Summary of Contents for Rover Seventy Five

  • Page 1 Owner’s Handbook Instruktieboekje Manuel du Conducteur Betriebsanleitung Manuale di Istruzioni Manual del Conductor Manual do Proprietário...
  • Page 2 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form, electronic, mechanical, recording or other means without prior written permission from Rover Group Limited. As part of Rover Cars environmental policy, this publication is printed on paper made from chlorine free pulp.
  • Page 3 Rover operate a policy of constant product improvement and therefore reserve the right to change specifications without notice at any time. Whilst every effort is made to ensure complete accuracy of the information in this handbook, no liabilities for inaccuracies or the consequences thereof, including loss or damage to property, or injury to persons, can be accepted by the manufacturer or the dealer who supplied the handbook, except in respect of personal injury caused by the negligence of the manufacturer or dealer.

  • Page 4: Table Of Contents

    Contents BEFORE YOU DRIVE MAINTENANCE Controls ........4 Maintenance .......134 Locks & Alarm ......5 Engine Compartment ....139 Seats ..........17 Engine ........143 Seat Belts ........24 Cooling System ......145 Airbag SRS ........30 Brakes ........147 Steering Column ......38 Power Steering ......148 Mirrors ........

  • Page 5: Controls

    Controls BEFORE YOU DRIVE Controls 10 11 12 H2744 1. Passenger airbag SRS 14. Window controls 2. Audio system 15. Boot release 3. Clock 16. Headlight adjuster 4. Horn 17. Instrument dimmer control 5. Direction indicators 18. Cruise control switches 6.

  • Page 6: Locks & Alarm

    Locks & Alarm Locks & Alarm ALARM SYSTEM NOTE: FOR MAXIMUM Your car is fitted with a sophisticated electronic anti-theft SECURITY ALWAYS alarm and engine immobilisation system. There are also a SUPERLOCK THE VEHICLE number of additional security features, some of which are USING THE REMOTE HANDSET selectable options.
  • Page 7 (in the instrument panel) starts to flash. Unlocking With the remote handset: • Press the unlock (Rover) button once. This will disarm the alarm and unlock the driver’s door only (see ‘Single point entry’). • Press the unlock button twice to disarm the alarm and unlock ALL the doors.
  • Page 8 Locks & Alarm Superlocking For safety, NEVER use Provided all the doors are fully closed, the superlocking Superlocking if feature is activated automatically whenever the car is locked passengers are to remain inside using the remote handset. Superlocking immobilises the the car - in an emergency they interior door handles, thereby preventing an intruder from would not be able to escape.
  • Page 9 This feature can be This is a personal security feature, which enables the driver's disabled by a Rover dealer. door alone to be unlocked, leaving the other doors in a locked state. It can be operated by the remote handset as follows: Press the unlock button once (or turn the key in the driver’s...
  • Page 10 This security feature locks all the doors automatically when be selected or deselected the road speed exceeds 4 mph (7 km/h). by a Rover dealer. Note that this feature is not selectable by the driver, and that operation of the door locks by any other means (interior...
  • Page 11 Locks & Alarm Interior space protection Never activate interior space protection if passengers are to be left inside the car - any movement will activate the alarm. H2700 NOTE: Interior space protection Interior space protection (ultrasonics) is designed to protect cannot be activated if a door, the interior of the car from intrusion (entry by a thief through window or sunroof is open, or if...
  • Page 12 The handset contains The battery should last for approximately three years delicate electronic dependent upon use. Always fit a Rover YWK10003 or a circuits and must be protected Panasonic CR2032 replacement battery (available from a from impact and water damage, Rover dealer).
  • Page 13 Locks & Alarm Care point: Finger marks will 4. Fit the new battery, ensuring that correct polarity is adversely affect battery life; if maintained (‘+’ side facing up). possible, avoid touching the flat 5. Press the two halves of the handset firmly together and surfaces of the battery and wipe ensure that both halves are fully joined to prevent dirt or them clean before fitting.
  • Page 14 Rover dealer. NOTE: Rover dealers do not stock If you lose a key, contact your Rover dealer; a key reported spare keys, time has to be lost will be deactivated. If the key is recovered, your Rover allowed for replacements to be dealer can have it reactivated.
  • Page 15 Locks & Alarm LUGGAGE COMPARTMENT Do not drive with the luggage compartment open, as poisonous exhaust gases will enter the car. H2706 To open, turn the key clockwise in the lock or, from inside the car, press the release button in the driver’s footwell. The luggage compartment and interior lights switch on automatically when the boot lid is opened.
  • Page 16 Locks & Alarm CHILD-PROOF LOCKS NEVER leave children unsupervised in the vehicle. H2691 Move the locking levers on the rear doors down to engage the child locks. With the child-proof locks engaged, the rear doors cannot be opened from inside the car, thereby avoiding the risk of a door being opened accidentally while the car is moving.
  • Page 17 Locks & Alarm DOOR LOCKING CUT-OFF SWITCH H2682 Always check for fuel An inertia switch, operational only with the alarm disarmed, leaks before resetting the will unlock the doors in the event of an accident or sudden switch! impact. When the switch operates, the interior lights illuminate until the system is reset by pressing the rubber top (arrowed in illustration).

  • Page 18: Seats

    Seats Seats MANUALLY OPERATED FRONT SEATS Your car is fitted with side Forward/rearward adjustment impact airbags. Refer to the Airbag SRS section of this handbook before fitting seat covers, or carrying out any repair or retrimming operations to the seat or seat covers. H2746 DO NOT adjust the seats Lift the lever and slide the seat into position.
  • Page 19 Seats Backrest adjustment DO NOT allow front seat occupants to travel with the seat backs reclined steeply rearwards. Optimum benefit is obtained from the seat belt with the backrest angle set to approximately 25° from the upright (vertical). H2747 Rotate the handwheel to adjust. Lumbar support adjustment H2748 Rotate the handwheel to increase or decrease support to the...
  • Page 20 Seats HEAD RESTRAINTS Head restraints are designed to restrain rearward movement of the head in the event of an accident or sudden stop - a properly adjusted head restraint can considerably reduce the risk of neck and head injuries. Head restraint adjustment NOTE: Where possible, adjust the head restraint so that the cushion is level with the back of the head...
  • Page 21 Seats POWER-OPERATED FRONT SEATS Your car is fitted with side Seat adjustment is available when the starter switch is in the impact airbags. Refer to second position. the Airbag SRS section of this handbook before fitting seat If the driver’s seat is equipped with the memory facility, it can covers, or carrying out any also be adjusted when the starter switch is in the first position, repair or retrimming operations...
  • Page 22 Seats Seat cushion angle (Driver’s seat only) DO NOT adjust the seats while the car is moving. H2752a Push the front of the switch up or down to tilt the seat cushion to the desired position. Seat cushion height (Driver’s seat only) H2753 Push the switch up or down to raise or lower the cushion.
  • Page 23 Seats Backrest adjustment DO NOT allow front seat occupants to travel with seat backs reclined steeply rearwards. Optimum benefit is obtained from the seat belt, with the backrest angle set to approximately 25° from the upright (vertical). H2754 Twist the switch forward or backwards until the desired angle is achieved.
  • Page 24 Seats DRIVER’S SEAT MEMORY FACILITY DO NOT adjust the seats while the car is moving. Before activating the seat memory and lazy seat functions, ensure that the area immediately surrounding the seat is clear of obstructions and that all occupants are clear of moving parts.

