Installation Instructions
MATTIRA
Digital Modulating Electric Boilers
MAS15 | MAS18
Please read these instructions carefully before
installing or using this appliance for the first time.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MATTIRA MAS15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Elnur MATTIRA MAS15

  • Page 1 Installation Instructions MATTIRA Digital Modulating Electric Boilers MAS15 | MAS18 Please read these instructions carefully before installing or using this appliance for the first time.
  • Page 2: Table Of Contents

    WARNING: This indication shows the possibility of causing death from electric shock. WARNING: This indication shows the possibility of causing death or serious injury. CAUTION: This indication shows the possibility of causing injury or damage to properties only. Symbol For Useful Information. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 3: Safety

    • The installation must be performed in accordance with current IEE Wiring Regulations, Building Regulations, Water Fitting Regulations (England & Wales) or Water Byelaws (Scotland) and all relevant British Standards. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 4: Safety Devices

    Competency for electrical installation is required. at a cardboard recycling site. recycling site. Observe national regulations. The power supply must meet the capacity for the Observe national regulations. heat output required plus all other appliance that Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 5: Location

    Boiler – 50 Kg. be maintained in front of the boiler to enable easy ac servicing. Ensure sufficient space to make all water connection Elnur powered by Gabarrón | MATTIRA | Installation Guide including the outlet pipes for the heating safety valve...
  • Page 6: Water Connections - General 4.9

    Test kits specifically for this purpose are available from ugh care inhibitor stockists. nces are xpert etc. when tached pipe-work or components. ave a sufficient load-bearing capacity. Check the quality of Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 7 All installations must be fitted in accordance with an air release valve (automatic type all local regulations in force at that time. Failure to recommended) installed. comply with these regulations will invalidate the manufacturers’ warranty. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 8: Pump Duty

    12kW 13kW 15kW boiler Supply current 17.4A 21.7A 26.1A 30.4A 34.8A 39.1A 43.5A 47.8A 52.2A 56.5A 65.2A MCB / RCD rating Minimum 2.5mm 10mm 10mm 10mm 16mm 16mm 16mm cable size Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 9 It is recommended that the boiler is controlled by an external control such as a time clock or room thermostat Controls or a combined programmable room thermostat such as the Elnur model CTP-10. hat the boiler is controlled by an external control such as a time clock or room thermostat or a combined CAUTION: The switching connection of this control should be VOLT FREE and connected thermostat such as the Elnur model CTP-10.
  • Page 10: Commissioning

    TIMIN. Minimum water flow temperature in AUTO heating mode. TEMAX. Outdoor temperature from which the water flow temperature will be TIMIN. TEMIN. Outdoor temperature below which the water flow temperature will be TIMAX. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 11: Limiting Boiler Maximum Output

    8.7A 8.7A 17.4A 13.0A 13.0A 8.7A 8.7A Connection Three-Phase 3x400v~+N Connection Single Phase 230v~ * The standard configuration of the boiler only allows a maximum of 12kW when connected SINGLE-PHASE 230V~. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 12: Heating System Flushing

    An LED indicator informs about the operating status of the pump: - Green: correct operation. - Green / red flashing: Lower voltage U<180V; overvoltage U>253V; Module overheating - Red flashing: pump blocked. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 13: Operating The Boiler

    If the heating function is not selected the screen will not display a value but just a red dot. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 14: Central Heating Operation

    TEMAX. Outdoor temperature from which the water flow temperature will be TIMIN. TEMIN. Outdoor temperature below which the water flow temperature will be TIMAX. TEMIN. Outdoor temperature below which the water flow temperature will be TIMAX. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 15: Heating Modulation Feature

    TEMIN. Outdoor temperature below which the water for a few hours even when automatic control mode, you would proceed as follows: flow temperature will be TIMAX. In the above example TEMIN=2ºC. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 16: Troubleshooting

    Low heating temperature. Failure of heating elements. Check and replace. Heat requirements miscalculated. Re-calculate & configure. If the suggested action fails to resolve a problem, please contact ELNUR technical service for further advice. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 17: Overheat Lock-Out & Re-Setting

    This type of valve modulates open when necessary to ensure that the appropriate minimum flow rate is maintained uration that is set on the boiler and also the modulated operating Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 18: Main Components List

    - The outer case can be cleaned with a damp cloth having first isolated the boiler from the mains. Do not use solvents or abrasive cleaners. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 19: Technical Data

    ◆ ◆ 100°C heating temperature limiter ◆ ◆ 3 bar central heating relief valve ◆ ◆ Ambient thermostat intake ◆ ◆ Sound power level (LWA) ◆ included using connecting links included Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 20: Declaration Of Conformity

    Any use not according to the instructions and/or any change to the appliance will invalidate this declaration of conformity. Algete, 28 de Octubre de 2016 Place, Date Alberto Fernández Director Gerente ELNUR, S.A. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 21: Product Fiche

    13. PRODUCT FICHE MODELO(S): GABARRON MATTIRA MAS15 (wall mounted electric SYSTEM boiler CONDENSING BOILER: NO LOW TEMP. BOILER: NO B1 BOILER: NO 13 PRODUCT FICHE CO-GENERATION SPACE HEATER: NO COMBINATION HEATER: NO MODELO(S): GABARRÓN MATTIRA MAS15 (wall mounted electric SYSTEM boiler) CONDENSING BOILER: NO LOW TEMP.
  • Page 22: Warranty

    - The boiler has been installed in the UK or Ireland. - The warranty card supplied separately with this manual is completed and returned to Elnur UK Ltd or that the online guarantee registration form is completed and submitted at www.elnur.co.uk within 21 days of purchase.
  • Page 23: Installation Commissioning Checklist

    *All installations in England and Wales must be notified to Local Authority Building Control (LABC) either directly or through a competent persons Scheme. A Building Regulations Compliance Certificate will then be issued to the customer. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 24: Electrical Installation

    *All installations in England and Wales must be notified to Local Authority Building Control (LABC) either directly or through a competent persons Scheme. A Building Regulations Compliance Certificate will then be issued to the customer. Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 25: Maintenance Checklist

    Check and advise the householder not to place any clothing or other combustible materials against or on top of this appliance Complete the service record log The manufacturer’s literature, including Installation Checklist and Service Record, has been explained and left with the customer Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 26: Service Record

    Comments: Signature: Signature: SERVICE RECORD #05 DATE: SERVICE RECORD #06 DATE: General/Heating Electrical General/Heating Electrical Engineer name: Engineer name: Company name: Company name: Telephone No: Telephone No: Comments: Comments: Signature: Signature: Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 27 Comments: Signature: Signature: SERVICE RECORD #11 DATE: SERVICE RECORD #12 DATE: General/Heating Electrical General/Heating Electrical Engineer name: Engineer name: Company name: Company name: Telephone No: Telephone No: Comments: Comments: Signature: Signature: Elnur powered by Gabarrón | MATTIRA | Installation Guide...
  • Page 28 Travesía de Villa Esther, 11 28110, Algete Madrid Telephone: +34 916281440 15190020 R2 | EN www.elnur.co.uk © All rights reserved. As part of the continuous improvement policy, ELNUR, S.A. reserves the right to alter or modify any specifications without notice.
