips
screw driver.
SWIVEL PAD STOOL
Step 3
Slide the top frame over the top of the
already assembled bottom frame leg and
small ring and using two more long bolts
and two nuts, insert and lightly hand tighten
on the two remaining sides.
Step 6
Slide the large frame ring over the top
of the already assembled parts, align
bolt holes and lightly hand tighten with
the remaining 4 long bolts and 4 nuts.
Step 9
Enjoy!
MADE IN CHINA