  • Page 25: Seat Belts

    Seat Belts Seat Belts SEAT BELT SAFETY The airbag supplementary The seat belts fitted to your car are intended for use by adult restraint system (SRS) is sized occupants and must be used by one occupant only. designed to add to the overall effectiveness of the seat belts.
  • Page 26 Seat Belts SEAT BELTS Ensure that all seat belts To minimise injury in the event of an accident, it is are worn correctly - an important that seat belts are worn correctly. Read the improperly worn seat belt instructions below and the advice contained under the increases the risk of death or heading ‘Seat belt safety’...
  • Page 27 For optimum protection, it is recommended that children weighing up to 13 kg (29 lb - or approximately 18 months of age) are restrained in a Rover approved rear facing child seat in an outer rear seating position. All infant and child restraint systems are designed to be secured in the car by means of an adult seat belt.
  • Page 28 Seat Belts Seat belt locking mechanism NOTE: The automatic locking All passenger seat belts have a special locking mechanism mechanism should also be used which aids the retention of child seats. The procedure to when securing large items of install a child seat is as follows: luggage to a seat.
  • Page 29 Seat Belts CARING FOR SEAT BELTS Always replace a seat belt Regularly inspect the webbing for signs of fraying, cuts and assembly where the wear, also pay particular attention to the condition of the webbing shows signs of fraying. fixing points and adjusters. Avoid contaminating the webbing with polish, oil and chemicals (see ‘Cleaning &...
  • Page 30 SRS to provide additional protection in the event of a be activated once and then severe frontal, rear or side impact on the vehicle (see ‘Airbag MUST BE REPLACED by a Rover SRS’). The pre-tensioners automatically retract the seat belts. dealer. Failure to replace the...

  • Page 31: Airbag Srs

    Airbag SRS Airbag SRS AIRBAG SRS The airbag SRS provides ADDITIONAL protection in a severe impact only. It does not replace the need to wear a seat belt. H2773 The airbag SRS (supplementary restraint system) incorporates front and side airbags for both the driver and front seat passenger.
  • Page 32 • Non-approved seat covers fitted over a front seat (in particular, be aware that seat covers approved for other cars will NOT be suitable for Rover 75). If in doubt, seek advice from a Rover dealer. Seating positions...
  • Page 33 Airbag SRS HOW THE AIRBAG SRS WORKS In the event of a collision, the airbag control unit monitors the rate of deceleration or acceleration induced by the collision, to determine whether the airbags should be deployed. NOTE: The airbag SRS is not Operation of the airbag SRS is dependent entirely on the rate designed to operate as a result of at which the car’s passenger compartment changes speed as a...
  • Page 34 Airbag SRS An inflating airbag can cause facial abrasions and other injuries. Minimise the risk of injury by ensuring that front seat occupants are wearing their seat belts and are seated correctly, with the seat as far back as is practical. H2774 Airbag inflation is virtually instantaneous and occurs with considerable force, accompanied by a loud noise.
  • Page 35 NEVER be fitted, and it is recommended that any repair or replacement to the front seats be carried out by a Rover dealer (see ’Service information’). H2761 Ensure that a gap is Side airbags are designed to protect the thorax region of the maintained between the torso and will only deploy in the event of a severe side impact.
  • Page 36 In the Rover dealer for examination. event of a severe side collision, the airbag pushes out from behind the roof lining and front pillar finisher as it inflates.
  • Page 37 Airbag SRS CHILD SEATS NOTE: Accident statistics show It is recommended that children should always be seated in that children are safer when the rear of the vehicle, in a child safety seat or restraint system properly restrained in the rear appropriate to their age and size (see ‘Seat belts’).
  • Page 38 SRS), some with any part of the airbag SRS, components will need to be replaced by a Rover dealer, who or wiring in the vicinity of an should stamp and sign the appropriate page of the Service airbag SRS component;...

  • Page 39: Steering Column

    Steering Column Steering Column STEERING COLUMN ADJUSTMENT DO NOT attempt to adjust the height or angle of the steering wheel while the car is in motion. This is extremely dangerous. H2674 Adjust the angle and height of the steering column to suit your driving position: 1.

  • Page 40: Mirrors

    Mirrors Mirrors POWER-OPERATED DOOR MIRRORS NOTE: Objects viewed in exterior mirrors may appear further away than they actually are. H3249 1. Mirror selection switches 2. Mirror glass adjustment switch 3. Mirror fold switch Mirror glass adjustment • With the starter switch turned to the second position, press the appropriate switch to select the left or right mirror.
  • Page 41 Mirrors Mirror folding The body of each door mirror is designed to fold flat against the side of the car on impact. The mirrors can also be folded back manually towards the side windows into a ‘park’ position to enable the car to negotiate narrow openings. H3250 On some cars the ‘park’...
  • Page 42 Mirrors INTERIOR REAR-VIEW MIRROR NOTE: The dipping function of Automatic mirror both mirrors helps to reduce glare from the headlights of following vehicles at night. H2770 The interior mirror is equipped with a light sensor (arrowed) which activates the automatic dipping function. Manual mirror NOTE: In some circumstances, the view reflected in a ‘dipped’...
  • Page 43 Mirrors SUN VISOR VANITY MIRROR The driver’s vanity mirror should only be used when the car is stationary H2666 Pivot the sun visor downward to use the vanity mirror. On some models, the vanity mirror has a cover and is illuminated when the cover is raised.

  • Page 44: Windows

    Windows Windows POWER-OPERATED WINDOW CONTROLS Accidental closing of a power-operated window on fingers, hands or on any other vulnerable parts of the body can result in serious injury. H2688 Driver’s door console NOTE: The front and rear The switches on the driver’s door operate the following: passenger windows can also be 1.
  • Page 45 Windows ‘One-touch’ down By briefly pressing and then releasing a switch (within half a second), a window can be opened at a single touch. Window movement can be stopped at any time by pressing the switch again. ‘One-touch’ up On some models, the driver's door has a ‘one-touch’ up facility which acts in the same way as ‘one-touch’...

  • Page 46: Sunroof

    Sunroof Sunroof SUNROOF OPERATION Accidental closing of a sunroof on fingers, hands or any vulnerable part of the body, can result in serious injury. H2707 NOTE: DO NOT allow passengers The sunroof can be operated when the starter switch is in the to extend any part of their bodies first or second position and for up to 40 seconds after the through the sunroof aperture...
  • Page 47 Sunroof ‘One-touch’ operation Firmly push the switch rearwards and release (the switch will be felt to click into position), the sunroof will fully open. Push the switch firmly forwards and release to fully close the sunroof at a single touch. Sunroof movement can be stopped at any time by briefly pressing the centre of the switch.

  • Page 48: Heating & Ventilation

    Heating & Ventilation Heating & Ventilation HEATING & VENTILATION Care point: Keep the air grille in the rear window shelf uncovered to enable air flow through the whole of the interior. H2782 Care point: Always keep the air The heating and ventilation system provides fresh or heated intake grille clear of obstructions air to the interior of the car from the air intake grille in front such as leaves, snow or ice.
  • Page 49 Heating & Ventilation Control panel H2771 1. Air temperature control • BLUE: Unheated air • RED: Heated air NOTE: When distributing air to 2. Air distribution control the face level vents, they must be Face level vents only. FULLY open to ensure best performance.
  • Page 50 Heating & Ventilation With air conditioning switched off (and on cars not equipped with air conditioning), air recirculation will automatically switch off after 4 minutes operation. This reduces the risk of misting windows. To override this timed feature, press and hold the recirculation button for 2 seconds (until the light in the switch flashes) - but note that the function must then be switched off manually.
  • Page 51 Heating & Ventilation Operating advice The following procedures will enable you to gain maximum benefit from the heating and ventilation system: To achieve maximum demisting/defrosting • Select ‘windscreen’ on the air distribution control. • Turn the air temperature control to the RED segment. •...
  • Page 52 Heating & Ventilation Heater bypass control H2861 Air supply from the face level vents is further controlled by the heater bypass control in the centre of the fascia panel. The purpose of this feature is to enable cooler air to be directed towards the face at those times when the heater is required to provide hot air in order to keep the interior of the car warm - particularly useful during winter.
  • Page 53 Heating & Ventilation Particle/pollen filter/odour filter A particle filter will help to keep the car interior free from pollen and dust. To remain fully effective, the filter should be replaced every 2 years or 30,000 miles (50,000 km), at the time of a oil service or inspection.
  • Page 54 Heating & Ventilation AUTOMATIC TEMPERATURE CONTROL (ATC) TEMP H2734a Auto mode In brief • Press the ’AUTO’ button for fully automatic operation. NOTE: An enclosed area in the centre of the display will show • Press the temperature control switches to select the ‘AUTO’, together with the required temperature (see ‘Temperature control’) - a temperature, air distribution and...
  • Page 55 Heating & Ventilation Temperature control NOTE: The temperatures shown Operate the rocker switches on either side of the display to set on the display are target the required temperature for the corresponding side of the temperatures only and are not passenger compartment (left hand switch for the left side of reflective of any specific the car, and right hand switch for the right side).
  • Page 56 Heating & Ventilation Blower control NOTE: If the air distribution and Use the control to adjust the blower speed. Press blower controls are operated the ‘+’ symbol to increase, and the ‘-’ symbol to independently, the system may decrease blower speed. The display will show a number of not be able to achieve or maintain segments which represent the blower speed (0 - 6 segments).
  • Page 57 Heating & Ventilation Heated rear screen NOTE: The heated rear screen will The heated rear screen will switch on automatically not operate unless the engine is for 20 minutes if the engine is started when the running. outside temperature is less than 10° C (50° F). The heated rear screen will also operate automatically in association with the automatic temperature control.

