- Page 1 Automation Computertechnik Datentechnik Hardware Documentation DS210 Docking Station Version: 1.50 © Copyright ACD Gruppe Dieses Dokument darf ohne Zustimmung weder vervielfältigt noch Dritten zugänglich gemacht werden.
-
Page 2: Table Of Contents
Hardware Configurations ................9 Hardware Configuration ACD DS210 Standard ............9 Hardware configuration ACD DS210 Ethernet ............11 Hardware configuration ACD DS210 Modem 56K TTL ..........13 Hardware configuration ACD DS210 ISDN............... 15 Accessories ....................17 USB Data cable ......................17 Ethernet connection cable .................. -
Page 3: Overview
1 Overview The docking station DS210 is a charging and communication station for the mobile data acquisition terminal M210. Features of the standard version are: • Charging the M210. • Charging one replacement battery. • Data transfer via USB interface to a PC. •... -
Page 4: Security Advices
2 Security advices For operation of the ACD docking station DS210 you may only use power supply packs allowed by ACD! ATTENTION For indoor use only. ATTENTION The power pack must not be covered while it is in operation. ATTENTION Do not place the device near heat sources (e.g. -
Page 5: Scope Of Supply
DS210 with Ethernet 10/100 Base T • Power supply pack • Country specific power cord • CAT 5e FTP cable 3.3 ACD DS210 Modem 56K TTL • DS210 with Analogue Modem • Power supply pack • Country specific power cord •... -
Page 6: Operation Of The Ds210
4 Operation of the DS210 Plug the power cord into the power supply pack. Plug the power cord into the power plug. Plug the low tension connector of the power supply pack into the plug socket at the back of the DS210 on the left side (see picture 2). -
Page 7: Connect
4.1.4 CONNECT The CONNECT LED has a different meaning for each of the four device versions. At the DS210 Standard the CONNECT LED glows green when the USB slave conductor has established a connection with the PC as well as with the M210. It is not checked if the software driver is also loaded for the connection! At the DS210 Ethernet the CONNECT LED blinks green, when the DS210 is connected with the network cable to the LAN (Ethernet) and the M210 has loaded the Ethernet driver. -
Page 8: Remove The M210 Out Of The Docking Station Ds210
M210 by default. A USB memory stick will be recognized automatically as a further drive of Windows CE. Other software drivers for other USB end devices can be integrated by ACD in the image of the M210 on request. -
Page 9: Hardware Configurations
5.1 Hardware Configuration ACD DS210 Standard The ACD DS210 Standard is suitable for charging the M210, for charging a replacement battery, for data transfer via USB interface to a PC and for the connection of a USB end device e.g. a USB memory stick. - Page 10 USB-A USB-B Con. Po.Su DS210 standard version USB- USB- Power supply. Slave Host M210 M210 Pic. 6: Block diagram ACD DS210 Standard DS210_HardwareDocu_V1.50_EN.doc 10 / 20...
-
Page 11: Hardware Configuration Acd Ds210 Ethernet
5.2 Hardware configuration ACD DS210 Ethernet The ACD DS210 Ethernet is suitable for charging the M210, for charging a replacement battery, for data transfer via USB interface to a PC and for connection of a USB end device e.g. a USB memory stick. - Page 12 RJ45 USB-A USB-B Conn with LED‘s P.S.. Netzteil USB – Ethernet converter USB – HUB DS210 Ethernet USB- USB- Voltage supply. Slave Host M210 M210 Pic. 8: Block diagram ACD DS210 Ethernet DS210_HardwareDocu_V1.50_EN.doc 12 / 20...
-
Page 13: Hardware Configuration Acd Ds210 Modem 56K Ttl
5.3 Hardware configuration ACD DS210 Modem 56K TTL The ACD DS210 Modem 56K TTL is delivered with integrated analogue modem. This version of the DS210 is able to charge a M210, to charge one replacement battery, to transfer data either directly from the M210 or via USB interface to a PC, or per remote data transmission via analogue modem. - Page 14 RJ11 USB-A USB-B Conn. P.S. analogue modem adapter USB – HUB USB serial converter DS210 Analogue Modem USB- USB- Power supply Slave Host M210 M210 Pic. 10: Block diagram ACD DS210 Modem 56K TTL DS210_HardwareDocu_V1.50_EN.doc 14 / 20...
-
Page 15: Hardware Configuration Acd Ds210 Isdn
5.4 Hardware configuration ACD DS210 ISDN The ACD DS210 ISDN is delivered with integrated ISDN Adapter. In this version the DS210 can charge a M210, charge one replacement battery, data can be transferred from the M210 either directly via USB interface to a PC, or per remote data transfer to a ISDN adapter. - Page 16 RJ45 USB-A USB-B Conn. P.S. ISDN adapter USB – HUB USB serial converter DS210 ISDN USB- USB- Power supply Slave Host M210 M210 Pic. 12: Block diagram ACD DS210 ISDN DS210_HardwareDocu_V1.50_EN.doc 16 / 20...
-
Page 17: Accessories
Please use a usual USB ‚A – B‘ cable, like e.g. for a printer. You need a type A plug on the PC side, on the DS210 side a type B plug. You can get such a cable directly from ACD Elektronik: Article number 12100321, lenght of cable 1,8 m 6.2 Ethernet connection cable... -
Page 18: Cleaning And Care Advices
7 Cleaning and care advices Clean the device while it is seated stable on a surface (e.g. desk top). This ensures a stable halt and the device cannot drop out of your hands during the cleaning process. Please use a soft and wet cloth for cleaning. -
Page 19: Technical Specifications
8 Technical specifications Operating temperature 0°C – 40°C / 32°F – 104°F Storage temperature 0°C – 60°C / 32°F – 140°F Rel. humidity 5% - 90% non-condensable Input voltage power supply pack 90 – 264 VAC / 47 – 63 Hz Protection IP20 DS210_HardwareDocu_V1.50_EN.doc... -
Page 20: Versions / Changes
9 Versions / Changes Version Date Description 1.00 16.03.07 Docking Station DS210 1.10 20.04.07 Changes Chapter. 3.3 data transmission USB – PC and 3.1.4 Connect 1.20 26.07.07 Minor changes 1.30 30.06.09 Insertation of chapter 4.3 Remove M210 out of the docking station DS210;...
