Sun-Power Autogates XP Series Manual

Hide thumbs Also See for XP Series:

Advertisement

Quick Links

Download this manual
V10
Version
Creating jobs in Australia
Smart & Green Auto Gate Operators
Australian made XP Series Automatic Gate Operators
Installation Guide & Owner's Manual – V10
©
Protect Your Warranty
• Read this manual before you begin installation
• Follow these instructions carefully.
• Refer to manual during installation.
• Refer to this manual before doing any maintenance
.
Take your time - Follow this manual - Get it right - Enjoy the benefits
This Instruction Booklet/Owner's Manual
should be retained by Gate owner for future reference.
This Manual is available on our web site
www.sungateaustralia.net
129 Gladstone Street, Fyshwick, ACT 2609
Ph: 02-6280 4655 Fax: 02-6280 7592
Email: sales@progressivecontrols.com.au
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the XP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sun-Power Autogates XP Series

Summary of Contents for Sun-Power Autogates XP Series

  • Page 1 Version Creating jobs in Australia Smart & Green Auto Gate Operators Australian made XP Series Automatic Gate Operators Installation Guide & Owner’s Manual – V10 © Protect Your Warranty • Read this manual before you begin installation • Follow these instructions carefully.

  • Page 2: Table Of Contents

    Index Dear Installer/Owner/Introduction Essential Info – Do’s & Don’ts – Maintenance Important Safety Warnings Installation Standard Installation Installation Procedure - 10 Install Radio receiver & Antenna When to connect power Adjusting Micro/Limit Switches Side Mount Installation / Out-swing / Restricted side room 11 - 13 Control Board &...

  • Page 3: Dear Installer/Owner/Introduction

    Circuitry for most options is already included. You simply connect up the external devices with no extra boxes or cables required. The design features in the XP Series gate operator will save you hours on site keeping the installation neat and tidy. Apart from the physical attributes the control circuit has some powerful operating features.
  • Page 4 The Sun-Power XP Series Automatic Gate Operator is an Australian Made electronically controlled automatic gate operator for swing gates. The XP Series has a range of features that are built in and some options available and can be used in a variety of situations/ •...
  • Page 5 /or organization who may use the equipment Maintenance: XP Series Auto Gate Operators are low maintenance units, however that does not mean maintenance free. The following is strongly recommended 3 Monthly routine a.

  • Page 6: Important Safety Warnings

    IMPORTANT - SAFETY WARNINGS Please read these important safety warnings before installing or using this product ● Never let children operate or play with the controls. ● Keep the transmitter/remote control away from the children. ● Do not operate the swing gate unless the gate is in full view and free from objects such as cars, children or people.

  • Page 7: Installation

    Standard Installation (PULL) XP series Operator Note re Figure 1 above: If the Space between Hinge centre and edge of mounting post/pillar/wall exceeds 200mm it may be necessary to extend the Secondary arm. Installation: Ensure that the gates swing freely to ‘Open’ & to ‘Close’ and that all existing Latches/Pad bolts/Chains etc are disabled or removed from the gate &...
  • Page 8 The vertical position is found by locating the gate bracket. The gate bracket is best placed where there is adequate fixing on the gate and the movement of the arms is unrestricted (See Figure 2). The gate operator may now be bolted in place. XP series Operator...
  • Page 9 DO NOT alter any pre-wiring except Brown & Blue. Altering pre-wiring (except motor polarity Brown & Blue) will compromise your warranty. The XP Series Gate Operators are set in the factory for a “standard installation” with the MASTER [Solar or Electric] placed on the left-hand side (inside looking out). If the master has to be located on the right then the motor wires need to be reversed.
  • Page 10 (using the spanner provided unscrew the bolt until the arm swings freely) then clamp the gate bracket in position. Open and close the gate to ensure the gate bracket is appropriately located. XP series XP series Operator Operator Connect power (12-volt 24 volt or solar) to the primary operator and connect the battery.