  • Page 58: Interior Equipment

    Interior Equipment Interior Equipment FRONT COURTESY AND MAP READING LIGHTS H2675 Manual operation Press the appropriate switch to turn the courtesy or map reading lights on, press again to turn off. The front courtesy light switch (arrowed) will also operate the rear courtesy lights.
  • Page 59 Interior Equipment REAR COURTESY AND MAP READING LIGHTS H2677 The rear courtesy lights will illuminate and extinguish automatically in conjunction with the front courtesy lights. Press the appropriate switch to illuminate the relevant map reading light - press again to switch off. GLOVEBOX H2690 Lift the lever to open.
  • Page 60 Interior Equipment CLOCK 11 12 H2678 NOTE: The clock will need to be To adjust the time, use a ball point pen or similar probe to reset if the battery has been advance or put back the time, using the right or left hand disconnected.
  • Page 61 - withdrawn for use. consult your Rover dealer). The cigar lighter cover will not close again until it has been allowed to open fully.
  • Page 62 Interior Equipment ASHTRAYS Ashtrays are fire hazards - Front ashtray DO NOT use for waste paper or other combustible materials. H2730 Press the leading edge of the ashtray to open. To empty the front ashtray, press the tray eject catch (see inset) and lift the inner tray from the surround.
  • Page 63 Interior Equipment CUBBY BOX H2697 NOTE: If an auxiliary power Lift the release catch (arrowed) to open the lid. The cubby socket is fitted to the vehicle, it box is designed to securely hold tapes or compact discs. will be located in the cubby box. REAR ARM REST STOWAGE H2718 Lift catch (arrowed) to open.
  • Page 64 Interior Equipment CUP HOLDERS Front cup holder The cup holder should not be used while the car is in motion. H2720a Press the passenger side panel to open. Rear cup holder H2729 Press the front of the cup holder to open.
  • Page 65 Interior Equipment REAR SUNBLIND NOTE: The rear sunblind helps reduce rear seat passenger discomfort from sun glare. H2779 Ensure that passengers Press to raise or lower the blind. are warned to keep clear of the sunblind while it is being operated.

  • Page 66: Audio System

    Audio System Audio System REMOTE AUDIO CONTROLS H2724 NOTE: Full operating instructions Volume control for any audio equipment fitted as Lift or press down to increase or decrease volume. standard to your car, are contained in the ‘ Audio & Mode select control Navigation System’...

  • Page 67: In-Car Telephones

    In-Car Telephones In-Car Telephones IN-CAR TELEPHONES Refrain from operateing a Your car uses a number of electronic systems designed to telephone fitted with its provide you with maximum comfort, safety and economy. own aerial inside the car (see These systems may be affected by the use of non-approved main text).

  • Page 68: Load Carrying

    Load Carrying Load Carrying FOLDING THE REAR SEATS DO NOT carry objects on DO NOT carry unsecured equipment, tools or luggage that the rear shelf - they could could move, causing personal injury in the event of an become dangerous projectiles accident, or emergency manoeuvre - where possible, use the in the event of an accident.
  • Page 69 Load Carrying CARRYING LONG LOADS Ensure that all long loads which project into the passenger compartment are securely restrained. H2725 On some models, a fold down hatch is fitted in the middle of the rear seat. This enables longer loads to be carried at the same time as two rear passengers.
  • Page 70 Only fit towing To ensure absolute safety, only fit accessories that have been accessories and roof designed and tested for your car. Your Rover dealer will racks that have been approved provide details of approved tow bars and roof racks.
  • Page 71 Rover 75 is fitted and that it is fitted by qualified personnel. H3001 The mounting points...

  • Page 72: Towing

    Towing Towing TOWING A TRAILER NOTE: Towing regulations vary from country to country. It is very important to ensure that national regulations governing towing weights and speed limits are observed (refer to the relevant national motoring organisation for information). The maximum permissible towed weights quoted in ‘Technical Data', refer to the car's design limitations...

  • Page 73: Driving Controls Instruments

    Instruments DRIVING CONTROLS Instruments INSTRUMENT PANEL 100 120 140 160 KM/H H2760 Diesel model illustrated 1. Temperature gauge 2. Tachometer 3. Speedometer 4. Fuel gauge 5. Total distance and trip recorder (odometer) 6. Trip recorder reset button Temperature gauge This gauge indicates the temperature of the engine coolant. As the engine warms up, the pointer will rise to the mid-point of the gauge, where it should remain while the engine is operating at its normal temperature.
  • Page 74 Instruments Fuel gauge The pointer falls to zero when the starter switch is turned off, but quickly rises to show the level of fuel in the tank when the switch is turned to the second position. Never allow the car to run An indicator light in the fuel gauge will illuminate when the out of fuel - the resultant fuel level is low (approximately 9 litres remaining) - if the...
  • Page 75 Instruments TRIP RECORDER H2793 The instrument panel features an LCD display located at the bottom centre which provides information about the following functions: 1. Digital odometer 2. Trip recorder 3. Service interval display 4. Gear display (automatic transmission only) 5. External temperature Digital odometer When the engine is switched off (starter switch in the off position), the display remains in the standby mode.
  • Page 76 Instruments Service interval display NOTE: After the completion of This shows the distance remaining before the next oil service each service, the dealer will reset or inspection is due. When the starter switch is initially turned the distance display, to to the second position, the service type and remaining commence the countdown to the distance are displayed for approximately four seconds, after...

  • Page 77: Trip Computer

    Trip Computer Trip Computer TRIP COMPUTER - FUNCTION SELECTION H2802 The trip computer utilises the message centre on the highline instrument pack only and provides valuable information to assist the driver to calculate fuel stops, journey times and distances. When the starter switch is in the second position, the different trip computer functions can be selected by pressing the button on the end of the left-hand column stalk.
  • Page 78 Trip Computer When a trip computer feature is selected, it will be displayed until switched off or until another trip computer feature is selected. However, note that the message centre is also used to display warning messages and these will automatically override the trip computer display (see ‘Warning messages’...
  • Page 79 Trip Computer Overspeed (‘Speed limit’) The overspeed warning function is an aid to keeping within speed limits set by the driver. Press and hold the trip computer button to increase the set speed by increments of 5 mph (5 km/h). Whenever the set speed is exceeded an audible warning will sound and the set speed will be displayed in the message centre.

