- Page 1 07 17...
-
Page 2: Table Of Contents
Table of content Introduction ................................3 Identification ................................... 4 Liability ..................................... 4 Warranty conditions ................................ 4 Support .................................... 5 Intended use ..................................5 Target group and previous knowledge ..........................5 Operating limits ................................5 Essentials ..................................6 Technical data .................................. 6 Safety .................................. -
Page 3: Introduction
With the PIEPS iPROBE II (hereinafter referred to as the iPROBE), you have a product that is state of the art in terms of safety and user-friendliness. Despite this, the iPROBE can pose risks if used inappropriately or incorrectly. -
Page 4: Identification
Any other warranties and liability for consequential damage are expressly excluded. For warranty claims, please take proof of purchase and a description of the fault to the point of sale. Manual PIEPS iPROBE II | 07/2017 4 / 17... -
Page 5: Support
Any other use requires the written consent of Pieps GmbH. Improper use can put individuals at risk and result in the unit being damaged. The iPROBE is an electronic avalanche probe with a number of automatic functions – for this reason, the iPROBE may only be used after having read and understood this operating manual. -
Page 6: Essentials
The iPROBE and property of the operator The efficient use of the iPROBE 1.9 Technical data Name PIEPS iPROBE II 220 | 260 | 300 Frequency range 457 kHz Total probe length 220 cm | 260 cm | 300 cm... -
Page 7: Signal Words Used In The Safety Instructions
The iPROBE may only be used in a perfect condition. It is forbidden to alter or change the iPROBE without the written permission of Pieps GmbH. Do not attempt to rectify faults or damage without authorization. Instead, you must contact support, who will tell you how to proceed. - Page 8 In this case, use the iPROBE like a classic avalanche probe. You can find instructions for performing the point search in chapter 4.1.2. The operating personnel must read the operating manual. Manual PIEPS iPROBE II | 07/2017 8 / 17...
-
Page 9: Packaging
The following instructions provide an overview of a possible method for rescuing companions and are not a substitute for deeper discussion. PIEPS recommends attending relevant training courses with professional providers as well as regular training on how to use the emergency equipment. -
Page 10: Pinpointing | Implementation
30 cm. • Communicate a hit and push the probe into the snow. IMPORTANT! Also leave the probe where it is throughout the digging out! It serves as an essential orientation aid! Manual PIEPS iPROBE II | 07/2017 10 / 17... -
Page 11: Iprobe Structure
(1B) clicks into place and a beep from the loudspeaker (1F) indicates that the iPROBE is on. The iPROBE is electronically active only when the beep sounds! Continuous tone for 1 second (piiiiiep) Manual PIEPS iPROBE II | 07/2017 11 / 17... -
Page 12: Self-Test
You can find instructions for performing the point search in chapter 4.1.2 4.4 Functionality during operation Check A1 Check A2 Check A3 Check A Search mode Proximity indicator Hit indicator Check B Check B Sender deactivation Manual PIEPS iPROBE II | 07/2017 12 / 17... -
Page 13: Check A: Search Mode | Proximity Indicator | Hit Indicator
No acoustic signal output uniform beeps at the interval of the transmitting beacons (piep_piep_piep_etc.) Check A3: Hit indicator, active transmitting avalanche beacon within < 0.5 m Both LEDs glow BLUE Continuous tone (piiiiiiiiiie...) Manual PIEPS iPROBE II | 07/2017 13 / 17... -
Page 14: Check B: Sender Deactivation
Deactivation takes place within a few seconds. * Avalanche beacons with iPROBE-Support: PIEPS MICRO, PIEPS DSP PRO, PIEPS DSP PRO ICE, PIEPS DSP SPORT, PIEPS DSP STANDARD ≥ v5.0, PIEPS DSP TOUR, PIEPS FREERIDE Check B: Sender deactivation, temporary deactivation of the transmitting avalanche beacon within <... -
Page 15: Turning Off And Correct Folding
Always start the folding procedure with the bottom probe tube and always push the probe tubes in until they stop before starting the next folding procedure. This ensures the probe cable will have a long service life. Manual PIEPS iPROBE II | 07/2017 15 / 17... -
Page 16: Troubleshooting, Maintenance, Storage, Disposal
3) Check the battery capacity, type and polarity (+,-); if necessary, fit a new battery 4) Reactivate the iPROBE If the iPROBE still does not respond or shows a system fault as before, please contact a PIEPS Service Center or our Support team (support@pieps.com). -
Page 17: Cleaning
6. Approval & conformity The approval text and the full text of the EU conformity declaration is available at the following website www.pieps.com/conformity Manual PIEPS iPROBE II | 07/2017 17 / 17...