  • Page 11: Side Mount Installation / Out-Swing / Restricted Side Room

    The limit switches may now be adjusted (see figure 5) Each of the Master and Slave operators has its own pair of cams, one to set the open position and one to set the closed position. Firstly, mark the position of each cam as a reference point before you loosen the screw holding the cams.
  • Page 12 XP Unit XP Unit XP Unit See also section on out swing installation Each XP operator should be fitted to the pier/post with its output shaft close to the gate hinge. With this in mind the standard installation instructions may now be followed. Special covers are supplied to suit this type of installation.
  • Page 13 XP series Operator Mark a point on the gate suitable for the gate bracket. Holding the gate bracket in position, measure the distance between the hole centres on the gate bracket and primary arm. Move the primary arm to its maximum open position. Open the gate and measure the distance again (See figure 8).
  • Page 14 The gate bracket and secondary arm should now be fitted. Out-Swing Installation (PUSH) In this type of installation, the gate swings outward away from the XP Series operator to the open position. Several factors must be considered to determine the most suitable arm length. These include •...
  • Page 15 Figure 9 Gate Operator Control Board Normal Operation...
  • Page 16 RESET. This button needs to be pushed after changing dip switches DIP SWITCHES The dip switches are used to switch between the modes: Auto Close Auto Close with Security Close Electronic Lose (on) / Magnetic Lock (on) Pedestrian Auto Close Electronic Lock NO/NC Dip switch is sued to choose between electronic lock NO [Normally Open] or NC [Normally Closed] Pedestrian Auto Close...
  • Page 17 Flashing Time: Potentiometer will set the time before auto/security close activation for the flashing light to be activated Motor 1 – Close Delay Potentiometer will set the time delay for motor 1 to close from activation Auto Close Delay: Potentiometer will set the time delay for door to close in auto mode. This will also act as the timeout in security close mode Security Close Delay Potentiometer will set the time delay for door to close in security mode Courtesy Light Time Potentiometer will set he activation time for the...
  • Page 18 Push-button / Key-Pad etc – a variety of wireless & hard-wired input devices can be used to operate the XP Series operator. Input should be in the form of a MOMENTARY CLOSED CIRCUIT. WARNING! Voltage must not be applied to these terminals.
  • Page 19 Auto Delay Auto Close...
  • Page 20 Push-button / Key-Pad etc – a variety of hard-wired input devices can be used to operate the XP Series operator. Input should be in the form of a MOMENTARY CLOSED CIRCUIT. WARNING! Voltage must not be applied to these terminals. Damage to the circuitry will result if voltage is applied.
  • Page 21 Electric Lock / Mag Lock- Connection for an electric lock/latch (EL) are provided on the circuit board. (see figure 9). This connection block will supply 12 Volts to energise the lock at the beginning of the opening and closing cycles. Lock/Latch...
  • Page 22 Photo-electric safety cell (240 volt or 12-volt operators only) – A photo electric safety cell (PE) may be fitted to detect obstructions in the path of the gate(s). The PE will check for obstructions during the closing cycle only. If an obstruction is encountered the gate(s) will reverse to the open position.

  • Page 23: Solar Wiring Detail

    Solar Wiring Detail DO NOT connect solar panel until all other settings and adjustments have been completed. For optimum charging clean solar panels regularly. Step 1 Locate the two-way terminal connection block on top plate near motor. This will have Red (positive) and black (negative) wires.

  • Page 24: Troubleshooting

    Negative wire is already connected NEW DIAGRAM REQUIRED HERE Locate Positive Wire (RED) Connect RED wire to + on Battery Note: All Gate Operator Kits (Solar, 240 volt and 12 volt) are supplied complete with a 9 AMP hour battery. This battery should be checked regularly. TROUBLESHOOTING Poor range with the radio transmitter (Tx).

  • Page 25: Radio Receiver

    Programming Transmitters Important: The Radio receiver, Remote Controls and Digital Key Pad are generally pre-programmed. Instructions below are for re-programming if necessary. Remote Control Wireless Keypad With code entry (DK50) (TX10) For domestic use ONLY SPXPPB-RAD-2 Wireless Push button Press & release ‘LEARN’ with 2 position key button On Radio receiver switch.
  • Page 26 Programming your Transmitters: Troubleshooting Remotes and Keypads/ FAQ I tried changing the pin code on my I press the button on my remote and wireless DK50 keypad. Now I can’t the little light on it isn’t coming on. remember the new code! My gate won’t open either! Sounds like a flat battery in your remote! Time for a new one.
  • Page 27 Details & Freight Dimensions Sun-Power XP Series Auto Gate Operators Chassis & Case 245mm High x 140mm Wide x 335mm Deep Primary arm. Pivot centres 540 mm Secondary arm. Pivot centres 545mm Sizes & Weights of various Kits: XP 100 Single 240v Kit 1 Ctn.
  • Page 28 [Type here]...