  • Page 80: Warning Lights

    Warning Lights Warning Lights WARNING LIGHT POSITION AND OPERATION H2791 The standard instrument panel features two main clusters of warning lights, one situated in the centre of the pack (1) and the other located at the upper centre of the instrument pack (2).
  • Page 81 Rover dealer at the earliest opportunity. If an ABS fault occurs while driving, the ABS warning light will be illuminated and ABS operation will be suspended but normal braking will still be available. Consult your Rover dealer at the earliest opportunity. Main beam - BLUE Illuminates when the headlights are switched to main beam.
  • Page 82 Warning Lights Check engine - YELLOW (petrol models only) This warning light is used to indicate faults detected by the engine management system. The ‘Check engine’ indicator illuminates as a system check when the starter switch is turned to the second position and should extinguish when the engine is started.
  • Page 83 Warning Lights Cruise Control - YELLOW Illuminates when cruise control is active and extinguishes when cruise control is cancelled. Airbag SRS - RED The light illuminates when the starter switch is turned to the second position and extinguishes after about four seconds. If the light illuminates at any other time or stays permanently lit at start up, an airbag restraint system fault has been detected, seek qualified assistance urgently.

  • Page 84: Front Fog Lights

    Warning Lights UPPER CENTRE CLUSTER WARNING LIGHTS - (standard instrument panel only) H3253 Front fog lights - GREEN The front fog warning light is illuminated whenever the front fog lights are switched on. Door open - RED Illuminates when any of the doors (including the boot and bonnet) are not fully closed.
  • Page 85 Warning Lights Bulb failure - YELLOW This warning light illuminates if a bulb failure is detected on an exterior light whenever the relevant circuit has been switched on (eg. brake lights, headlights, sidelights etc.). Check which light is not operating and replace the bulb.
  • Page 86 Warning Lights Engine malfunction - YELLOW (diesel models only) Illuminates as a bulb check when the starter switch is turned to the second position. Also illuminates as a warning while driving if an engine malfunction is detected. If this occurs, the car can still be driven, but engine power will be reduced.

  • Page 87: Message Centre

    Message Centre Message Centre MESSAGE CENTRE DISPLAY On instrument packs that incorporate a message centre, information concerning various aspects of the car’s status is displayed by a combination of icons and words in the display at the upper centre of the instrument panel. Bonnet open - RED A large vehicle icon showing the bonnet open with the words ‘BONNET OPEN’...
  • Page 88 Message Centre Bonnet/boot open - RED Small icon used to warn that the bonnet or boot is still open after the main warning display has timed out. Close the bonnet/boot securely before attempting to drive the car. Door open - RED A large vehicle icon showing the relevant door opened with the words ‘DOOR OPEN’...
  • Page 89 Message Centre Sidelight fail - YELLOW A large vehicle icon with an active sidelight with the message ‘SIDE LIGHT FAIL’ is displayed. The icon shows a sidelight on the same side of the car as the bulb failure. The message will be displayed for approximately 4 seconds after selection of the lighting circuit.
  • Page 90 Message Centre Number plate light fail - YELLOW NOTE: A number plate light A large vehicle icon with an active number failure is only detected if both plate light with the message ‘NO. PLATE bulbs have failed. LIGHT’ is displayed. The message will be displayed for approximately 4 seconds after turning on the side or headlights.
  • Page 91 ‘ABS FAULT’. If an ABS fault occurs while driving, the ABS warning light illuminates and ABS operation will be suspended. However normal braking will still be available. Consult your Rover dealer at the earliest opportunity. No battery charge warning - RED...
  • Page 92 Message Centre Low oil pressure - RED This message is displayed (together with the dedicated warning light in the centre cluster of the instrument panel) when engine oil pressure is dangerously low and liable to result in engine damage. The icon is displayed with the message ‘LOW OIL PRESSURE’.
  • Page 93 Message Centre Airbag SRS malfunction - RED This message is displayed (together with the dedicated warning light in the centre cluster of the instrument panel) to alert the driver of a SRS system failure. The icon appears with the message ‘AIRBAG FAULT’...
  • Page 94 Message Centre Trailer light fail - YELLOW This warning message only functions when a towed vehicle has been electrically connected to the car’s exterior light circuit using the dedicated socket. The warning message will be displayed if a bulb failure has been detected on the towed vehicle. The icon is displayed with the message ‘BULB FAILURE’.
  • Page 95 Message Centre Low battery mode - YELLOW Displayed when the battery voltage is less than 10V and extinguishes when the battery voltage rises above 11V. The display is extinguished during engine cranking and for a further five seconds after cranking. The icon is displayed with the message ‘LOW BATTERY’.

  • Page 96: Starting & Driving

    Starting & Driving Starting & Driving STARTER SWITCH Once the steering lock is engaged, it is impossible to steer the car. DO NOT remove the key or turn the starter switch off while the car is in motion. H2685 The starter switch is located to the right of the steering column and uses the following sequence of key positions to operate the steering lock, electrical circuits and starter motor: Position O...
  • Page 97 Starting & Driving Unlocking the steering After inserting the key, a small movement of the steering wheel while turning the starter switch to the first position will help to disengage the steering lock. Locking the steering After removing the key, turn the steering wheel towards the kerb until the lock engages.
  • Page 98 Starting & Driving DIESEL MODELS Never start, or leave the Starting the engine engine running, in an 1. Check that the handbrake is applied and that the gear unventilated building - exhaust lever is in neutral (‘P’ or ‘N’ for automatic transmission). gases are poisonous and 2.
  • Page 99 Starting & Driving ALL MODELS Cold climates Operating tip: When starting In temperatures of -10° C (14° F) and below, engine cranking manual transmission vehicles in times will increase. As the starter motor may need to operate freezing condition or when the for longer, it is essential that all unnecessary electrical battery is in a low state of charge, equipment is switched off while cranking.

  • Page 100: Environmental Driving

    In a great many respects, however, criticism of the car and its manufacturer is misplaced, for few industries have done more to reduce pollution than the motor industry. Rover is no exception. Your new Rover 75 has been designed with the latest technology in order to minimise the environmental impact of exhaust emissions.
  • Page 101 Environmental Driving • Do not drive in a low gear for longer than necessary Driving in lower gears uses more fuel and creates more noise. Change up to a higher gear as soon as possible, provided it does NOT cause the engine to labour. •...

  • Page 102: Catalytic Converter

    Catalytic Converter Catalytic Converter CATALYTIC CONVERTER Exhaust temperatures can be extremely high, do not park on ground where combustible materials such as dry grass or leaves could come into contact with the exhaust system - in dry weather a fire could result.
  • Page 103 Service Portfolio book. operating temperature, it may be driven SLOWLY (at risk of catalyst damage) to a Rover dealer. • Do not run the engine with a spark plug or lead removed or use any device that requires an insert into a spark plug.

  • Page 104: Automatic Transmission

    Automatic Transmission Automatic Transmission GEAR SELECTOR H2738 NOTE: A light on the selector The automatic transmission features a five speed gearbox with display and a number or letter on three manually selectable modes (Normal (economy), Sport the trip recorder display, and Snow mode).
  • Page 105 Automatic Transmission Selector lever positions • ‘P’ Park Always leave the car with the gear selector in ’P’ In this position the transmission is locked to prevent the (Park) position when parked. car from rolling away. Select ONLY when the car is stationary and with the handbrake applied.
  • Page 106 Automatic Transmission Using the automatic transmission The following information is important - particularly for drivers who are unused to driving cars with automatic transmission. • Before starting the engine, ensure that both foot brake and handbrake are applied. • After starting the engine, KEEP BOTH BRAKES APPLIED before and whilst moving the selector lever to the required drive position.
  • Page 107 Automatic Transmission MODE SWITCH H2756 The automatic gearbox has three driver-selectable operating modes, Normal (economy), Sport and Snow. When the starter switch is turned on, the transmission automatically selects the Normal (economy) mode. Normal (economy) mode Normal mode is suitable for all day to day driving and optimises fuel consumption and exhaust emissions.
  • Page 108 On Rover 75 however, the hill descent mode provides engine braking by causing the transmission to automatically change to a lower gear on steep downhill gradients, provided the following criteria occur: •...
  • Page 109 Automatic Transmission • Cold start mode In very cold conditions the automatic transmission will stay in the lower gears for longer, to help the engine reach its normal operating temperature more quickly. This will help to improve overall fuel economy and driveability, and reduce emissions.

