Summary of Contents for Plevo Runner

  • Page 1 RUNNER User's manual...

  • Page 2: Table Of Contents

    Contents Chapter 1: Overview of the PLEVO Runner. Chapter 2: First steps. Download the PLEVO App. Turning on the suitcase. Pairing. Chapter 3: Removable battery. Parts and characteristics. Installation. Extraction. Loading devices. Backup battery. Chapter 4: Removable wheels. Installation. Disassembly.
  • Page 3 Chapter 10: Search for a mobile device. Chapter 11: Shutting down the suitcase. Chapter 12: Unlinking a device. PLEVO Runner - User's manual 2019 RUNNER User's manual...

  • Page 4: Chapter 1: Overview Of The Plevo Runner

    Front Cover Removable wheel Main handle button Dashboard Battery access cover Rear electronic closure Rear badge Rear cover Handle structure Wheel fastener Note: Some external components of the Runner model vary between the Infinite and UP models. RUNNER User's manual...

  • Page 5: Chapter 2: First Steps

    Download the PLEVO App In order to start using all the electronic functions of the suitcase it is necessary to download the PLEVO App in the App Store for the iOS operating system or in Google Play for the Android system.

  • Page 6: Pairing

    Raise the main handle to access the button. Pairing To connect your Runner suitcase with a mobile device, follow these steps: 1) Activate the Bluetooth of your mobile device. 2) Select the model of your suitcase in the App and bring the device close to the suitcase's board for two seconds until the CYAN lights on the board and front panel gets turn on.
  • Page 7 Important: In case of problems in pairing with Android devices, we recommend that you move the phone closer to the board to improve the Bluetooth connection. After making the connection with the suitcase, the user can get away from it perfectly and use the different functions. RUNNER User's manual...

  • Page 8: Chapter 3: Removable Battery

    03 - Removable battery. All PLEVO suitcases incorporate a removable 8,000 mAh battery that supplies power to the internal backup battery and allows the charging of mobile devices. Parts and characteristics -Dimensions Capacity: on/off button Charging lights Installation Raise the main handle and access the rubber cover located on the back of the board.

  • Page 9: Extraction

    Open the rubber cover to the right in order to access the internal compartment of the board. Place the battery horizontally (with the PLEVO logo facing up) and press until it locks the mechanism and is anchored. Extraction Open the rubber cover to the right in order to access the battery.

  • Page 10: Loading Devices

    To display the charge level, press the button and the lights will turn on automatically indicating the battery status. The maximum load level is represented by 4 lights lit CYAN color. Power button Charging lights RUNNER User's manual...

  • Page 11: Backup Battery

    Backup battery All PLEVO suitcases have a Nickel ion backup battery located inside the board that complies with all established regulations. It is responsible for feeding the suitcase system when the removable battery is not installed. Backup battery Important: The backup battery is charged automatically when the removable battery is installed.

  • Page 12: Chapter 4: Removable Wheels

    Slide and hold the safety lock back and place Support orifice the wheel bolt in the hole in the support following the shape of the wheel. Bolt Put pressure on the wheel until the bolt fully enters the support orifice. RUNNER User's manual...

  • Page 13: Disassembly

    Follow steps 1 and 2 to remove the locks and disassemble the wheels. Press and hold the lock back to release the bolt. Bolt Pull the wheel back while holding the safety lock. The wheel will be dismantled once the bolt has come completely out of the hole. RUNNER User's manual...

  • Page 14: Chapter 5: Opening And Closing The Suitcase

    05 - Opening and closing the suitcase General components of the closure TSA Logo Closure lock Indicator light Side closure Morse code button TSA Lock Opening command Opening command TSA Logo Back closure Morse code TSA Lock Indicator button light RUNNER User's manual...

  • Page 15: Electronic Opening And Closing By Face Id / Touch Id

    Electronic opening and closing by Face ID / Touch ID With the PLEVO App, it is possible to open or close the suitcase using biometric data. According to the mobile model used, facial recognition or fingerprinting can be used. Opening Follow steps 1 to 3 to open the suitcase with biometric data.
  • Page 16 Follow steps 1 and 2 to close the suitcase. Handles Insert the handles into the closing Select the "Close" function in the holes until the adjustment of the Lock section of the App. locks occurs. The suitcase will automatically close. RUNNER User's manual...

  • Page 17: Electronic Opening And Closing By Morse Code

    Electronic opening and closing by Morse Code All PLEVO suitcases have an alternative closure system by Morse Code. Only one configuration of the code is required for one time and will be ready to be used at any time without relying on the mobile device.
  • Page 18 CYAN color for 3 seconds and the closing flaps will open automatically. Command Indicates that the suitcase was opened correctly CYAN light using the Morse Code. On for 3 sec. Indicates that the Morse Code was entered RED light On for 3 sec. incorrectly. RUNNER User's manual...
  • Page 19 Important: In case of making a new numerical configuration for the Morse Code and recording problems when opening / closing the suitcase, it is advisable to disconnect and reconnect the "Bluetooth" function of your Android or iOS mobile device. RUNNER User's manual...

  • Page 20: Opening With A Key

    Opening with a key All PLEVO suitcases have a set of keys approved by the TSA to open and close in an alternate way. To operate with this method it is necessary to follow the following steps: Locate the set of keys that accompanies the PLEVO suitcase and enter one of them inside the TSA lock.

  • Page 21: Chapter 6: Digital Scale

    06 - Digital scale Sensors The PLEVO suitcases have a set of sensors located on the internal ends of the secondary handle that act in conjunction with the App to record the weight of the suitcase and its load. Secondary handle...
  • Page 22 -During the weighing process, avoid that the suitcase touches the ground. -The weight obtained can have a variation of + - 800 grams concerning the actual weighing. -The weighing can be restarted following the same steps described above. RUNNER User's manual...

  • Page 23: Chapter 7: Rear Compartment - Quick Access

    07 - Rear compartment - Quick access. The PLEVO Runner model has a rear storage compartment with an independent closing system. OPENING It is necessary to operate the independent rear lock to open the lid. It has an identical functioning to the lateral closure. See Opening and closing suitcase, p. 13...

  • Page 24: Storing A Notebook

    Storing a notebook The rear access allows you to store a laptop 13 "inside, for safety it is recommended to locate it in the pocket designed to hold devices safely, located on the back of the suitcase. RUNNER User's manual...
  • Page 25 BlueTooth connected when you remove the suitcase from the conveyor. - The suitcase will automatically link with your mobile device when entering within the range of the BlueTooth on the conveyor belt. The PLEVO will be ready to use and the removable battery can be installed again if desired.

  • Page 26: Chapter 9: Lights

    Indicates that the Morse Code has been entered RED light On for 3 sec. incorrectly. Indicates that the suitcase was opened correctly CYAN light On for 3 sec. using Face ID / Touch ID or Morse Code. RUNNER User's manual...

  • Page 27: Indicator Lights And Alerts On The Front Board And Panel

    Indicator lights and alerts on the front board and panel The PLEVO suitcases have two lights (A) present on the board and one (B) on the front panel that communicate the status of the suitcase lock and the pairing with mobile devices.
  • Page 28 PLEVO that helps to locate it. For this function is necessary: Find my phone - Press only once and quickly the On / Off button (with the case on) for the PLEVO to locate the device and generate an alert. There will be an immediate notification on the mobile.
  • Page 29 To completely unlink the suitcase from a mobile device it is necessary: Get into the "Info" section Click the red basket on the top right and within the PLEVO App. finally confirm. The suitcase will automatically turn off. RUNNER User's manual...
  • Page 30 www.plevo.co/help...
