Thermomètres infrarouge
§
Infrared thermometers
§
Infrarot - thermometer
§
Termometri a infrarossi
§
Termómetros infrarrojo
E N G L I S H
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Phone: 021-8690 6777 (Hunting)
C.A 1864
C.A 1866
User's manual
Mobile: +62 816 1740 8925
Fax: 021-8690 6771
Fax: 021-8690 6777

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C.A 1864 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALAT UJI C.A 1864

  • Page 1 § Thermomètres infrarouge C.A 1864 § Infrared thermometers § Infrarot - thermometer C.A 1866 § Termometri a infrarossi § Termómetros infrarrojo User’s manual E N G L I S H Mobile: +62 816 1740 8925 Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia Workshop: Jl.
  • Page 2 C.A 1864 – C.A 1866 English Thank you for purchasing a C.A 1864 or C.A 1866 infrared thermometers. To get the best service from this instrument: • Read this user’s manual carefully, • Respect the safety precautions detailed MEANING OF THE SYMBOL Sorting of wastes required for the recycling of electrical and electronic equipment in the European Union.
  • Page 3 English C.A 1864 – C.A 1866 PRECAUTIONS FOR USE If this device is damaged or a part is missing, please contact the dealer immediately. The protection provided by the device may be compromised if it is used in a way not specified by the manufacturer.

  • Page 4: Table Of Contents

    C.A 1864 – C.A 1866 English SUMMARY PRESENTATION ..................20 FUNCTIONING - EMISSIVITY ..............20 DESCRIPTION ..................21 USE ......................22 PROCEDURE ..................... 22 MEASUREMENT PRECAUTIONS ............... 22 « TARGET DISTANCE / MEASUREMENT FIELD DIAMETER » RATIO ..23 MEASUREMENT PARAMETERS ..............24 ERROR MESSAGES ...................

  • Page 5: Presentation

    0.1 for a highly reflective surface, and 1 for a black body. In the case of the C.A 1864 and C.A 1866 thermometers, the emissivity can be adjusted from 0.1 to 1, the value of which is determined depending on the material of the body or surface to be measured.

  • Page 6: Description

    C.A 1864 – C.A 1866 English DESCRIPTION 1 : LASER view finder aperture 2 : Measurement lens 3 : LCD display decrease in increments of emissivity values, hight and low value of the alarm increase in increments of emissivity values, hight and low value of the alarm...

  • Page 7: Use

    English C.A 1864 – C.A 1866 Never aim the LASER beam towards eyes. PROCEDURE Press the black trigger, all screen segments are displayed and the instrument carries out a measurement as set-up before it was last switched off. SCAN appeared on the screen. The HOLD symbol is displayed when you release the...

  • Page 8: Target Distance / Measurement Field Diameter " Ratio

    C.A 1864 – C.A 1866 English « TARGET DISTANCE / MEASUREMENT FIELD DIAMETER » RATIO This ratio, also known as the field of vision, indicates the diameter of the probes’ measurement field at a given distance from the target (see figure below).

  • Page 9: Measurement Parameters

    English C.A 1864 – C.A 1866 MEASUREMENT PARAMETERS The choice and setting of the measurement parameters is carried out by successively pressing the MODE button: ■ EMI (see fig to right) The emissivity percentage is adjusted using the buttons qpaccording to the surface being ε...
  • Page 10 C.A 1864 – C.A 1866 English ■ MIN (see fig to right) When the trigger is pressed and held, the small right-hand display indicates minimum ε = 0.9 HOLD temperature value measured whilst the trigger °C is pressed. The measurement set-up is held in memory 234.8...

  • Page 11: Error Messages

    English C.A 1864 – C.A 1866 (1) C/F Select the temperature units ( C or F) using the switch (2) LOCK ON / OFF To lock the unit on for continuous measurement, slide the middle switch LOCK ON/OFF right. If the trigger is pulled while the unit is lock on, the laser and backlight will turn on if they have been activated.

  • Page 12: Specifications

    C.A 1864 – C.A 1866 English SPECIFICATIONS SPECIFICATIONS • Measurement range : -50 to +1000°C (-58 to +1832°F) • Resolution : 0,1°C/0,1°F • Polarity indication : automatic (minus only) • Accuracy : -50 to –20°C (-58 to –4°F): ±5°C (±9°F) -20 to 200°C (-4 to 392 °F):...

  • Page 13: Warranty

    English C.A 1864 – C.A 1866 WARRANTY Our guarantee is applicable for twelve months after the date on which the equipment is made available (extract from our General Conditions of Sale, available on request). MAINTENANCE For maintenance, use only specified spare parts. The manufacturer will not be held responsible for any accident occuring following a repair done other than by its After Sales Service or approved repairers.