  • Page 110: Manual Gearbox

    Manual Gearbox Manual Gearbox GEAR LEVER H2667 The gear positions are indicated on the gear lever knob. Synchromesh is provided on all gears (including reverse). In the neutral position, the gear lever is spring loaded to rest naturally in the centre of the gate between 3rd and 4th gears. Precautions while driving •...

  • Page 111: Fuel System

    Fuel System Fuel System FUEL FILLER H2717 Fuel filler flap NOTE: The fuel flap is locked only The fuel filler flap is located on the rear right-hand wing and when the car is locked using the is linked to the central door locking system. With the car handset (locking the car with the unlocked, push on the right-hand side of the flap to open.
  • Page 112 If in doubt, consult a Rover dealer for advice. The RON value quoted alongside is a MINIMUM requirement for the United Kingdom and most European markets and can be safely exceeded.
  • Page 113 • Petrol engine: Start the engine carefully after refuelling. If the engine runs unevenly, switch off and contact your Rover dealer before attempting to restart the engine. • Diesel engine: The fuel system will prime automatically and the engine can be started.
  • Page 114 Fuel System FUEL CUT-OFF SWITCH ALWAYS check for fuel leaks before resetting the fuel cut-off switch. H2682 The fuel cut-off switch is a safety device which, in the event of a collision or sudden impact, automatically cuts off the fuel supply to the engine.

  • Page 115: Lights & Indicators

    Lights & Indicators Lights & Indicators LIGHTING SWITCH NOTE: If the lights (other than parking lights and headlight courtesy delay) are left on after the starter switch has been turned off, a warning chime will sound when the driver’s door is opened, until either the lights are turned off, or the door is closed.
  • Page 116 Lights & Indicators FOG LIGHTS Fog lights should ONLY be used when visibility is severely restricted - other road users could be dazzled in clear conditions. H2792 Operating tip: Both the rear and Rear fog guard lights front fog lights are switched off Press the switch (1) to switch on and off;...
  • Page 117 Lights & Indicators HAZARD WARNING LIGHTS H2732 Press to operate. All the direction indicators and direction indicator warning lights will flash together. Use only in an emergency to warn other road users when your car is causing an obstruction or is in a hazardous situation. Remember to switch off before driving away.

  • Page 118: Direction Indicators (Amber)

    Lights & Indicators DIRECTION INDICATOR LEVER Take care not to dazzle oncoming vehicles when driving using main beam headlights. H2681 Direction indicators Operating tip: Hold the direction Move the lever down to indicate a LEFT turn, or up to indicator lever half way up or indicate a RIGHT turn.
  • Page 119 Lights & Indicators Parking lights The near or off-side tail lights and side lights can be switched on independently for parking purposes, as follows: With the starter switch turned off, move the direction indicator lever fully DOWN to switch on the left hand parking lights.
  • Page 120 Lights & Indicators HEADLIGHT BEAM HEIGHT ADJUSTER H2715 The angle of the dipped beams is affected by the distribution of passenger and luggage weight within the car. It is important that the headlights are adjusted to ensure that the point at which they meet the road surface provides adequate illumination ahead of the vehicle, without dazzling other road users.

  • Page 121: Horn

    Horn Horn HORN H2726 To operate, press either of the horn switches set into the steering wheel pad.

  • Page 122: Wipers & Washers

    - any increase in speed will decrease the delay. Auto-park Auto-park can be selected If the starter switch is turned off while the wipers are or deselected by a Rover operating, the wipers will continue operating until the parked dealer. position is reached.
  • Page 123 Note that the wipers continue operating for a further three be adjusted to either 2 or 4 wipes after the lever is released. by a Rover dealer. If the washers fail to deliver the screen wash solution (dirt or ice may have blocked the jets), release the lever immediately.

  • Page 124: Cruise Control

    Cruise Control Cruise Control CRUISE CONTROL H2689 Operating tip: Use of ‘sport’ Cruise control enables the driver to maintain a constant road mode on automatic gearbox speed without using the accelerator pedal. This is particularly vehicles is not recommended useful for motorway cruising, or for any journey where a when cruise control is selected.
  • Page 125 Cruise Control To operate cruise control The cruise control system has three switches; a master switch on the centre console and two control switches marked ‘SET+’ and ‘RES’ mounted on the steering wheel. 1. Press the master switch (the switch indicator light and the warning light in the instrument panel illuminate whenever cruise control is operating).

  • Page 126: Brakes

    Brakes Brakes FOOT BRAKE NOTE: DO NOT rest your foot on For added safety, the hydraulic braking system operates the brake pedal while driving; this through dual circuits. If one circuit should fail, the other will may overheat the brakes, reduce continue to function, but increased brake pedal travel, greater their efficiency and cause pedal pressure, and longer stopping distances will be...
  • Page 127 Brakes remains illuminated for more than three seconds after the starter switch is turned on, there is a fault with the braking system, and EBD may not be available. If this occurs, stop the car as soon as safety permits and seek qualified assistance immediately.
  • Page 128 Brakes HANDBRAKE DO NOT drive with the handbrake applied, or apply the handbrake while the car is in motion; this could result in loss of control, prevent the anti-lock braking system from functioning correctly, and may even cause damage to the rear brakes.
  • Page 129 Brakes ANTI-LOCK BRAKES ABS cannot overcome the The purpose of the anti-lock braking system (ABS) is to physical limitations of prevent the wheels from locking while braking, thereby stopping the car in too short a enabling the driver to retain steering control of the car. distance, cornering at too high a speed, or the danger of Under normal braking conditions, (where sufficient road...
  • Page 130 Brakes Braking in an emergency DO NOT pump the brake If an emergency situation occurs, the driver should apply full pedal at any time; this will braking effort even when the road surface is slippery. The interrupt operation of the ABS anti-lock braking system will constantly monitor the and may increase braking rotational speed of the wheels and vary braking pressure to...

  • Page 131: Traction Control

    Traction Control Traction Control ELECTRONIC TRACTION CONTROL NOTE: The individual wheel The purpose of electronic traction control is to aid traction, braking feature of the traction thereby helping the driver to maintain control of the car in control system will not operate at situations where one or both of the driving wheels are road speeds above 62 mph (100 spinning (for example, if one wheel is on ice and the other on...
  • Page 132 Traction Control Warning light On cars equipped with the standard instrument panel (no message centre), the light flashes while the traction control system is operating (cars equipped with a message centre, feature a traction control message, which appears for a minimum of 4 seconds). The light also illuminates as a bulb check (for approximately 3 seconds) when the starter switch is turned on and illuminates continuously whenever traction control is...

  • Page 133: Parking Aid

    Parking Aid Parking Aid PARKING AID The parking aid is not infallible. It is for 5 feet (1.5m) guidance only! The sensors may not be able to detect certain 14in (35cm) types of obstruction, eg. narrow posts or small objects no more than a few inches wide, small objects close to the ground, objects above the level of the...
  • Page 134 Parking Aid Parking aid in operation Operating tip: Reduce the radio With the starter switch turned to the second position, the volume while reversing - loud parking aid operates automatically whenever reverse gear is audio sounds may ‘drown’ the selected and is switched off as soon as reverse is deselected. warning chimes.

  • Page 135: Maintenance

    Maintenance MAINTENANCE Maintenance ROUTINE SERVICING The safety, reliability and performance of your car will depend partly on how well it is maintained. Maintenance is the owner’s responsibility and you must ensure that owner maintenance operations, oil services, inspections and brake fluid and coolant changes are carried out when required and according to the manufacturers’...
  • Page 136 The engine coolant (anti-freeze and water solution) needs to be replaced every four years regardless of the distance the car has travelled. Your Rover dealer will replace the coolant at the scheduled oil service or inspection nearest to the conclusion of each four year period, to avoid the need for an additional dealer visit.
  • Page 137 Maintenance EMISSION CONTROL Your car is fitted with emission and evaporative control equipment designed to meet specific territorial and legal requirements. You should be aware that unauthorised replacement, modification or tampering with this equipment by an owner or motor vehicle repairer could be unlawful and subject to legal penalties.
  • Page 138 If your car is frequently used in dusty conditions, or operated in extreme climates where sub-zero or very high ambient temperatures are normal, more frequent attention may need to be paid to servicing requirements. Contact a Rover dealer for advice.
  • Page 139 Maintenance SAFETY IN THE GARAGE Cooling fans may If you need to carry out maintenance, observe the following commence operating after safety precautions at all times: the engine is switched off, and • Keep your hands and clothing away from drive belts and continue operating for a number pulleys.

  • Page 140: Engine Compartment

    Engine Compartment Engine Compartment BONNET OPENING DO NOT drive with the bonnet retained by the safety catch alone. H2679 1. From inside the car, pull the bonnet release handle. 2. Lift the bonnet safety catch lever and raise the bonnet. Closing the bonnet Lower the bonnet.
  • Page 141 Engine Compartment UNDERBONNET LOCATIONS 1.8 petrol engines While working in the engine compartment, always observe the safety precautions listed under ‘Safety in the garage’ on a previous page. H2780 1. Brake reservoir (black cap) 2. Power steering reservoir (black cap) 3.
  • Page 142 Engine Compartment 2.0 & 2.5 petrol engines While working in the engine compartment, always observe the safety precautions listed under ‘Safety in the garage’ on a previous page. H2709 1. Brake reservoir (black cap) 2. Engine oil dipstick (yellow) 3. Engine oil filler (yellow cap) 4.
  • Page 143 Engine Compartment Diesel engines While working in the engine compartment, always observe the safety precautions listed under ‘Safety in the garage’ on a previous page. H2710 1. Brake reservoir (black cap) 2. Engine oil filler (yellow cap) 3. Engine oil dipstick (yellow) 4.

  • Page 144: Engine

    Engine Engine ENGINE OIL Operating tip: Check the oil level Check the oil level weekly, or whenever you fill up with fuel. when you fill up with fuel (refuel Ideally the oil level should be checked with the engine hot first, then check the oil - this will and the car resting on level ground.
  • Page 145 Engine H2672 Diesel engines Care point: Take care to avoid 1. Withdraw the dipstick and wipe the blade clean. spilling engine oil onto a hot 2. Slowly insert the dipstick and withdraw again to check engine - a fire may result! the level, which should NEVER be allowed to fall below the lower mark on the dipstick.

  • Page 146: Cooling System

    Cooling System Cooling System COOLANT CHECK & TOP-UP DO NOT remove the The coolant level should be checked weekly when the reservoir cap when the cooling system is cold and with the car resting on level cooling system is hot - escaping ground.
  • Page 147 - top-up the cooling system with clean water, but be aware of the resultant reduction in frost protection. DO NOT top-up or refill with other anti-freeze formulations. If in doubt consult a Rover dealer. IMPORTANT: Cooling System draining and re-filling are service operations that require detailed product knowledge and should only be carried out by qualified personnel according to the processes described in the workshop manual.

  • Page 148: Brakes

    Brakes Brakes BRAKE FLUID Brake fluid is highly toxic - The level of fluid in the brake reservoir may fall slightly keep containers sealed during use, as a result of brake pad wear and will need to be and out of the reach of children. topped-up from time to time.

  • Page 149: Power Steering

    Power Steering Power Steering POWER STEERING FLUID If power steering fluid If the power steering is operating correctly, there will be little should come into contact or no requirement to top-up the reservoir. Any frequent or with the skin or eyes, rinse regular need to top-up the fluid should be investigated by a immediately with plenty of qualified dealer.
  • Page 150 Power Steering Check & Top-up Fluid specification: Use any fluid to Dexron III specification. Fluids manufactured to this specification are suitable for use in temperatures between -20° C to +30° C (if climatic temperature falls outside these limits, seek advice from your dealer). H2683 Care point: Take care not to spill Check the fluid level every week.

  • Page 151: Battery

    Battery Battery BATTERY MAINTENANCE H2743 To access the battery, unclip and remove the battery cover as shown in illustration. Operating tip: If necessary, clean The battery is designed to be maintenance free, so topping-up the top of the battery to ensure a is unnecessary.
  • Page 152 Battery Battery safety Remove any metal wrist Batteries contain sulphuric acid, which is both corrosive and bands and jewellery poisonous. If spillage occurs: before working in the engine • On clothing or the skin - remove any contaminated compartment. clothing immediately, flush the skin with large amounts of water, and seek medical attention urgently.
  • Page 153 (the front facing vent environment, and should be hole is identified with an arrow in the previous illustration). recycled. If in doubt seek advice about disposal from a Rover dealer or your local authority.
  • Page 154 Battery Battery charging DO NOT charge the battery As the battery ages, it may not retain its charge as effectively if it is suspected of being as when it was new. Cars that are used infrequently, or are frozen. used excessively for short journey motoring, or operation in cold climates, may need the battery to be charged regularly.

  • Page 155: Washers

    Washers Washers WINDSCREEN WASHER TOP-UP DO NOT use an anti-freeze or vinegar/water solution in the washer reservoir - anti-freeze will damage painted surfaces, while vinegar can damage the windscreen washer pump. H2684 Some Screenwash The windscreen washer reservoir supplies both front screen products are washer jets and headlight washer jets (where fitted).

  • Page 156: Wipers

    Wipers Wipers WIPER BLADES Care point: Clean the windscreen Grease, silicon and petrol based products impair the blade’s regularly with an approved glass wiping capability. Wash the wiper blades in warm soapy cleaner and ensure the screen is water and periodically check their condition. thoroughly cleaned before fitting replacement wiper blades.

  • Page 157: Tyres

    Tyres Tyres CARING FOR YOUR TYRES Care point: If possible, protect Always drive with consideration for the condition of the tyres from contamination by oil, tyres, and regularly inspect the tread and side walls for any sign grease, fuel and other automotive of distortion (bulges), cuts or wear.
  • Page 158 Tyres Tyre wear indicators H2703 Tyres fitted as original equipment have wear indicators moulded into the tread pattern at several points around the circumference. When the tread has worn down to 1.6 mm, the indicators will come to the surface of the tread pattern, producing the effect of a continuous band of rubber across the width of the tyre.
  • Page 159 195/65 R15 tyres on 6J wheels, and only fit chains that have been recommended by a Rover dealer and approved by Rover for use on your car. Care point: Avoid tyre damage...

  • Page 160: Cleaning & Vehicle Care

    Cleaning & Vehicle Care Cleaning & Vehicle Care WASHING YOUR CAR Some high pressure cleaning systems will penetrate door, window and sunroof seals, and damage lock mechanisms. DO NOT aim water jets directly at components that might be easily damaged. H2669 In order to preserve the paint finish on your car, please observe the following care points:...
  • Page 161 Body protection After washing, examine the paintwork for damage. Treat paint chips and scratches with a Rover paint touch-up pencil. If the damage has revealed bare metal, use a coloured primer first, then apply the correct colour base coat and finish off with a lacquer pencil, if appropriate.
  • Page 162 Cleaning & Vehicle Care Windows and mirrors Regularly clean all windows, inside and out, using an approved glass cleaner. Windscreen: In particular, clean the outside of the screen with glass cleaner after washing the car with wash and wax products, and before fitting new wiper blades. Care point: DO NOT scrape or Rear screen: Clean the inside with a soft cloth, using a side to use abrasive cleaners on the...
  • Page 163 Cleaning & Vehicle Care CLEANING THE INTERIOR Care point: DO NOT polish Plastic materials dashboard components - these Clean plastic-faced materials with diluted upholstery cleaner, should remain non-reflective. then wipe with a damp cloth. Carpet and fabrics Clean with diluted upholstery cleaner - test a concealed area first.

  • Page 164: Emergency Information Wheel Changing

    Wheel Changing EMERGENCY INFORMATION SPARE WHEEL AND TOOLS Wheel Changing NOTE: The spare wheel supplied with your car will vary according to model specification: space saver steel, or regulation steel. H2723 1. Remove the carpeted panel from the floor of the boot. 2.
  • Page 165 Wheel Changing CHANGING A WHEEL NOTE: Switch on the hazard If possible, choose a safe place to stop away from the main warning lights to alert other road thoroughfare. Always ask your passengers to get out of the car users. and wait in a safe area away from other traffic.
  • Page 166 Wheel Changing Positioning the jack NEVER work beneath the car with the jack as the only means of support. The jack is designed for wheel changing only! H2722 Never jack the car using Position the jack on firm level ground under the jacking point any jacking points other nearest the wheel to be removed.
  • Page 167 Wheel Changing Changing the wheel Avoid accidental contact 1. Before raising the car, use the wheel wrench to slacken with any underbody parts, each of the wheel bolts half a turn anti-clockwise (refer especially hot exhaust system to the pages that follow for information about locking components.
  • Page 168 Wheel Changing LOCKING WHEEL BOLTS H2757 NOTE: A code number is stamped Cars with alloy wheels are fitted with one locking wheel bolt on the underside of the adaptor. to each wheel. These are similar to standard wheel bolts, but Ensure the number is recorded have a removable cap (1) and can only be removed using the on the Security Information card...

  • Page 169: Emergency Starting

    Emergency Starting Emergency Starting USING BOOSTER CABLES During normal use, Using booster cables (jump leads) from a donor batteries emit explosive battery, or a battery fitted to a donor vehicle, is the hydrogen gas, sufficient to only approved method of starting a car with a flat cause severe explosions battery.
  • Page 170 Emergency Starting H2860 2.0 & 2.5 petrol engines DO NOT disconnect the If the battery from a donor vehicle is to be used, the vehicles discharged battery. Make should be parked with their battery locations adjacent to one sure that BOTH batteries are of another.
  • Page 171 Emergency Starting 5. Once both engines are running normally, allow them to idle for two minutes before switching off the engine of the donor vehicle and disconnecting the booster cables. DO NOT switch on any electrical circuits on the previously disabled vehicle, until AFTER the booster cables have been removed.

  • Page 172: Vehicle Recovery

    Vehicle Recovery Vehicle Recovery TOWING EYES DO NOT use either towing point to tow a trailer or caravan. H2671 H2670 Operating tip: The front towing Your car is equipped with a fixed towing point at the rear of eye cover may be secured to the the car and a removable towing eye at the front.
  • Page 173 Vehicle Recovery TOWING FOR RECOVERY If your car is to be towed, most qualified recovery specialists will use wheel lift equipment to suspend the front wheels, while the rear wheels remain on the ground. However, if it is necessary for the car to be towed with all four wheels on the ground, abide by the following procedure.
  • Page 174 Vehicle Recovery Transporter or trailer lashing DO NOT use the lashing points to tow your car behind another vehicle, or use the lashing points to tow a trailer or caravan. H2788a If your car is to be transported on the back of a trailer or transporter, use the recommended lashing points at the front and rear of the car only.

  • Page 175: Fuses

    Fuses Fuses PASSENGER COMPARTMENT FUSE BOX H2727 Operating tip: A coin or The passenger compartment fuse box is located behind the flat-bladed screwdriver is needed front passenger glove box. to remove the closure panel beneath the glovebox in order to Fuses be able to access the fuse box.
  • Page 176 Fuses Checking or renewing a fuse H3252 NOTE: Turn off the starter switch 1. Turn off the starter switch and all electrical equipment. and all electrical equipment 2. Remove the fuse box cover (depress the two catches before changing a fuse. arrowed in illustration on the previous page), then refer to the chart to identify the suspect fuse.
  • Page 177 Fuses Fuse specifications Fuse number Rating (AMPS) Circuit protected Rear windows Traction control Memory seats, clock Air conditioning, power windows Body Control Unit, wipers Instrument pack Immobilisation, cruise control Body Control Unit Windscreen washer pump Instrument pack Audio system, power windows, mirrors, cigar lighter Accessories socket, rear sunblind, parking aid Interior lamps Central door locking...
  • Page 178 Fuses Fuse number Rating (AMPS) Circuit protected Engine management Heated mirrors & washer jets Alternator Not used Not used Not used Exterior lights Cruise control, reversing lights Not used...
  • Page 179 Fuses ENGINE COMPARTMENT FUSES H3258 The fuse box is located on the left hand side of the engine compartment. Press the catch (arrowed in illustration) to release the hinged cover. Owners are advised against removing or replacing the fusible links identified on the underside of the fuse box lid.

  • Page 180: Bulb Replacement

    Bulb Replacement Bulb Replacement REPLACING BULBS Check the operation of all exterior lights before you drive the car. Care point: Only replace bulbs Before replacing any bulb, turn off the lighting switch to with the same type and avoid any possibility of a short circuit. specification.
  • Page 181 Bulb Replacement EXTERIOR LIGHTS Headlights Care point: During use, headlight Your car is equipped with twin headlights. The inboard bulbs may shatter if the glass has headlight bulbs (those nearest the centre of the car) can be been scratched, or contaminated reached from inside the engine compartment, however, the with oil or perspiration.
  • Page 182 Bulb Replacement Outboard headlights (dipped beam) Replacement bulb: H7 55 watt. Turn the front wheels to full left or right lock. This will provide room for you to reach into the wheel arch to remove the headlight access panel. H3257 NOTE: When replacing the bulb, Using a screwdriver, rotate the turnbuckle a quarter turn to ensure the squared section of the...
  • Page 183 Bulb Replacement NOTE: Replacing the outboard When removing the bulb, the following tips will make the headlight bulbs must be done by job easier. ‘feel’ and, in the most part, with • Always remove the electrical connector BEFORE one hand only. unhooking the wire securing clip.
  • Page 184 Bulb Replacement Front fog light Replacement bulb: H1 55 watt. H2789 Operating tip: It may be Pull the inboard side of the fog light surround away from the necessary to insert the blade of a front of the car - see illustration (gentle leverage using a small screwdriver under the flat-bladed screwdriver behind the surround may be metal flange at the base of the...
  • Page 185 Bulb Replacement Front direction indicators Replacement bulb: 21 watt (amber). H2702 Using hand pressure, push the bottom of the outboard corner of the lens very firmly towards the REAR of the car; at the same time, push the inboard side of the lens firmly towards the SIDE of the car.

  • Page 186: Side Repeater Lights (Amber)

    Bulb Replacement Side repeater lights Replacement bulb: 5 watt (amber). H2701 Push the lens firmly towards the front of the car to release the light unit, then withdraw the light from the wing. Twist anti-clockwise to release the bulb holder from the light unit.
  • Page 187 Bulb Replacement Rear lights H2711 Replacement bulbs: 1. Brake light 21 watts 2. Tail light 5 watts 3. Fog guard light 21 watts 4. Reversing light 21 watts 5. Direction indicator light 21 watts (amber) Open the hinged cover inside the boot to access the light unit. Detach the electrical connector from the rear of the light unit by depressing the release catch (arrowed in inset), at the same time pulling the connector free.

  • Page 188: Number Plate Light

    Bulb Replacement Number plate light Replacement bulbs: 5 watt. H2705 Care point: When refitting the There are two number plate lights. To access each bulb, lens, ensure that the curved face remove the two screws securing the lens and remove the lens. points toward the rear.
  • Page 189 Bulb Replacement INTERIOR LIGHTS Front courtesy & map reading lights Replacement bulbs: 3 watt H2695 Insert a small flat-bladed screwdriver into the indent at the rear of the lens (see inset) and gently prise the lens from the light unit. Pull the bulbs from their mountings to remove. When replacing the lens, locate the single ‘prong’...

  • Page 190: Courtesy Lights

    Bulb Replacement Rear courtesy lights Replacement bulbs: 3 watt H2694 Insert a small flat-bladed screwdriver into the indent at the rear of the lens (see inset) and gently prise the lens from the light unit. Pull the bulbs from their mountings to remove. When replacing, locate and position the ‘prongs’...

  • Page 191: Glovebox Light

    Bulb Replacement Boot light Replacement bulb: 10 watt H2783 Insert a small flat-bladed screwdriver into the indent on one of the narrow sides of the lens (see arrow in illustration) and carefully prise the unit from its location. Push and twist the bulb to remove.

  • Page 192: Parts & Accessories

    To enhance your motoring pleasure, a comprehensive and versatile range of quality accessories are available. This wide range of genuine Rover products is an integral part of the car’s design and development programme and will help to guarantee continued reliability, safety and performance.

  • Page 193: Identification Numbers

    Identification Numbers Identification Numbers IDENTIFICATION NUMBERS When communicating with your dealer, always quote the Vehicle Identification Number (VIN). If your communication concerns the engine or gearbox, it may be necessary to quote these numbers too. Vehicle identification number The VIN (and recommended maximum vehicle weights) is stamped on a plate at the foot of the left hand door pillar and also stamped into the top of the right hand front suspension mounting, inside the engine compartment.
  • Page 194 Identification Numbers Identification number locations H2778 1. Vehicle identification number (VIN) 2. Engine number 1.8 petrol models: Stamped horizontally into the centre front face of the cylinder block. 2.0 & 2.5 petrol models: Stamped vertically into the right side of the cylinder block (when viewed from the front). Diesel models: Stamped vertically into the flange between the engine casing and gearbox.

  • Page 195: Technical Data

    Technical Data TECHNICAL DATA Technical Data ENGINES 1.8 litre petrol Fuel UNLEADED 95 RON to EN 228 specification is recommended† Capacity 1796 cm Firing order 1-3-4-2 Idle speed 750 ± 50 rev/min Bore 80 mm (3.15 in) Stroke 89.3 mm (3.52 in) Number of cylinders 4 in-line Compression ratio...
  • Page 196 Technical Data 2.5 litre petrol Fuel UNLEADED 95 RON to EN 228 specification is recommended† Capacity 2497 cm Firing order 1-6-5-4-3-2 Idle speed 750 ± 50 rev/min Bore 80 mm (3.15 in) Stroke 82.8 mm (3.26 in) Number of cylinders 6 V-arrangement Compression ratio 10.5:1...
  • Page 197 Technical Data ELECTRICAL Battery type: 1.8 litre petrol engine with manual H5, sealed for life transmission All other variants H6, sealed for life Battery rating: 1.8 litre petrol engine with manual 61 amp/hr transmission All other variants 75 amp/hr Voltage and polarity 12 V, negative (-) earth...
  • Page 198 Technical Data WHEELS & TYRES Wheel size and type Type Size Steel wheels 6J x 15 Alloy wheels: 15" wheels 6J x 15 or 6.5J x 15 16" wheels 6.5J x 16 17" wheels 7.0J x 17 Spare wheels: space-saver steel† 4J x 16 regulation steel* 6.0J x 15, or 6.5J x 15...
  • Page 199 Technical Data TYRE PRESSURES Normal driving conditions (up to maximum allowable gross vehicle weight) Pressure - bar (lbf/in Tyre Size 1.8 Petrol 2.0 Petrol 2.5 Petrol 2.0 Diesel 195/65 R15 91V Front 2.1 (30) 2.1 (30) 2.1 (30) 2.2 (32) Rear 1.9 (28) 1.9 (28)
  • Page 200 Technical Data Towing Pressure - bar (lbf/in Tyre Size 1.8 Petrol 2.0 Petrol 2.5 Petrol 2.0 Diesel 195/65 R15 91V Front 2.1 (30) 2.1 (30) 2.1 (30) 2.2 (32) Rear 2.3 (33) 2.3 (33) 2.3 (33) 2.3 (34) 205/65 R15 94V Front 2.1 (30) 2.1 (30)
  • Page 201 Technical Data DIMENSIONS H3259 Overall length - A 4747 mm (186.9 in.) Overall width (exc. mirrors) - B 1778 mm (70.0 in.) Overall height (sunroof closed) - C 1424 mm (56.1 in.) Wheelbase - D 2746 mm (108.1 in.) Front overhang - E 914 mm (36.0 in.) Rear overhang - F 1087 mm (42.8 in.)
  • Page 202 Technical Data WEIGHTS Approximate unladen vehicle weight (full fuel tank, excluding options): 1.8 petrol models - Manual transmission 1370 - 1510 kg (3020 - 3329 lb) - Automatic transmission 1420 - 1550 kg (3130 - 3417 lb) 2.0 & 2.5 petrol models - Manual transmission 1440 - 1560 kg (3174 - 3439 lb) - Automatic transmission...
  • Page 203 Technical Data TOWING WEIGHT Max trailer weight (unbraked): All models 750 kg (1654 lb) Max trailer weight (braked): 1.8 petrol models: Manual transmission 1200 kg (2646 lb) Automatic transmission 1400 kg (3087 lb) 2.0 petrol models Manual transmission 1450 kg (3197 lb) Automatic transmission 1600 kg (3528 lb) 2.5 petrol models (manual &...
  • Page 204 Technical Data FUEL CONSUMPTION The fuel consumption figures shown below have been calculated using a standard testing procedure (the new EC test procedure from Directive 93/116/EC), and produced in accordance with The Passenger Car Fuel Consumption (Amendment) Order 1996. Under normal use, a car’s actual fuel consumption figures may differ from those achieved through the test procedure, depending on driving technique, road and traffic conditions, environmental factors, vehicle load and condition.

  • Page 206: Index

    Index Cigar lighter Cleaning - car interior Cleaning - paintwork ABS warning light Climate control Accessories Clock Air conditioning Cold climates Air distribution Coolant top-up Air distribution control Cooling system Air recirculation Courtesy lights Air vents Cruise control Airbag SRS Cubby box Airbag SRS service information Cup holders...
  • Page 207 Index Fuel filler Fuel filling Jacking Fuel gauge Jump starting Fuel specification Fuel system Fuses Keys Gauges Lashing points Gearbox number Lazy seats Gears - automatic Lighting switch Gears - manual Load carrying General data Loadspace light bulb Glovebox Locking Glovebox light bulb Locking - speed related Locking wheel bolts...
  • Page 208 Index Pollen filter Sport mode - automatic transmission Power steering fluid Starter switch Power-operated seats Starting - diesel models Pre-tensioners Starting - petrol models Punctured tyres Steering column adjustment Steering lock Sun visor Sunblind Rain sensor Sunroof Rear fog guard light bulb Superlocking Rear fog guard lights Rear light bulb...
  • Page 209 Index Warning lights Washer jets Washer reservoir - top-up Washers Washing the car Weights Wheel changing Wheels Windows Windows (cleaning) Windscreen washer top-up Windscreen washers Windscreen wipers Wiper blade (cleaning) Wiper blade replacement Wiper controls...

Table of Contents
